🔧 Grand Cherokee - A/C Compressor Replacement

You’ll be removing the A/C compressor, swapping any needed parts (like O-rings), and then having the system evacuated and recharged with the correct refrigerant and oil. This is a bigger job because the A/C system is pressurized and must be opened safely and legally.

Difficulty Level: Advanced | Estimated Time: 3–5 hours (mechanical work only)

---

⚠️ Safety & Precautions

• ⚠️ Never vent refrigerant to the atmosphere. It can cause frostbite, eye injury, and is illegal in most regions. The system must be evacuated with proper A/C recovery equipment at a shop.
• ⚠️ Always disconnect the negative battery cable before working near the serpentine belt and compressor.
• ⚠️ Allow the engine to cool fully before working in the engine bay to avoid burns.
• ⚠️ Support the Grand Cherokee on jack stands, never rely only on a jack.
• ⚠️ Wear safety glasses and mechanic gloves to protect from debris and sharp edges.
• ⚠️ Do not start the engine or run the A/C after compressor installation until the system has been properly vacuumed and recharged with the correct refrigerant and oil.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠️ Floor jack (rated 3-ton minimum)
• 🛠️ Jack stands (rated 3-ton minimum)
• 🛠️ Wheel chocks
• 🛠️ 10mm socket
• 🛠️ 13mm socket
• 🛠️ 15mm socket
• 🛠️ 3/8" drive ratchet
• 🛠️ 3/8" drive torque wrench
• 🛠️ Serpentine belt tool or long 1/2" drive breaker bar
• 🛠️ Assorted extension bars (3/8" drive)
• 🛠️ Flathead screwdriver (medium)
• 🛠️ Trim clip removal tool
• 🛠️ Pry bar (small)
• 🛠️ Pick tool set
• 🛠️ Line wrench set (metric)
• 🛠️ A/C manifold gauge set (specialty)
• 🛠️ Vacuum pump for A/C systems (specialty)
• 🛠️ Shop light or LED work light
• 🛠️ Safety glasses
• 🛠️ Mechanic gloves
• 🛠️ Drain pan
• 🛠️ Clean shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 A/C compressor (complete assembly) - Qty: 1
• 🔩 A/C compressor mounting bolt set - Qty: 1 (recommended)
• 🔩 A/C O-ring kit (for compressor connections) - Qty: 1
• 🔩 PAG refrigerant oil (correct spec for 2019 Grand Cherokee 5.7L) - Qty: per system spec
• 🔩 R-134a or R-1234yf refrigerant (as equipped) - Qty: per system spec
• 🔩 Serpentine drive belt - Qty: 1 (recommended if worn)
• 🔩 A/C system flush solvent - Qty: 1 (only if required by diagnosis)
• 🔩 Dielectric grease (for electrical connector seals) - Qty: 1
• 🔩 Brake cleaner or A/C-safe cleaner (for cleaning area) - Qty: 1
• 🔩 Nitrile gloves - Qty: 1 box

---

📋 Before You Begin

• Park the Grand Cherokee on level ground, shift to Park, and apply the parking brake.
• Have a licensed A/C shop recover all refrigerant from the system before you disconnect any A/C lines. They can recharge it later.
• Open the hood and let the engine cool completely.
• Disconnect the negative battery terminal using a 10mm socket and set it aside so it cannot spring back.
• Review the belt routing diagram under the hood or take a clear photo before removing the serpentine belt.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Safely raise and secure the vehicle (if needed)

• Place wheel chocks behind the rear wheels.
• Use the floor jack (3-ton) to lift the front of the Grand Cherokee at the approved lift points.
• Set the vehicle down onto jack stands (3-ton) under the frame or designated support points.
• Only work under a vehicle supported by stands.

Step 2: Remove any lower splash shields (if equipped)

• Use a 10mm socket and ratchet to remove bolts holding the front lower splash shield or undertray.
• Use a trim clip removal tool to pop out any plastic clips.
• Set the shield and clips aside in order so reinstallation is easy.

Step 3: Remove the intake ducting for access

• Use a flathead screwdriver to loosen hose clamps at the airbox and throttle body.
• Disconnect any sensor connectors on the intake tube by hand or with a pick tool if there are locking tabs.
• Lift the intake tube out and set it aside. This gives better access to the compressor and belt.

Step 4: Release tension and remove the serpentine belt from the compressor

• Locate the belt tensioner (spring-loaded pulley in the belt path).
• Use the serpentine belt tool or a 1/2" drive breaker bar in the tensioner square hole to rotate the tensioner and relieve belt tension.
• While holding tension off, slide the belt off the A/C compressor pulley by hand.
• Slowly release the tensioner back to its rest position.
• If replacing the belt, remove it completely following your photo or diagram for routing.

Step 5: Disconnect the A/C compressor electrical connector

• Locate the electrical connector on the compressor body.
• Use a pick tool gently if needed to lift the locking tab.
• Pull the connector straight off by hand. Do not pull on the wires.
• Check for corrosion or damage now.

