🔧 Camry - Cabin Air Filter Replacement

Your Camry’s cabin air filter cleans the air going through the heater and A/C. When it gets dirty, airflow can drop and you may notice musty smells or more dust inside the car.

Difficulty Level: Beginner | Estimated Time: 10-20 minutes

---

⚠️ Safety & Precautions

• ⚠️ Park on level ground and shift to P.
• ⚠️ Turn the car OFF and keep the key/fob away from the vehicle so it can’t “wake up” while your hands are inside the dash area.
• ⚠️ Do not force plastic tabs—if something won’t move, re-check the clip/tabs first.
• ⚠️ Battery disconnect is not required for this filter replacement.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Flashlight
• Plastic trim removal tool (non-marring)
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Cabin air filter - Qty: 1

---

📋 Before You Begin

• Park the Camry on a flat surface and make sure the ignition is OFF.
• Open the passenger door and clear items out of the glove box.
• Take a quick photo of the filter direction arrows.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Open and empty the glove box

• Open the glove box fully and remove manuals/loose items by hand.
• Use a flashlight so you can see the right-side glove box arm clearly.

Step 2: Disconnect the glove box damper arm

• On the right side of the glove box, find the small “damper” arm (a little slow-down strut that keeps the glove box from dropping fast).
• Use a plastic trim removal tool (non-marring) to gently pry the damper arm off its pin (or unhook it by hand if it releases easily).

Step 3: Drop the glove box down

• Push the glove box sides inward with your hands to clear the stop tabs.
• Let the glove box swing downward slowly once the stops clear.

Step 4: Remove the cabin filter cover

• Behind the glove box you’ll see the cabin filter housing.
• Use your hand (or a plastic trim removal tool (non-marring) if needed) to press the cover tabs and pull the cover straight off.

Step 5: Slide out the filter tray and old filter

• Pull the filter tray straight out by hand.
• Remove the old cabin filter from the tray by hand.
• If leaves fall out, that’s normal.

Step 6: Install the new cabin air filter (correct direction)

• Check the airflow arrow on the new filter (often marked “AIR FLOW”).
• Install the filter in the tray in the same direction as the old one (typical is arrow pointing down, but follow the arrow and housing markings).
• Slide the tray back into the housing by hand until fully seated.

Step 7: Reinstall the housing cover

• Align the cover and push it on by hand until the tabs click into place.
• If it won’t click, pull it back off and re-align—don’t force it.

Step 8: Reinstall the glove box

• Lift the glove box back up.
• Push the glove box sides inward again to pass the stop tabs, then release.
• Reconnect the right-side damper arm by hand (it should snap back onto the pin).

---

✅ After Repair

• Start the Camry and run the blower on medium-high for 30 seconds.
• Check for normal airflow and make sure there are no rattles from the glove box area.
• If there’s a whistle, the filter may be flipped.

---

💰 DIY vs Shop Cost

Shop Cost: $80-$160 (parts + labor)

DIY Cost: $15-$40 (parts only)

You Save: $40-$140 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.3-0.5 hours.

---
