🔧 Lancer - A/C Compressor Replacement

Replacing the A/C compressor means safely recovering the refrigerant, removing the drive belt, swapping the compressor and sealing O-rings, then vacuuming and recharging the system. This is done when the compressor is seized, noisy, leaking, or not building pressure.

Difficulty Level: Advanced | Estimated Time: 3-6 hours

Assumption: your A/C system is factory R-134a; use the under-hood label as the authority for refrigerant type/charge weight.

---

⚠️ Safety & Precautions

• ⚠️ Do not vent refrigerant to the atmosphere—have the system professionally recovered first (this is required and dangerous to skip).
• ⚠️ Wear eye protection and gloves—refrigerant/oil can cause severe frostbite and eye injury.
• ⚠️ Keep hands/tools clear of the belt drive; work with the engine OFF and key removed.
• ⚠️ Disconnect the negative battery terminal before unplugging the compressor clutch/valve connector.
• ⚠️ Cap/plug open A/C lines immediately—moisture damages the system fast.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 10mm socket
• 12mm socket
• 14mm socket
• 3/8" ratchet
• 3/8" extension set
• 14mm combination wrench
• Torque wrench (10–100 Nm range)
• Trim clip removal tool
• Phillips screwdriver
• Line/cap plug set
• A/C manifold gauge set for R-134a
• Vacuum pump (specialty)
• Refrigerant scale (specialty)
• Refrigerant recovery machine (specialty)
• UV leak light (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• A/C compressor - Qty: 1
• A/C compressor clutch/coil (if not included with compressor) - Qty: 1
• A/C compressor manifold O-ring set - Qty: 1
• Receiver/drier or condenser drier (recommended whenever the system is opened) - Qty: 1
• PAG A/C compressor oil (correct spec for your A/C system) - Qty: 1
• R-134a refrigerant (charge amount per under-hood label) - Qty: 1
• A/C system dye (optional) - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Have the refrigerant recovered first. Recovery is removing refrigerant into a machine—this must be done before opening any A/C line.
• Disconnect the battery: use a 10mm socket to remove the negative terminal and isolate it so it can’t spring back.
• Raise the front safely using a floor jack and support it on jack stands at the proper lift points.
• Remove the lower splash shield if it blocks access: use a trim clip removal tool and Phillips screwdriver.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm the system is empty (no pressure)

• Remove the service port caps (low and high side).
• Connect your A/C manifold gauge set for R-134a to both ports.
• Verify both gauges read ~0 psi before you loosen any A/C lines.

Step 2: Remove the drive belt from the A/C compressor

• From above or below, locate the belt tensioner.
• Use a 14mm combination wrench on the tensioner to rotate it and relieve belt tension.
• Slip the belt off the A/C compressor pulley, then slowly release the tensioner.
• Tip: take a belt routing photo first.

Step 3: Unplug the compressor electrical connector

• Locate the compressor electrical connector.
• Press the lock tab and disconnect it by hand.

Step 4: Remove the A/C line/manifold block from the compressor

• Place a rag under the connection to catch any residual oil.
• Use a 12mm socket (common) to remove the manifold retaining bolt(s).
• Carefully pull the lines straight off the compressor (do not pry hard).
• Immediately install line/cap plug set plugs on the open lines and compressor ports.
• Torque on install: 10 Nm (7 ft-lbs) for the line/manifold retaining bolt(s).

Step 5: Remove the compressor mounting bolts and remove the compressor

• Support the compressor with one hand as you remove bolts.
• Use a 14mm socket with a 3/8" ratchet and 3/8" extension set to remove the compressor mounting bolts.
• Lower the compressor out (usually easiest from underneath).
• Torque on install: 25 Nm (18 ft-lbs) for compressor mounting bolts.

Step 6: Prepare the new compressor (oil balancing)

• Drain the old compressor oil into a measuring container (tilt and rotate the hub by hand to help it drain).
• Check the new compressor oil amount (many new compressors ship pre-oiled).
• Add/remove oil so the new compressor contains the same amount you drained, unless the new compressor instructions specify otherwise.
• Use only the specified PAG A/C compressor oil for your system.
• Tip: keep caps on until final install.

Step 7: Install new O-rings and reinstall the A/C lines

• Remove the old O-rings from the line/manifold block.
• Lightly coat the new O-rings with clean PAG A/C compressor oil (this helps sealing and prevents tearing).
• Install the new O-rings, then push the lines straight onto the compressor ports.
• Install and tighten the retaining bolt(s) with a 12mm socket.
• Torque: 10 Nm (7 ft-lbs).

Step 8: Install the new compressor

• Position the compressor and hand-start all mounting bolts to avoid cross-threading.
• Tighten using a 14mm socket and finish with a torque wrench.
• Torque: 25 Nm (18 ft-lbs).
• Reconnect the electrical connector by hand until it clicks.

Step 9: Reinstall the belt

• Route the belt according to your photo/routing diagram.
• Use a 14mm combination wrench to rotate the tensioner and slip the belt onto the compressor pulley.
• Release the tensioner slowly and confirm the belt is centered on all pulleys.

Step 10: Evacuate (vacuum) the system and recharge by weight

• Connect the A/C manifold gauge set for R-134a to both service ports.
• Connect the center hose to the vacuum pump (specialty).
• Run vacuum for at least 30–45 minutes to boil off moisture.
• Close valves and verify it holds vacuum (no rise) for 10–15 minutes.
• Recharge using a refrigerant scale (specialty) and add refrigerant by the exact weight listed on the under-hood A/C label.

Step 11: Leak check

• Start the engine, set A/C to MAX, blower high, and let it run.
• Use a UV leak light (specialty) if dye is present, and inspect compressor fittings and service ports.
• Reinstall splash shield using a trim clip removal tool and Phillips screwdriver.

---

✅ After Repair

• Reconnect the battery negative terminal with a 10mm socket.
• Confirm vent temperature drops and the compressor cycles normally (no loud knocking/grinding).
• Verify no oily residue appears at the compressor fittings after a short drive.
• If cooling is weak or pressures are abnormal, stop and re-check charge weight and leaks.

---
