🔧 Battery - Replacement

Your RAV4 uses a 12-volt battery under the hood. Replacing it means removing the hold-down, swapping the battery, and reconnecting everything in the correct order so the vehicle powers up normally. This is a straightforward job, but you need to be careful around the battery terminals and memory settings.

Difficulty Level: Beginner | Estimated Time: 0.5-1 hour

---

⚠️ Safety & Precautions

• Turn the ignition off and remove the key/fob from the vehicle.
• Wear safety glasses and gloves. Battery acid can burn skin and eyes.
• Do not let a wrench touch both battery terminals at once. That can cause a short circuit.
• Keep sparks, cigarettes, and open flames away from the battery.
• If your battery has a vent tube, transfer it to the new battery.
• Battery disconnect may erase radio presets and clock settings.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm wrench
• 12mm socket
• Ratchet
• Extension bar
• Battery terminal puller (specialty)
• Gloves
• Safety glasses
• Battery strap or lifting handle
• Memory saver (optional)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V battery - Qty: 1
• Battery terminal protector spray - Qty: 1
• Battery hold-down hardware - Qty: 1, if damaged

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Make sure all lights, accessories, and the ignition are off.
• If you use a memory saver, connect it before disconnecting the battery.
• Open the hood and locate the battery on the left side of the engine bay.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Access the battery

• Open the hood and secure it.
• Remove any plastic cover over the battery, if equipped.

Step 2: Disconnect the negative cable

• Use the 10mm wrench to loosen the negative battery terminal clamp.
• Lift the cable off the battery post and tuck it aside so it cannot spring back.

Step 3: Disconnect the positive cable

• Use the 10mm wrench to loosen the positive terminal clamp.
• Remove the cable and keep it clear of metal parts.

Step 4: Remove the battery hold-down

• Use the 12mm socket, ratchet, and extension bar to remove the battery hold-down bracket.
• Lift the bracket out and keep the hardware together.

Step 5: Remove the old battery

• Lift the battery straight up using a battery strap or lifting handle.
• Battery is heavy. Lift with both hands.

Step 6: Install the new battery

• Set the new battery in the tray the same way the old one sat.
• Make sure the positive and negative posts are in the same orientation as before.

Step 7: Reinstall the hold-down

• Install the hold-down bracket with the 12mm socket and ratchet.
• Torque to 18 Nm (13 ft-lbs).

Step 8: Connect the positive cable

• Use the 10mm wrench to install the positive terminal clamp first.
• Torque to 5 Nm (44 in-lbs).
• Make sure it is fully seated and cannot twist by hand.

Step 9: Connect the negative cable

• Use the 10mm wrench to install the negative terminal clamp last.
• Torque to 5 Nm (44 in-lbs).

Step 10: Finish up

• Reinstall any battery cover or trim removed earlier.
• Close the hood.

---

✅ After Repair

• Start the engine and make sure it cranks normally.
• Check that the battery warning light is off.
• Reset the clock and radio presets if needed.
• Check that the terminals are tight after the first drive.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$380 (parts + labor)

DIY Cost: $140-$240 (parts only)

You Save: $80-$140 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1 hour.

---
