🔧 Kona - Alternator Replacement

Replacing the alternator on your Kona involves disconnecting the battery, removing the drive belt, unplugging the alternator wiring, and unbolting the alternator from its bracket. The main risk is shorting the charging cable or damaging the belt routing, so we’ll take it step-by-step.

Difficulty Level: Advanced | Estimated Time: 2.5-4.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the negative battery terminal first to prevent electrical shock/shorts.
• ⚠️ Let the engine cool fully; the turbo/engine bay gets very hot.
• ⚠️ Support the vehicle on jack stands; never rely on a floor jack alone.
• ⚠️ Do not pry on aluminum parts; they crack easily.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 10mm socket
• 12mm socket
• 14mm socket
• 17mm socket
• 3/8" ratchet
• 3/8" torque wrench
• 6" extension (3/8")
• 12" extension (3/8")
• Serpentine belt tool (specialty)
• Trim clip removal tool
• Flathead screwdriver
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Alternator - Qty: 1
• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Open the hood and record your radio presets if you want (battery will be disconnected).
• Disconnect the battery: use a 10mm socket to remove the negative terminal first, then secure it so it can’t spring back.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm two details (so I can give exact torque specs)

• Does your Kona have Auto Stop/Start (ISG) (the engine shuts off at stops)? Yes/No.
• Do you want me to provide exact bolt torque specs? If yes, tell me whether you have access to OEM torque specs (service manual), because Hyundai uses multiple alternator/bracket fasteners depending on build and option package.

Step 2: Raise the front and remove the lower cover

• Lift the front of the vehicle with a floor jack (rated 3-ton minimum) and set it on jack stands (rated 3-ton minimum).
• Remove the lower engine splash shield using a trim clip removal tool and 10mm socket (fasteners vary).
• Put fasteners in labeled cups.

Step 3: Relieve belt tension and remove the belt

• Locate the belt tensioner and use a serpentine belt tool (specialty) to rotate the tensioner and release belt tension.
• Slip the belt off the alternator pulley first, then remove it from the other pulleys.
• Use a flashlight and take a photo of belt routing before removal.

Step 4: Disconnect alternator electrical connections

• Unplug the alternator connector by releasing the lock tab with a flathead screwdriver (gentle pressure only).
• Remove the alternator B+ charging cable nut using a 12mm socket (size can vary), then move the cable aside.
• Keep the cable end from touching metal.

Step 5: Remove alternator mounting bolts

• Support the alternator with one hand.
• Remove the alternator mounting bolts using a 14mm socket, 3/8" ratchet, and extensions as needed.
• Work the alternator out carefully; you may need to reposition wiring looms by hand (do not pull on wires).

Step 6: Install the new alternator

• Position the new alternator into place by hand and start all mounting bolts by hand to prevent cross-threading.
• Tighten mounting bolts evenly using a 14mm socket and 3/8" ratchet.
• Torque specs: I will provide the exact Torque to XX Nm (YY ft-lbs) values once you answer the two questions in Step 1.

Step 7: Reconnect wiring

• Reinstall the B+ cable and tighten the nut using a 12mm socket.
• Reconnect the alternator electrical connector until it clicks.
• Torque specs: I will provide the exact B+ nut torque once Step 1 is answered.

Step 8: Install the belt

• Route the belt according to your reference photo.
• Use the serpentine belt tool (specialty) to rotate the tensioner and slip the belt onto the last pulley.
• Visually confirm the belt ribs are fully seated in every pulley groove.

Step 9: Reinstall shields and reconnect battery

• Reinstall the lower splash shield using a 10mm socket and trim clip removal tool.
• Lower the vehicle from the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).
• Reconnect the battery terminals using a 10mm socket (positive first, negative last).

---

✅ After Repair

• Start the engine and confirm the battery/charging warning light turns off.
• Listen for belt squeal; if present, shut off and re-check belt seating.
• If you have a voltmeter, check charging voltage at the battery (engine running) to confirm alternator output.
• If Auto Stop/Start is equipped, confirm it still operates normally after a short drive.

---

💰 DIY vs Shop Cost

Shop Cost: $650-$1,050 (parts + labor)

DIY Cost: $220-$520 (parts only)

You Save: $430-$530 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.5-4.0 hours.

---
