🔧 Canyon - Cabin Air Filter Replacement

Your Canyon’s cabin air filter cleans the air going through the HVAC system (heat/AC). Replacing it helps reduce dust, musty smells, and weak airflow from the vents.

Difficulty Level: Beginner | Estimated Time: 0.3-0.8 hours

Assumption: Standard glovebox-access cabin filter housing (most 2015–2016 Canyon).

---

⚠️ Safety & Precautions

• ⚠️ Turn the ignition OFF and remove the key before working near the dash.
• ⚠️ Don’t force plastic tabs—use steady pressure to avoid breaking them.
• ⚠️ No battery disconnect is required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Trim removal tool
• Flashlight
• Small flathead screwdriver
• Work gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Cabin air filter - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Open the passenger door for better access and lighting.
• Empty the glovebox so nothing falls out when it swings down.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lower the glovebox

• Open the glovebox fully.
• Use a trim removal tool to gently help the glovebox side stops clear the dash opening (these are the plastic “ears” that keep it from dropping).
• If your glovebox has a soft-open strap/damper on the right side, use a small flathead screwdriver to carefully pop it off its peg. Go slow—small plastic parts break easily.
• Let the glovebox swing downward to expose the HVAC housing behind it.

Step 2: Remove the cabin filter access door

• Find the rectangular cabin filter cover directly behind the lowered glovebox.
• Use your flashlight to see the retaining tabs.
• Press the tabs and remove the cover by hand; if tight, use the trim removal tool to gently pry at an edge.

Step 3: Remove the old cabin air filter

• Slide the filter straight out.
• Note the airflow direction arrow on the filter frame (it must match when you install the new one).
• Use work gloves—the old filter can be dusty and sharp-edged.

Step 4: Install the new cabin air filter

• With the flashlight, check the housing for leaves/debris and remove any you can reach by hand (with work gloves).
• Slide the new filter in the same orientation as the old one, matching the airflow arrow.
• Make sure it seats fully and isn’t folded or pinched.

Step 5: Reinstall the access door and glovebox

• Reinstall the filter cover and press until the tabs click into place.
• Lift the glovebox back up.
• Reattach the glovebox damper (if equipped) by pushing it back onto its peg by hand.
• Push the glovebox sides inward so the side stops pass the dash opening, then close the glovebox normally.

---

✅ After Repair

• Start the engine and run the blower fan on medium, then high, to confirm strong airflow.
• Switch between fresh air and recirculation to ensure no rattles from the glovebox area.
• If you notice a whistle, reopen the cover and confirm the filter is fully seated and facing the correct direction.

---

💰 DIY vs Shop Cost

Shop Cost: $80-$160 (parts + labor)

DIY Cost: $15-$45 (parts only)

You Save: $65-$115 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.3-0.6 hours.

---
