🔧 Wrangler - Battery Replacement

You’ll remove the old 12V battery and install a new one, then reconnect the cables in the correct order. The key is preventing sparks and keeping the battery secured so it can’t move while driving.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Keep keys out of the ignition and all accessories OFF.
• ⚠️ Remove the negative (–) cable first and install it last to reduce short-circuit risk.
• ⚠️ Do not let a tool touch the battery positive (+) terminal and any metal body part at the same time.
• ⚠️ Batteries are heavy and can leak acid—wear gloves and eye protection.
• ⚠️ No smoking/open flames near the battery.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 13mm socket
• 3/8" drive ratchet
• 6" socket extension (3/8" drive)
• Torque wrench (inch-pound)
• Battery terminal brush
• Shop rags
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V starting battery (correct fitment for your Wrangler) - Qty: 1
• Battery terminal anti-corrosion pads - Qty: 2
• Battery terminal protectant spray - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to neutral, and set the parking brake.
• Open the hood and let the engine bay cool if it’s hot.
• Note: disconnecting the battery may reset the clock and radio presets.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the battery

• Open the hood and find the battery on the right side of the engine bay.
• Identify terminals: negative (–) usually has a black cable; positive (+) usually has a red cable.

Step 2: Disconnect the negative (–) cable

• Use a 10mm socket with a 3/8" ratchet to loosen the negative terminal clamp nut.
• Wiggle and lift the clamp straight up off the post.
• Move the cable aside so it can’t spring back onto the battery. Keep it away from the post.

Step 3: Disconnect the positive (+) cable

• Use a 10mm socket to loosen the positive terminal clamp nut.
• Remove the positive clamp and position it so it can’t touch metal.

Step 4: Remove the battery hold-down

• At the base of the battery, remove the hold-down bolt using a 13mm socket, 6" extension, and 3/8" ratchet.
• Lift off the hold-down bracket and set it aside.

Step 5: Remove the old battery

• Grab the battery by its handle (or sides) and lift it straight up and out.
• Place it on the ground upright. Do not tip it.

Step 6: Clean the tray and cable ends

• Use shop rags to wipe out debris from the battery tray.
• Use a battery terminal brush to clean the inside of each cable clamp until the metal looks bright.
• If there’s heavy corrosion, brush gently and wipe often. Clean metal makes a strong connection.

Step 7: Install the new battery

• Set the new battery into the tray in the same orientation as the old one (posts in the same positions).
• Reinstall the hold-down bracket using the 13mm socket, extension, and ratchet.
• Use a torque wrench (inch-pound) to tighten the hold-down bolt: Torque to 89 in-lb (10 Nm).

Step 8: Reconnect the positive (+) cable first

• Install an anti-corrosion pad on the positive post (if used).
• Push the positive clamp fully down on the post.
• Tighten the clamp nut with a 10mm socket, then finish with a torque wrench (inch-pound): Torque to 50 in-lb (5.6 Nm).
• Spray battery terminal protectant on the connection (light coat).

Step 9: Reconnect the negative (–) cable last

• Install an anti-corrosion pad on the negative post (if used).
• Push the negative clamp fully down on the post.
• Tighten with a 10mm socket, then torque with an inch-pound torque wrench: Torque to 50 in-lb (5.6 Nm).
• Spray battery terminal protectant on the connection (light coat).

Step 10: Quick final checks

• Try to rotate each terminal by hand—if it twists on the post, tighten slightly using a 10mm socket (do not over-tighten).
• Confirm the battery cannot move in the tray.
• Remove tools from the engine bay and close the hood.

---

✅ After Repair

• Start the engine and verify normal cranking.
• Check that the battery warning light is off.
• Reset the clock and radio presets if needed.
• Drive 10-15 minutes and recheck that the terminals are still tight.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $160-$300 (parts only)

You Save: $90-$150 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
