🔧 Durango - A/C Compressor Replacement

Your A/C compressor is the “pump” that circulates refrigerant so the system can cool. Replacing it is a bolt-on job, but the refrigerant must be professionally recovered and the system must be vacuumed and recharged to the exact under-hood label specification.

Difficulty Level: Advanced | Estimated Time: 3-6 hours (plus A/C evac/recharge time)

---

⚠️ Safety & Precautions

• ⚠️ Refrigerant must be recovered—do not vent to air; it can cause frostbite and is illegal.
• ⚠️ Do not open A/C lines until the system is fully evacuated by an A/C machine.
• ⚠️ Keep dirt/moisture out—cap/plug A/C lines immediately after disconnecting.
• ⚠️ Work on a cool engine; keep hands clear of the belt path.
• ⚠️ Battery disconnect is recommended before unplugging the compressor clutch/solenoid connector.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 3/8" drive ratchet
• 1/2" drive ratchet
• Socket set 8mm–18mm
• Serpentine belt tool or 1/2" breaker bar
• Torque wrench (10–100 ft-lbs range)
• Trim clip remover
• Flathead screwdriver
• Hose clamp pliers
• Line wrench set (metric)
• A/C line caps/plugs kit (specialty)
• Manifold gauge set for R-134a (specialty)
• Vacuum pump (specialty)
• Refrigerant recovery machine (specialty)
• UV leak detection flashlight (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• A/C compressor (Durango SRT compatible) - Qty: 1
• A/C compressor manifold O-ring set - Qty: 1
• Refrigerant (per under-hood label specification) - Qty: 1
• A/C compressor oil (per under-hood label specification) - Qty: 1
• Serpentine belt - Qty: 1 (optional, if worn/cracked)

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear tires.
• Have a shop (or your recovery machine) fully recover the A/C refrigerant before you loosen any A/C line fittings.
• Open the hood and take a picture of the under-hood A/C label—it lists the exact refrigerant charge amount and oil spec for your Durango.
• Disconnect the negative battery terminal using a 10mm socket.
• Tip: Label bolts and connectors as you remove them.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Recover the refrigerant

• Use an A/C refrigerant recovery machine (specialty) to fully recover the system.
• Verify the system is at 0 psi on both high/low sides using the manifold gauge set for R-134a (specialty).

Step 2: Raise the front (as needed for access)

• Lift the front with a floor jack (rated 3-ton minimum) and support on jack stands (rated 3-ton minimum).
• Keep wheel chocks in place.

Step 3: Remove intake ducting/engine cover for access

• Remove the engine cover (pull upward by hand if equipped).
• Loosen intake clamps using a flathead screwdriver or appropriate socket set 8mm–18mm.
• Release any air duct clips with a trim clip remover, then move the ducting aside.

Step 4: Remove the serpentine belt from the A/C compressor

• Rotate the belt tensioner using a serpentine belt tool or 1/2" breaker bar to relieve tension.
• Slip the belt off the A/C compressor pulley, then slowly release the tensioner.
• Tip: Take a belt-routing photo first.

Step 5: Disconnect the compressor electrical connector

• Unplug the compressor connector by releasing the lock tab with a flathead screwdriver (gentle pressure).
• Secure the harness out of the way.

Step 6: Disconnect the A/C lines at the compressor

• Place rags under the fitting area.
• Remove the compressor line retaining bolt using the correct socket set 8mm–18mm.
• Carefully pull the manifold block straight off the compressor.
• Immediately cap/plug the open lines and compressor ports using an A/C line caps/plugs kit (specialty).

Step 7: Remove the A/C compressor

• Support the compressor by hand.
• Remove the compressor mounting bolts using a socket set 8mm–18mm and ratchet.
• Lift the compressor out carefully (avoid bending nearby lines).

Step 8: Prep the new compressor (oil + O-rings)

• Replace the manifold O-rings with the new set from the A/C compressor manifold O-ring set.
• Lightly lubricate O-rings with the correct A/C compressor oil (per under-hood label specification) so they don’t pinch.
• If the new compressor is not pre-filled to the correct amount, add oil per the under-hood A/C label specification.
• Tip: Don’t overfill oil—cooling performance drops.

Step 9: Install the new compressor

• Position the compressor and hand-start all mounting bolts using your socket set 8mm–18mm.
• Tighten mounting bolts evenly using a torque wrench: Torque to 28 Nm (21 ft-lbs).

Step 10: Reconnect the A/C lines

• Remove caps/plugs and keep the openings clean.
• Install the manifold block straight onto the compressor (don’t twist it).
• Install the retaining bolt using the correct socket, then use a torque wrench: Torque to 12 Nm (106 in-lbs).

Step 11: Reconnect the electrical connector

• Plug the connector back in until it clicks.

Step 12: Reinstall the serpentine belt

• Route the belt per your photo.
• Relieve tension with the serpentine belt tool or 1/2" breaker bar and slip the belt onto the last pulley.
• Visually confirm the belt is fully seated in every pulley groove.

Step 13: Reinstall intake ducting/engine cover

• Reinstall ducts, clamps, and clips using a flathead screwdriver and trim clip remover as needed.
• Reinstall the engine cover.

Step 14: Evacuate (vacuum) and recharge the A/C system

• Reconnect the battery negative terminal using a 10mm socket.
• Connect the manifold gauge set for R-134a (specialty) and pull vacuum with a vacuum pump (specialty) (typical target is ~30 minutes).
• Verify the system holds vacuum (no rapid loss). If it won’t hold, recheck O-rings/fittings.
• Recharge with refrigerant (per under-hood label specification) using the correct procedure/equipment.
• Tip: Charging by “can feel” causes poor cooling.

---

✅ After Repair

• Start the engine and set A/C to MAX A/C, blower high, and confirm the compressor engages and cooling is steady.
• Check for abnormal noises (squeal/clicking) around the belt drive.
• Use a UV leak detection flashlight (specialty) to inspect the compressor/manifold area for dye/oil residue (if dye is present in your system).
• Confirm no warning lights and no refrigerant smell.

---

💰 DIY vs Shop Cost

Shop Cost: $1,000-$1,800 (parts + labor + evac/recharge)

DIY Cost: $350-$900 (parts only, plus evac/recharge fee if done by a shop)

You Save: $300-$900 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.5-4.5 hours.

---
