🔧 Battery Replacement - Battery Change

Your battery is mounted under the hood, so this is a straightforward replacement. The key is to save memory settings if needed, disconnect the cables in the correct order, and secure the new battery so it cannot move.

Difficulty Level: Beginner | Estimated Time: 0.5-1 hour

---

⚠️ Safety & Precautions

• Wear safety glasses and gloves. Battery acid can burn skin and eyes.
• Turn the ignition OFF, remove the key, and keep it away from the truck.
• Do not let a wrench touch both battery terminals at once.
• Use a memory saver if you want to keep radio and clock settings.
• Battery is heavy. Lift with both hands.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm wrench
• 13mm socket
• Ratchet
• Battery terminal puller (specialty)
• Battery brush
• Memory saver
• Safety glasses
• Gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V battery - Qty: 1
• Battery terminal protectant - Qty: 1
• Battery hold-down hardware - Qty: 1 set

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Turn all lights and accessories OFF.
• If using a memory saver, connect it before disconnecting the battery.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Open the battery area

• Open the hood and locate the battery on the front left side of the engine bay.
• Check for any cover or shield and remove it by hand if equipped.

Step 2: Disconnect the negative cable

• Use a 10mm wrench to loosen the negative cable clamp.
• Remove the negative cable and move it aside so it cannot touch the terminal.
• Always disconnect negative first.

Step 3: Disconnect the positive cable

• Use a 10mm wrench to loosen the positive cable clamp.
• Remove the positive cable and keep it away from metal parts.

Step 4: Remove the battery hold-down

• Use a 13mm socket and ratchet to remove the battery hold-down fastener.
• Lift the hold-down bracket out and keep the hardware together.

Step 5: Remove the old battery

• Lift the battery straight up and out of the tray.
• Use both hands. It is heavy.
• Inspect the tray for corrosion, dirt, or acid residue.

Step 6: Clean and prep the tray

• Use a battery brush to clean the cable ends if they are corroded.
• Wipe the tray clean and make sure the new battery will sit flat.
• Clean terminals help the new battery last longer.

Step 7: Install the new battery

• Set the new battery in the tray with the terminals in the same position as the old one.
• Reinstall the hold-down bracket.
• Use a 13mm socket to tighten the hold-down fastener.
• Torque to 13 Nm (115 ft-lbs).

Step 8: Reconnect the positive cable

• Install the positive cable first.
• Use a 10mm wrench to tighten the clamp.
• Torque to snug, do not over-tighten.

Step 9: Reconnect the negative cable

• Install the negative cable last.
• Use a 10mm wrench to tighten the clamp.
• Torque to snug, do not over-tighten.

Step 10: Final check

• Make sure both terminals are tight and the battery cannot move.
• Reinstall any cover you removed.
• Close the hood.

---

✅ After Repair

• Start the engine and confirm it cranks normally.
• Check for warning lights on the dash.
• Reset the clock and radio presets if needed.
• If you used a memory saver, verify all stored settings worked correctly.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$380 (parts + labor)

DIY Cost: $150-$250 (parts only)

You Save: $70-$130 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1 hour.

---
