🔧 Renegade - Alternator Replacement

The alternator charges your battery and powers the vehicle while the engine runs. On your Renegade, access is tight, so you’ll usually remove the right-front wheel and inner splash shield to reach the belt and alternator safely.

Difficulty Level: Advanced | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the battery negative cable before touching the alternator wiring (prevents a dead short).
• ⚠️ Never work under a vehicle supported only by a jack—use jack stands.
• ⚠️ Keep fingers and tools away from the serpentine belt path.
• ⚠️ Let the engine cool; the turbo/exhaust area can burn you.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 21mm socket
• 3/8" drive ratchet
• 1/2" drive breaker bar
• 3/8" drive torque wrench
• 1/2" drive torque wrench
• 10mm socket
• 13mm socket
• 15mm socket
• E12 external Torx socket
• E14 external Torx socket
• Flat-blade trim tool
• Flat-blade screwdriver
• Needle-nose pliers
• Serpentine belt tool (specialty)
• Work light

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Alternator - Qty: 1
• Serpentine belt - Qty: 1 Replace if cracked or glazed
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Open the hood and keep the key fob away from the vehicle.
• Disconnect the battery negative terminal using a 10mm socket. Wrap the cable so it can’t touch
• Take a quick photo or draw the belt routing before removing the serpentine belt.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and secure the right-front corner

• Use a floor jack (rated 2-ton minimum) to lift the right-front jack point.
• Set the vehicle onto jack stands (rated 2-ton minimum) and verify it’s stable.
• Remove the right-front wheel using a 21mm socket and 1/2" drive breaker bar.
• Reinstall later and Torque to 135 Nm (100 ft-lbs).

Step 2: Remove the right-front inner splash shield

• Remove the plastic fasteners/screws using a flat-blade trim tool and flat-blade screwdriver.
• Pull the splash shield out to expose the serpentine belt and accessory drive area.

Step 3: Relieve serpentine belt tension

• Fit a 15mm socket on the belt tensioner bolt (or use a serpentine belt tool (specialty) for more room).
• Rotate the tensioner to release tension, then slip the belt off the alternator pulley.
• Slowly let the tensioner return to its resting position. Don’t let it snap back

Step 4: Disconnect alternator electrical connections

• Locate the alternator wiring connector and release the lock using a flat-blade screwdriver, then unplug it.
• Remove the rubber protective cap from the main power stud.
• Remove the B+ cable nut using a 13mm socket, then lift the cable off the stud.
• During reassembly: Torque the B+ nut to 13 Nm (115 in-lbs).
• Apply a small dab of dielectric grease to the connector seal before plugging back in.

Step 5: Unbolt and remove the alternator

• Support the alternator with one hand and remove the mounting bolts using either:

• Use a 15mm socket (hex-head bolt version), or
• Use an E12 external Torx socket / E14 external Torx socket (external Torx bolt version).

• Work the alternator out through the wheel-well opening. Rotate it slowly to clear hoses
• During reassembly: Torque alternator mounting bolts to 48 Nm (35 ft-lbs).

Step 6: Install the new alternator

• Set the new alternator into place and start all mounting bolts by hand to avoid cross-threading.
• Tighten mounting bolts using the same tool you removed them with.
• Torque alternator mounting bolts to 48 Nm (35 ft-lbs).

Step 7: Reconnect wiring

• Install the B+ cable onto the stud and tighten the nut using a 13mm socket.
• Torque the B+ nut to 13 Nm (115 in-lbs), then reinstall the protective cap.
• Plug in the alternator connector until it clicks.

Step 8: Reinstall the serpentine belt

• Route the belt according to your photo/diagram.
• Rotate the tensioner using a 15mm socket or serpentine belt tool (specialty), then slide the belt onto the alternator pulley.
• Double-check the belt ribs are fully seated in every pulley groove. Misalignment shreds belts fast

Step 9: Reinstall splash shield and wheel

• Reinstall the inner splash shield fasteners using a flat-blade trim tool and flat-blade screwdriver.
• Reinstall the wheel using a 21mm socket.
• Lower the vehicle, then Torque lug nuts to 135 Nm (100 ft-lbs) using a 1/2" drive torque wrench.

Step 10: Reconnect the battery

• Reconnect the negative battery terminal using a 10mm socket.
• Torque to 6 Nm (53 in-lbs).

---

✅ After Repair

• Start the engine and confirm the battery/charging warning light is off.
• Listen for belt squeal or slapping; shut off and recheck belt seating if you hear noise.
• If you have a scan tool, clear any stored charging-system codes and recheck for returns.
• Check charging voltage at the battery with a meter: typically ~13.5–14.8V with the engine running.

---

💰 DIY vs Shop Cost

Shop Cost: $650-$1,050 (parts + labor)

DIY Cost: $220-$520 (parts only)

You Save: $430-$530 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
