🔧 Alternator - Replacement

The alternator charges the battery and powers the electrical system while the engine runs. On your Sequoia, replacement means removing the drive belt, disconnecting the battery, swapping the alternator, and reinstalling everything with the belt routed correctly.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable first. The alternator has constant battery power and can short if touched with a tool.
• Let the engine cool fully before starting. The belt area can be hot.
• Keep fingers, clothing, and jewelry away from the serpentine belt and pulleys.
• Use jack stands if you need under-vehicle access. Never rely on a jack alone.
• Tip: Take a belt-routing photo before removal.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm wrench
• 12mm socket
• 14mm socket
• 3/8-inch drive ratchet
• 3/8-inch drive breaker bar
• Torque wrench
• Serpentine belt tool (specialty)
• Flat-blade screwdriver
• Trim clip tool
• Jack stands
• Floor jack (rated 3-ton minimum)
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Alternator - Qty: 1
• Serpentine belt - Qty: 1
• Alternator mounting bolt hardware - Qty: 1 set
• Battery terminal anti-corrosion washer - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and shut the engine off.
• Remove the key/fob from the vehicle so it cannot accidentally start.
• Disconnect the negative battery cable before touching the alternator.
• If the belt is cracked, glazed, or noisy, replace it now.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect the battery

• Use a 10mm wrench to loosen the negative battery terminal.
• Lift the cable off the battery and keep it away from the post.

Step 2: Remove the engine cover and intake parts

• Use your hands and a flat-blade screwdriver to remove the engine cover and any intake ducting blocking access to the front of the engine.
• Set the parts aside in order so they go back the same way.

Step 3: Release the serpentine belt

• Use the serpentine belt tool (specialty) or a 3/8-inch drive breaker bar on the belt tensioner.
• Rotate the tensioner to unload the belt, then slide the belt off the alternator pulley.
• Slowly let the tensioner return.

Step 4: Remove the alternator electrical connections

• Use a 10mm wrench to remove the main B+ cable nut from the alternator.
• Remove the protective cap, then move the cable aside.
• Unplug the alternator connector by pressing the lock tab and pulling straight off.

Step 5: Remove the alternator mounting bolts

• Use a 12mm socket and 14mm socket with a ratchet to remove the alternator mounting bolts.
• Support the alternator with one hand while removing the last bolt.
• Torque on install: alternator mounting bolts to 39 Nm (29 ft-lbs).

Step 6: Remove the alternator

• Work the alternator out of the engine bay carefully.
• If it sticks, wiggle it gently rather than forcing it against hoses or wiring.

Step 7: Install the new alternator

• Set the new alternator in place and start all mounting bolts by hand.
• Use the 12mm socket and 14mm socket to snug the bolts evenly.
• Torque to 39 Nm (29 ft-lbs).

Step 8: Reconnect the wiring

• Reconnect the alternator connector until it clicks.
• Install the B+ cable and tighten the nut with a 10mm wrench.
• Torque the terminal nut to 8.5 Nm (75 in-lbs).

Step 9: Reinstall the serpentine belt

• Route the belt over all pulleys exactly the same as before.
• Use the serpentine belt tool (specialty) or breaker bar to move the tensioner again.
• Slip the belt onto the alternator pulley last, then release the tensioner slowly.
• Tip: Make sure every rib sits fully in each pulley groove.

Step 10: Reinstall intake parts and battery cable

• Reinstall the intake ducting and engine cover using your hands and the flat-blade screwdriver if clips are present.
• Reconnect the negative battery cable with the 10mm wrench and tighten securely.

---

✅ After Repair

• Start the engine and watch the belt to confirm it runs straight and true.
• Check for battery or charging warning lights.
• Verify charging voltage if you have a meter. You want a normal charging reading with the engine running.
• Listen for belt squeal, pulley noise, or electrical smells.

---

💰 DIY vs Shop Cost

Shop Cost: $700-$1,200 (parts + labor)

DIY Cost: $250-$500 (parts only)

You Save: $450-$700 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
