🔧 IS - A/C Compressor Replacement

Replacing the A/C compressor on your IS involves safely recovering the refrigerant, removing the belt-driven compressor, swapping seals, and then evacuating and recharging the system. The critical part is doing the refrigerant recovery/evac/recharge correctly so you don’t damage the new compressor or contaminate the system.

Difficulty Level: Advanced | Estimated Time: 4-6 hours

Assumption: Factory R-134a system; stock underbody covers/access.

---

⚠️ Safety & Precautions

• ⚠️ Refrigerant is high-pressure and can cause frostbite/eye injury—do not vent refrigerant to the air.
• ⚠️ Refrigerant recovery/evac/recharge should be done with proper A/C equipment; if you don’t have it, have a shop recover and later recharge.
• ⚠️ Keep all A/C lines capped/plugged once opened to prevent moisture entering the system.
• ⚠️ Work on a cool engine; the turbo and exhaust area can stay hot.
• ⚠️ Disconnect the 12V battery negative terminal before unplugging the compressor connector.
• ⚠️ Support the car with jack stands on proper lift points; never rely on a jack alone.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 3/8" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (10-150 ft-lbs range)
• Socket set (8mm-19mm)
• 10mm socket
• 12mm socket
• 14mm socket
• 6" extension (3/8" drive)
• Trim clip removal tool
• Phillips screwdriver
• Pick set
• Line caps/plugs kit
• Shop rags
• Catch pan
• Manifold gauge set for R-134a (specialty)
• Vacuum pump (specialty)
• Refrigerant recovery machine (specialty)
• Refrigerant scale (specialty)
• UV leak detection light (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• A/C compressor - Qty: 1
• A/C line O-ring kit (R-134a) - Qty: 1
• A/C compressor oil (ND-OIL 8 equivalent) - Qty: 1
• R-134a refrigerant - Qty: As needed (charge by under-hood label)
• Receiver/drier or desiccant element (if serviced separately on your system) - Qty: 1
• Serpentine drive belt (recommended if worn or oil-soaked) - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and use wheel chocks.
• Have the refrigerant professionally recovered first if you do not have a recovery machine (specialty).
• Disconnect the 12V battery: use a 10mm socket to remove the negative terminal and isolate it so it can’t spring back.
• Raise the front of the car using a floor jack and support it on jack stands at the proper front lift points.
• Remove lower engine covers as needed so you can see the belt and compressor.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Recover the refrigerant

• Use a refrigerant recovery machine (specialty) to recover the R-134a from the system.
• Never crack A/C lines open under pressure.

Step 2: Remove the lower undercovers for access

• Use a trim clip removal tool and 10mm socket to remove the fasteners holding the lower engine undercovers/splash shields.
• Set clips and bolts aside in a tray so you don’t lose them.

Step 3: Remove the serpentine belt from the compressor

• Locate the belt tensioner and use a 14mm socket with a breaker bar to rotate the tensioner and relieve belt tension.
• Slip the belt off the A/C compressor pulley, then slowly release the tensioner.
• If you’re reusing the belt, note the belt routing before removal.

Step 4: Disconnect the compressor electrical connector

• Use a pick set carefully to release the connector lock if needed (don’t break the tab).
• Unplug the compressor connector and move the harness aside.

Step 5: Disconnect the A/C refrigerant lines from the compressor

• Place a catch pan underneath and put shop rags around the line joint to catch oil drips.
• Use the correct socket set (8mm-19mm) to remove the refrigerant line retaining bolt(s) at the compressor manifold.
• Carefully pull the lines straight back (do not pry hard on the aluminum tubes).
• Immediately cap the open lines and compressor ports using a line caps/plugs kit.
• Remove old O-rings using a pick set (do not scratch sealing surfaces).

Step 6: Remove the A/C compressor

• Support the compressor with one hand while removing bolts.
• Use a 12mm socket and/or 14mm socket with a ratchet and extension to remove the compressor mounting bolts.
• Lower the compressor out carefully; keep it upright to reduce oil spillage.

Step 7: Prepare the new compressor (oil and seals)

• Install new O-rings from the A/C line O-ring kit (R-134a) onto the line ends.
• Lightly coat the O-rings with A/C compressor oil (ND-OIL 8 equivalent) so they don’t pinch during assembly.
• If the new compressor is not pre-filled to the correct amount, add oil per service information for your IS; measure what came out of the old compressor and match that amount as directed.
• Turn the compressor input by hand a few rotations to distribute oil evenly before installation.

Step 8: Install the new compressor

• Position the compressor and hand-start all mounting bolts to avoid cross-threading.
• Use a torque wrench (10-150 ft-lbs range) to tighten mounting bolts: Torque to factory specification.
• Reconnect the refrigerant lines, ensuring they seat squarely on the new O-rings.
• Use a torque wrench (10-150 ft-lbs range) on the line retaining bolt(s): Torque to factory specification.
• Reconnect the electrical connector until it clicks.

Step 9: Reinstall the serpentine belt

• Route the belt correctly on all pulleys.
• Use a 14mm socket with a breaker bar to rotate the tensioner, slip the belt on, then release the tensioner slowly.
• Double-check the belt is seated in every pulley groove.

Step 10: Reinstall undercovers and reconnect the battery

• Reinstall undercovers using a trim clip removal tool, Phillips screwdriver, and 10mm socket.
• Reconnect the battery negative terminal using a 10mm socket.

Step 11: Evacuate, leak-check, and recharge the A/C system

• A manifold gauge set for R-134a (specialty) is a hose-and-gauge set that connects to the high/low service ports so you can evacuate and charge safely.
• Connect the manifold gauge set for R-134a (specialty) to the service ports.
• Use a vacuum pump (specialty) to pull a deep vacuum to remove air and moisture: typical evacuation is 30-45 minutes.
• Verify the system holds vacuum (vacuum decay suggests a leak).
• Charge the system by weight using R-134a refrigerant and a refrigerant scale (specialty): Use the exact charge amount printed on the under-hood A/C label.
• If desired, use a UV leak detection light (specialty) after running the A/C to check for signs of leakage.

---

✅ After Repair

• Start the engine and set HVAC to MAX A/C with the blower on high; confirm the compressor engages and the air gets cold.
• Listen for belt squeal or knocking; shut off immediately if you hear loud abnormal noises.
• Check for oily residue at the compressor line connections (often indicates a leak).
• Recheck belt alignment after a short test drive.
• If cooling is weak, do not “top off” blindly—recover and recharge to the exact label weight.

---
