🔧 Tucson - Battery Replacement

Replacing the battery on your Tucson is a beginner-friendly job. The battery sits in the engine bay, and the main goal is to disconnect it safely, remove the hold-down, install the new battery, and make sure the terminals are clean and tight.

Difficulty Level: Beginner | Estimated Time: 20-40 minutes

---

⚠️ Safety & Precautions

• ⚠️ Always remove the negative battery cable first to reduce the chance of sparks.
• ⚠️ Keep metal tools away from both battery posts at the same time.
• ⚠️ Batteries are heavy and contain acid, so wear gloves and safety glasses.
• ⚠️ Do not smoke or create sparks near the battery.
• ⚠️ Battery disconnect is required for this repair.
• ⚠️ Your Tucson may lose clock, radio presets, and some learned idle settings after disconnecting the battery.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm wrench
• 10mm socket
• 12mm socket
• 3/8-inch ratchet
• 6-inch extension
• Battery terminal cleaner brush
• Battery carrying strap (specialty)
• Torque wrench, inch-pound range
• Memory saver 12V OBD-II device (optional specialty)
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V starting battery, Group 124R / H7, AGM or flooded lead-acid as equipped - Qty: 1
• Battery terminal anti-corrosion protectant - Qty: 1
• Battery terminal felt washers - Qty: 2

---

📋 Before You Begin

• Park your Tucson on level ground and shift to Park.
• Set the parking brake and turn the ignition fully off.
• Remove the key from the vehicle and keep it away from the ignition area.
• Open the hood and let the engine bay cool if the vehicle was recently driven.
• If using a memory saver, plug the memory saver 12V OBD-II device into the OBD-II port before disconnecting the battery. A memory saver helps keep radio presets and learned settings during battery replacement.
• Take a quick photo of the old battery position so the new one goes in the same way.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Open the Hood and Locate the Battery

• Use the interior hood release, then lift the hood and secure it with the hood prop rod.
• The battery is in the engine bay near the front corner on the driver-side area.
• Put on safety glasses and nitrile gloves before touching the battery.
• Take a photo before removing anything.

Step 2: Identify the Negative and Positive Terminals

• Look for the negative terminal marked -, usually with a black cable.
• Look for the positive terminal marked +, usually with a red cover or red cable.
• A terminal is the metal clamp attached to the battery post.

Step 3: Disconnect the Negative Cable First

• Use a 10mm wrench or 10mm socket to loosen the nut on the negative battery terminal clamp.
• Twist the clamp gently by hand and lift it off the negative battery post.
• Move the negative cable aside so it cannot spring back and touch the battery post.
• Do not let your tool touch the positive terminal while loosening the negative cable.

Step 4: Disconnect the Positive Cable

• Lift the red positive terminal cover if equipped.
• Use a 10mm wrench or 10mm socket to loosen the nut on the positive battery terminal clamp.
• Twist the clamp gently by hand and lift it off the positive battery post.
• Move the positive cable aside carefully.

Step 5: Remove the Battery Hold-Down Bracket

• The hold-down bracket keeps the battery from moving while driving.
• Use a 12mm socket, 3/8-inch ratchet, and 6-inch extension to remove the battery hold-down bolt.
• Remove the hold-down bracket and set it aside where it will not be lost.
• Keep the bolt and bracket together.

Step 6: Remove the Old Battery

• Attach a battery carrying strap if the battery does not have a handle.
• Lift the battery straight up and out using both hands.
• Keep the battery upright at all times.
• Set it on the ground gently, away from children, pets, flames, and sparks.

Step 7: Clean the Battery Tray and Cable Ends

• Inspect the battery tray for dirt, corrosion, or loose hardware.
• Use a battery terminal cleaner brush to clean the inside of both cable clamps.
• If you see white or green crust, brush it off gently while wearing safety glasses and nitrile gloves.
• Do not breathe battery corrosion dust.

Step 8: Install the New Battery

• Place the new 12V starting battery into the tray in the same direction as the old battery.
• Make sure the positive post lines up with the positive cable and the negative post lines up with the negative cable.
• Do not force the cables to reach. If they do not line up, the battery is turned the wrong way or is the wrong case layout.

Step 9: Reinstall the Battery Hold-Down

• Install the hold-down bracket over the battery base.
• Use a 12mm socket, 3/8-inch ratchet, and 6-inch extension to tighten the hold-down bolt.
• Torque to 8-10 Nm (71-89 in-lbs).
• The battery should not slide or rock by hand after tightening.

Step 10: Connect the Positive Cable First

• Place one battery terminal felt washer over the positive battery post if using felt washers.
• Push the positive cable clamp fully down onto the positive battery post.
• Use a 10mm wrench or 10mm socket to tighten the clamp nut.
• Torque to 4-6 Nm (35-53 in-lbs).
• Close the red positive terminal cover if equipped.

Step 11: Connect the Negative Cable Last

• Place one battery terminal felt washer over the negative battery post if using felt washers.
• Push the negative cable clamp fully down onto the negative battery post.
• Use a 10mm wrench or 10mm socket to tighten the clamp nut.
• Torque to 4-6 Nm (35-53 in-lbs).
• You may see a tiny spark when connecting the negative cable. That can be normal if small electronics wake up.

Step 12: Protect the Terminals

• Use battery terminal anti-corrosion protectant on both terminal connections.
• Apply only a light coating after the clamps are tightened.
• Do not put grease or protectant between the clamp and battery post before tightening.

Step 13: Final Check

• Use your hand to gently wiggle each cable clamp. They should not rotate or lift off.
• Use your hand to gently push the battery. It should stay firmly in place.
• Remove all tools from the engine bay before starting your Tucson.

---

✅ After Repair

• Start your Tucson and let it idle for 2-3 minutes.
• Check that the battery warning light turns off after the engine starts.
• Reset the clock and radio presets if needed.
• If the idle feels slightly rough at first, let the engine idle with all accessories off for a few minutes so the computer can relearn.
• Turn the steering wheel left and right once while parked if any stability/steering warning appears after battery disconnect.
• Recycle the old battery at a parts store, battery retailer, or recycling center. Do not throw it in household trash.

---

💰 DIY vs Shop Cost

Shop Cost: $230-$390 USD equivalent (parts + labor)

DIY Cost: $150-$260 USD equivalent (parts only)

You Save: $80-$130 USD equivalent by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.3-0.6 hours.

---
