🔧 Focus - Alternator Replacement

The alternator charges your battery and powers the electrical system while the engine runs. On your Focus, the alternator is belt-driven and typically accessed from the passenger-side wheel well, so you’ll remove the wheel and splash shield to reach it.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable first to prevent short circuits at the alternator power stud.
• Support the car with jack stands; never work under a car supported only by a jack.
• Let the engine cool; you’ll be working near hot engine and exhaust components.
• Keep fingers clear of the belt and pulleys when releasing the tensioner.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Mechanic gloves
• 21mm socket
• 1/2" drive breaker bar
• 3/8" drive ratchet
• 3/8" drive torque wrench
• 6" socket extension (3/8" drive)
• 8mm socket
• 10mm socket
• 13mm socket
• 15mm socket
• T25 Torx bit
• Flat trim clip tool
• Small flathead screwdriver
• Multimeter
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Alternator - Qty: 1
• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park on level ground, put the transmission in 1st gear, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Open the hood and plan to disconnect the battery (negative cable first).
• Take a quick photo of belt routing.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect the battery

• Use a 10mm socket to loosen the negative battery terminal clamp and remove the cable from the battery.
• Move the cable aside so it can’t spring back to the post.

Step 2: Raise the passenger front and remove the wheel

• Use a 21mm socket and breaker bar to slightly loosen the lug nuts while the tire is still on the ground.
• Lift the passenger front with the floor jack and set the car securely on jack stands.
• Remove the lug nuts with the 21mm socket and remove the wheel.
• During reassembly: Torque lug nuts to 135 Nm (100 ft-lbs).

Step 3: Remove the passenger-side splash shield (inner fender)

• Use the T25 Torx bit and 8mm socket (fasteners vary) to remove screws/bolts from the splash shield.
• Use a flat trim clip tool to pop out any plastic push-clips.
• Pull the splash shield back to expose the belt, tensioner, and alternator area.

Step 4: Release belt tension and remove the belt from the alternator

• Use a 15mm socket and 3/8" drive ratchet to rotate the belt tensioner and relieve tension. (The tensioner is a spring-loaded arm that keeps the belt tight.)
• While holding the tensioner rotated, slip the belt off the alternator pulley.
• Slowly release the tensioner back into place.

Step 5: Disconnect alternator wiring

• Unplug the alternator electrical connector by pressing the tab (use a small flathead screwdriver gently if it’s stuck).
• Remove the protective cap over the alternator power stud.
• Use a 10mm socket to remove the B+ cable nut, then lift the cable off the stud.
• During reassembly: Torque B+ terminal nut to 10 Nm (89 in-lbs).

Step 6: Remove the alternator mounting bolts

• Support the alternator with one hand.
• Use a 13mm socket, ratchet, and extension to remove the alternator mounting bolts.
• Note the bolt locations and any brackets/spacers so they go back the same way.

Step 7: Remove the alternator from the wheel well area

• Work the alternator out through the opening near the wheel well. Rotate it as needed to clear hoses and brackets.
• Go slow—don’t force it past wiring.

Step 8: Install the new alternator

• Position the new alternator into place the same way the old one came out.
• Hand-thread the mounting bolts first to avoid cross-threading.
• Use a 13mm socket and torque wrench to tighten the alternator mounting bolts: Torque to 35 Nm (26 ft-lbs).

Step 9: Reconnect wiring to the alternator

• Install the main power cable onto the stud and tighten with a 10mm socket: Torque to 10 Nm (89 in-lbs).
• Reinstall the protective cap over the power stud.
• Plug in the alternator electrical connector until it clicks.

Step 10: Reinstall/route the serpentine belt

• If installing a new belt, match its length to the old belt before installing.
• Route the belt around all pulleys except the alternator pulley (use your photo as a guide).
• Use a 15mm socket and ratchet to rotate the tensioner again, slip the belt onto the alternator pulley, then slowly release the tensioner.
• Visually confirm the belt is fully seated in every pulley groove.

Step 11: Reinstall the splash shield and wheel

• Reposition the splash shield and reinstall fasteners using the T25 Torx bit and 8mm socket.
• Reinstall the wheel and hand-thread lug nuts.
• Lower the car off the jack stands using the floor jack.
• Use a torque wrench and 21mm socket: Torque lug nuts to 135 Nm (100 ft-lbs).

Step 12: Reconnect the battery

• Reconnect the negative terminal and tighten with a 10mm socket.

---

✅ After Repair

• Start the engine and listen for belt squeal or slapping; shut it off and re-check belt seating if you hear noise.
• Use a multimeter at the battery terminals with the engine idling: a healthy charging voltage is typically about 13.5V to 14.7V.
• Turn on headlights and blower motor; confirm voltage stays steady and the battery light stays off.
• Recheck for any loose wiring near the belt path.

---