Step 6: Disconnect A/C lines from the compressor

• Confirm that the refrigerant has already been fully recovered by a shop.
• Locate the suction and discharge lines attached to the compressor.
• Use the appropriate line wrench (metric) or 13mm socket depending on the fitting style to loosen the fasteners.
• Carefully pull the lines away from the compressor; you may use a small pry bar very gently if they are stuck.
• Place a drain pan underneath to catch any oil drips.
• Immediately cap or plug the open line ends and compressor ports with clean caps or tape to keep dirt and moisture out.

Step 7: Remove the A/C compressor mounting bolts

• Identify the compressor mounting bolts (usually 3–4 bolts into the engine bracket).
• Use a 13mm socket and ratchet to loosen and remove all mounting bolts while supporting the compressor with your free hand.
• Note any different bolt lengths and positions so you can put them back in the same locations.
• Carefully lower and remove the compressor from the engine bay.
• Torque spec: Refer to the official service manual for exact compressor mounting bolt torque; do not over-tighten.

Step 8: Prepare the new compressor

• Compare the old and new compressors side by side to ensure they match (mounts, ports, pulley, connector).
• Check the label or documentation that comes with the new compressor for oil amount and type. Many new compressors ship pre-filled with the correct PAG oil; others require you to add or adjust oil.
• If required, drain oil from the old compressor into a drain pan and measure it, then set up the new compressor with the same quantity, following the manufacturer’s instructions.
• Lightly coat new O-rings with the correct PAG oil before installation. O-rings seal the fittings.
• Never reuse old O-rings; they often leak.

Step 9: Install the new A/C compressor

• Position the new compressor in the bracket where the old one sat.
• Hand-thread all mounting bolts to avoid cross-threading.
• Use a 13mm socket and ratchet to snug the bolts evenly.
• Use a torque wrench with a 13mm socket to tighten the bolts to the factory specification from the service manual.

Step 10: Reconnect A/C lines with new O-rings

• Install new O-rings on the compressor ports, lightly lubricated with PAG oil.
• Align the suction and discharge lines on the compressor ports without forcing them.
• Hand-start the line bolts or fittings.
• Use the appropriate line wrench (metric) or 13mm socket to tighten the line connections snugly.
• Use a torque wrench with the correct socket to torque the line bolts/fittings to the service manual spec.

Step 11: Reconnect electrical connector

• Apply a tiny amount of dielectric grease inside the connector seal if available.
• Push the connector onto the compressor until it clicks into place.
• Gently tug to confirm it is locked.

Step 12: Reinstall serpentine belt

• Route the belt according to the under-hood diagram or your photo, leaving the compressor pulley for last.
• Use the serpentine belt tool or breaker bar to rotate the tensioner and relieve tension.
• Slide the belt over the compressor pulley, then slowly release the tensioner.
• Visually inspect every pulley to make sure the belt sits fully in the grooves and is not twisted.

Step 13: Reinstall intake ducting and splash shields

• Reinstall the intake tube and reconnect any sensors, tightening the clamps with a flathead screwdriver.
• Reinstall the lower splash shield using a 10mm socket for bolts and the trim clip removal tool to push clips back in place.

Step 14: Reconnect battery and lower the vehicle

• Reconnect the negative battery cable using a 10mm socket and tighten it securely.
• Use the floor jack to raise the vehicle off the jack stands, then remove the stands and lower the vehicle to the ground.

Step 15: Evacuate and recharge the A/C system

• If you have proper A/C equipment: connect the A/C manifold gauge set to the high and low service ports and the vacuum pump to the center hose.
• Pull a deep vacuum for at least 30–45 minutes, then close valves and verify it holds vacuum (no leaks).
• Charge the system with the exact specified amount of refrigerant listed under the hood label, using the A/C manifold gauge set.
• If you do not have this equipment, tow or carefully drive the Grand Cherokee (with A/C OFF) to an A/C shop and have them perform vacuum and recharge with the correct refrigerant and oil.

---

✅ After Repair

• Start the engine and let it idle with the A/C OFF for a couple of minutes to circulate oil.
• Turn A/C ON, set to maximum cold and blower speed, and check for cold air from the vents.
• Visually inspect the compressor and line connections for any signs of oil or refrigerant leaks.
• Listen for unusual noises from the compressor (squealing, grinding, rattling). Shut off immediately if you hear anything abnormal.
• Recheck belt alignment while the engine is running; belt should track smoothly with no wobble.
• After a test drive, inspect again for leaks or loose fasteners.

---

💰 DIY vs Shop Cost

Shop Cost: $1,200–$1,800 (parts + labor, including evac/recharge)

DIY Cost: $400–$800 (compressor, O-rings, refrigerant, oil; assuming shop only does evac/recharge)

You Save: $400–$1,000 by doing the mechanical work yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 3–4 hours.

---
