🔧 Focus - Cabin Air Filter Replacement

Your Focus cabin air filter cleans the air coming through the heater/AC vents. When it’s dirty, you may notice weak airflow, musty smells, or more dust inside the car.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

Assumption: cabin filter access is behind the glove box.

---

⚠️ Safety & Precautions

• ⚠️ Turn the ignition off and remove the key before working under the dash.
• ⚠️ Use safety glasses—dust and debris can fall when you remove the filter.
• ⚠️ Do not force plastic tabs; they can crack in cold weather.
• ⚠️ Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 7mm socket
• 1/4" drive ratchet
• 1/4" drive extension (3"-6")
• Trim removal tool
• Flashlight
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Cabin air filter - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Turn the HVAC system off.
• Move the passenger seat back to give yourself room to work.
• Have a trash bag ready—the old filter can be very dusty.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Clear out the glove box area

• Open the glove box and remove anything inside so nothing falls out.
• Use a flashlight to look for the glove box “dampener” arm (a small slow-down strap/arm on the side).

Step 2: Lower the glove box

• If equipped, unclip the glove box dampener arm by hand (it usually pops off a small pin).
• Push in on both sides of the glove box (with your hands) to flex the stops past the dash opening, then let the glove box swing downward.
• Go slow—plastic tabs break when forced.

Step 3: Remove any trim panel blocking access

• If a side trim panel is in the way, use a trim removal tool to gently pry it off.
• If there are small screws holding a lower panel, remove them with a 7mm socket, 1/4" ratchet, and extension.
• For any 7mm screws you remove and reinstall: Torque to 2 Nm (18 in-lbs).

Step 4: Remove the cabin filter access cover

• Behind the lowered glove box, locate the cabin filter housing cover (a small rectangular cover with tabs).
• Press the tabs and pull the cover off by hand. If it’s tight, use the trim removal tool gently—don’t gouge the plastic.

Step 5: Remove the old cabin air filter

• Slide the old filter straight out.
• Pay attention to the airflow direction arrow printed on the filter frame (this must match when installing the new one).
• Keep the dirty side facing up as you pull it out to reduce debris dropping.

Step 6: Install the new cabin air filter

• Compare the new filter to the old one for the same shape and size.
• Slide the new filter into the housing with the airflow arrow pointing the same direction as the old filter came out.
• Make sure the filter seats fully and isn’t folded or pinched.

Step 7: Reinstall the cover and glove box

• Reinstall the filter housing cover by hand until it clicks into place.
• Lift the glove box back up and push the sides in again so the stops go back into position.
• Reconnect the dampener arm (if equipped) by pressing it back onto its pin.
• If you removed any 7mm screws: install them with a 7mm socket and 1/4" ratchet, then Torque to 2 Nm (18 in-lbs).

---

✅ After Repair

• Start the car and turn the fan to medium/high. Confirm airflow feels stronger and there are no rattles.
• Switch between fresh air and recirculate to confirm the glove box area stays quiet and nothing is rubbing.
• If you still smell musty odor, run the fan on fresh air for a few minutes to clear old dust from the ducts.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$170 (parts + labor)

DIY Cost: $15-$35 (parts only)

You Save: $55-$155 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
