🔧 Grand Cherokee - Battery Replacement

Your Grand Cherokee’s main battery is located under the front passenger seat (not under the hood like many cars). Replacing it is mostly careful trim removal and correct “disconnect/reconnect” order so you don’t damage electronics.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Keep the key fob at least 20 feet away so modules go to sleep.
• ⚠️ Do not short the battery with tools; remove metal jewelry.
• ⚠️ The negative cable may have an IBS sensor (a current sensor on the negative terminal). Don’t pry on or twist the sensor.
• ⚠️ Battery gases are flammable; no sparks or smoking.
• ⚠️ Battery disconnect is required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 13mm socket
• 1/4" ratchet
• 3/8" ratchet
• 6" extension
• Trim removal tool
• Torque wrench (inch-pound)
• Torque wrench (foot-pound)
• Battery terminal cleaning brush
• Work light
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Main battery (correct-fit, same type as removed) - Qty: 1
• Battery terminal anti-corrosion pads - Qty: 2
• Battery terminal protectant spray - Qty: 1
• Auxiliary battery (if equipped with ESS) - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and turn everything off.
• Open the tailgate or a door you can leave open; once the battery is disconnected, power locks may not work.
• Wait 5–10 minutes after ignition OFF so computers go to sleep.
• Quick check: Does your Grand Cherokee have Auto Start/Stop (ESS) on the dash? If yes, it may also have an auxiliary battery and you may need to replace/inspect both.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Move the passenger seat for access

• Turn ignition ON and use the seat switch to move the passenger seat all the way back and up for working room.
• Turn ignition OFF and keep the key fob away from the vehicle.

Step 2: Remove the battery access trim and cover

• Use a trim removal tool to carefully pop off the plastic trim pieces at the front edge/side of the passenger seat base (they are clipped in).
• Remove the battery cover/retainer as equipped using a 10mm socket or 13mm socket (fastener size varies by cover style).
• Tip: Pull straight on clips to avoid breaking them.

Step 3: Disconnect the battery (negative first)

• Use a 10mm socket to loosen the negative (-) terminal clamp nut and remove the cable from the battery post.
• Position the removed negative cable so it cannot spring back and touch the terminal.
• Use a 10mm socket to loosen the positive (+) terminal clamp nut and remove the cable from the battery post.
• Torque (reinstall later): Torque to 5 Nm (44 in-lbs) for terminal clamp nuts.

Step 4: Remove the battery hold-down

• Use a 13mm socket, 3/8" ratchet, and 6" extension to remove the battery hold-down bolt/bracket at the base of the battery.
• Torque (reinstall later): Torque to 10 Nm (89 in-lbs) for the hold-down bolt.

Step 5: Remove the old battery

• Lift the battery straight up and out carefully. It is heavy; use mechanic gloves for grip.
• If corrosion is present, use a battery terminal cleaning brush to clean the inside of the cable clamps.

Step 6: Install the new battery

• Set the new battery in the tray in the same orientation as the old one.
• Reinstall the hold-down bracket using the 13mm socket and 3/8" ratchet.
• Torque to 10 Nm (89 in-lbs) using a torque wrench (foot-pound).

Step 7: Reconnect the cables (positive first)

• Install the positive (+) cable first and tighten using a 10mm socket.
• Install the negative (-) cable last and tighten using a 10mm socket.
• Torque to 5 Nm (44 in-lbs) using a torque wrench (inch-pound).
• Install battery terminal anti-corrosion pads and apply battery terminal protectant spray.

Step 8: Reinstall the cover and trim

• Reinstall the battery cover/retainer using the 10mm socket or 13mm socket (whichever you removed).
• Press the seat-base trim panels back into place by hand until all clips seat fully.

Step 9 (If equipped): Auxiliary battery / ESS check

• If your Grand Cherokee has Auto Start/Stop (ESS), a weak auxiliary battery can cause warning messages even after replacing the main battery.
• If ESS warnings remain, the auxiliary battery and its connections should be tested and likely replaced as well (location and access vary by equipment).

---

✅ After Repair

• Start the engine and confirm normal cranking and no warning lights.
• Check that the battery cables are tight by gently trying to rotate each clamp by hand (it should not move).
• Reset items as needed: clock, radio presets, and one-touch window operation (if it lost memory).
• If a battery/charging warning remains, the charging system and battery sensor wiring should be scanned for codes.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $180-$320 (parts only)

You Save: $70-$130 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
