🔧 F-250 Super Duty - Cabin Air Filter Replacement

On many Super Duty trucks in this generation, a cabin air filter was not installed from the factory. If your A/C case has a small filter access door behind the glove box, you can replace it in minutes. If there’s no access door, the truck isn’t equipped (a retrofit kit is required).

Difficulty Level: Beginner | Estimated Time: 0.2-0.6 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn the ignition OFF and remove the key before working under the dash.
• ⚠️ Use a flashlight and work slowly to avoid snapping plastic dash clips.
• ⚠️ Battery disconnect is not required for a standard filter swap.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Trim removal tool set
• Phillips screwdriver
• 7mm socket
• 1/4" drive ratchet
• Flashlight
• Work gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Cabin air filter - Qty: 1
• Cabin air filter retrofit kit - Qty: 1 (only if no factory access door)

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Move the passenger seat back for more working room.
• Tip: Take a photo before removing anything.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Access the area behind the glove box

• Open the glove box and remove all items.
• If a damper strap is attached on the right side, gently unhook it by hand or use a trim removal tool set.
• Push in on both sides of the glove box to clear the stops, then let it swing down.

Step 2: Check for a cabin filter access door

• Use a flashlight to look straight behind the glove box toward the HVAC case (the black plastic A/C housing).
• Look for a small rectangular cover/door (often held by tabs or small screws).
• If you do not see any access door or slot for a filter, your A/C case likely does not have a serviceable cabin filter without a cabin air filter retrofit kit.

Step 3: Remove the access door (if equipped)

• If the door uses tabs, release them by hand or with a trim removal tool set.
• If screws are present, remove them using a 7mm socket and 1/4" drive ratchet or a Phillips screwdriver (use the tool that matches your fasteners).
• Set the door/screws aside where they won’t get lost.

Step 4: Remove the old cabin air filter

• Slide the filter straight out with your hands (wear work gloves if it’s dirty).
• Keep it level as you pull it out to avoid dumping leaves and dust.
• Tip: Vacuum the slot if debris is visible.

Step 5: Install the new cabin air filter

• Check the airflow arrow printed on the filter frame.
• Install the new filter in the same direction the old one came out (airflow arrow must match the housing direction).
• Slide it in fully so it seats flat and doesn’t buckle.

Step 6: Reinstall the access door and glove box

• Reinstall the filter door and tighten screws snug using a 7mm socket and 1/4" drive ratchet (do not overtighten plastic).
• Lift the glove box back up, push the sides inward to pass the stops, and close it.
• Reconnect the damper strap if equipped.

Step 7: If there is no access door (retrofit note)

• A retrofit kit typically requires removing trim and cutting an outline in the HVAC case to create a filter opening.
• This is doable, but it’s more involved and must be done carefully to avoid damaging the evaporator core (the cold A/C radiator inside the case).
• Tip: If you choose retrofit, follow the kit’s template exactly.

---

✅ After Repair

• Start the engine and turn the blower fan to high.
• Confirm airflow is strong and there are no new rattles behind the glove box.
• If you smell dust for a minute, that’s normal as the system clears out.

---

💰 DIY vs Shop Cost

Shop Cost: $80-$180 (parts + labor)

DIY Cost: $15-$45 (parts only)

You Save: $65-$135 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.2-0.6 hours.

---
