🔧 Yukon - Cabin Air Filter Replacement

Replacing the cabin air filter keeps dust, pollen, and road debris out of your A/C and heat system. A clogged filter can cause weak airflow, musty smells, and extra strain on the blower motor.

Difficulty Level: Beginner | Estimated Time: 10-20 minutes

---

⚠️ Safety & Precautions

• ⚠️ Turn the ignition OFF and remove the key before working under the dash.
• ⚠️ Do not force the glove box or trim; tabs can snap.
• ⚠️ No battery disconnect is required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Trim removal tool (plastic)
• Phillips #2 screwdriver
• Small flashlight
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Cabin air filter - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Move the front passenger seat back to give yourself room.
• Tip: Keep a small cup for screws.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Empty and open the glove box

• Open the glove box and remove any items so nothing falls out.
• Use a small flashlight to look at the right side of the glove box for a small “damper” arm (a little strap that slows the door).

Step 2: Disconnect the glove box damper (if equipped)

• If you see a damper arm on the right side, gently pop it off its pin using a trim removal tool (plastic).
• A trim tool is a plastic pry tool that helps release clips without scratching.

Step 3: Drop the glove box down

• Push in on both sides of the glove box (near the back edges) with your hands to release the stop tabs.
• Let the glove box swing downward slowly.
• Tip: Push one side at a time if tight.

Step 4: Remove the cabin filter access cover

• Behind the glove box, locate the cabin filter cover (a rectangular plastic door).
• Release the cover tabs by hand; if there are screws, remove them using a Phillips #2 screwdriver.

Step 5: Remove the old cabin air filter

• Pull the filter straight out. Use nitrile gloves if it’s dirty.
• Note the airflow direction arrow on the filter frame (you’ll match it on the new one).

Step 6: Install the new cabin air filter

• Slide the new filter into the slot in the same orientation as the old one.
• Make sure it seats fully and isn’t folded or pinched.

Step 7: Reinstall the cover and glove box

• Reinstall the access cover until the tabs click; if screws were removed, install them with a Phillips #2 screwdriver (snug only; do not overtighten).
• Lift the glove box back up and push the sides in to pass the stop tabs back into place.
• Reconnect the damper arm (if equipped) by pressing it back onto its pin by hand.

---

✅ After Repair

• Start the engine and run the HVAC blower on medium, then high, to confirm strong airflow.
• Switch between fresh air and recirculation to verify normal operation.
• If you hear a ticking or fluttering noise, recheck that the filter is fully seated and the cover is clipped in.

---

💰 DIY vs Shop Cost

Shop Cost: $80-$160 (parts + labor)

DIY Cost: $15-$45 (parts only)

You Save: $65-$115 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.2-0.4 hours.

---
