🔋 Battery - Replacement

Your Rogue uses a 12V under-hood battery, so this is a straightforward replacement. The main goals are to keep power loss controlled, remove the old battery safely, and install the new one with the terminals secured correctly.

Difficulty Level: Beginner | Estimated Time: 0.5-1 hours

---

⚠️ Safety & Precautions

• Turn the ignition off and remove the key/fob before starting.
• Wear safety glasses and gloves. Battery acid and corrosion can irritate skin and eyes.
• Do not let a wrench touch both battery terminals or a terminal and body metal at the same time.
• Disconnect the negative terminal first, then the positive terminal.
• Reconnect the positive terminal first, then the negative terminal.
• Keep metal tools away from the battery posts once one cable is removed.
• If the battery has a vent tube, transfer it to the new battery.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• Ratchet
• 6-inch extension
• Battery terminal puller (specialty)
• Battery carrier strap
• Memory saver (optional)
• Safety glasses
• Mechanic gloves
• Wire brush
• Shop rag

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V battery - Qty: 1
• Battery terminal protector spray - Qty: 1
• Battery terminal cleaning brush - Qty: 1
• Battery hold-down hardware - Qty: 1 if damaged or corroded

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Make sure the ignition is off and all accessories are off.
• If you want to keep radio and clock memory, connect a memory saver before disconnecting the battery.
• Take a photo of the cable layout first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Open the battery area

• Open the hood and locate the battery on the driver side of the engine bay.
• Clear any covers or loose items around the battery so you have room to work.

Step 2: Disconnect the negative cable

• Use a 10mm socket and ratchet to loosen the negative terminal clamp.
• Lift the negative cable off the battery post and move it aside so it cannot spring back.
• Negative first prevents shorts.

Step 3: Disconnect the positive cable

• Use a 10mm socket to loosen the positive terminal clamp.
• Remove the positive cable from the battery post and keep it clear of metal.

Step 4: Remove the battery hold-down

• Use a 10mm socket, ratchet, and 6-inch extension to remove the battery hold-down hardware.
• Lift off the hold-down bracket and set the fasteners aside.

Step 5: Lift out the old battery

• Use a battery carrier strap if needed and lift the battery straight up and out.
• Batteries are heavy. Keep your back straight and use both hands.

Step 6: Clean the battery tray and terminals

• Use a wire brush and shop rag to clean corrosion from the tray, clamps, and cable ends.
• Remove loose dirt and white or blue corrosion before installing the new battery.

Step 7: Install the new battery

• Lower the new battery into the tray in the same orientation as the old one.
• Make sure the positive and negative posts are on the correct sides and the battery sits flat.
• If equipped, reconnect the vent tube.

Step 8: Reinstall the hold-down

• Install the hold-down bracket and tighten it with a 10mm socket and ratchet.
• Torque to 8-10 Nm (71-89 in-lbs).
• Snug is enough.

Step 9: Reconnect the positive cable

• Place the positive cable on the positive post.
• Use a 10mm socket to tighten the clamp.
• Torque to 5-7 Nm (44-62 in-lbs).

Step 10: Reconnect the negative cable

• Place the negative cable on the negative post.
• Use a 10mm socket to tighten the clamp.
• Torque to 5-7 Nm (44-62 in-lbs).

Step 11: Finish up

• Apply battery terminal protector spray to the terminal tops if desired.
• Close the hood and make sure the battery is secure.

---

✅ After Repair

• Start the engine and confirm it cranks normally.
• Check that the dash lights are off after startup.
• Reset the clock, radio presets, and any saved settings if needed.
• Drive for a few minutes and recheck that the battery clamps stay tight.

---

💰 DIY vs Shop Cost

Shop Cost: $200-$350 (parts + labor)

DIY Cost: $130-$220 (parts only)

You Save: $70-$130 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1 hours.

---
