🔧 Colorado - Battery Replacement

Replacing your Colorado’s 12V battery is a straightforward under-hood job. You’ll remove the hold-down, disconnect the cables (negative first), swap the battery, then reconnect (positive first) to avoid electrical shorts.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• Wear eye protection and gloves—battery acid is corrosive.
• Keep metal tools away from both terminals at the same time to prevent a short.
• Disconnect the negative (-) cable first and reconnect it last.
• Do not lean over the battery while disconnecting/reconnecting.
• Battery disconnect is not required for removal (you will disconnect the cables anyway), but be prepared for lost radio presets/clock.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 13mm socket
• 3/8" ratchet
• 6" socket extension
• Torque wrench (in-lb and ft-lb capable)
• Battery terminal brush
• Battery strap/lifter
• Digital multimeter
• Memory saver (OBD-II) (specialty)
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V battery (correct fit for your Colorado) - Qty: 1
• Battery terminal anti-corrosion pads - Qty: 2
• Battery terminal protectant spray - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and turn the ignition fully OFF.
• Open the hood and locate the battery on the passenger-side front of the engine bay.
• If you want to keep presets, plug in a memory saver (OBD-II) before disconnecting the battery (it supplies low power to preserve settings).
• Check the replacement battery: match the terminal layout and confirm it’s the correct type (some trucks use AGM—look for “AGM” on the label).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove any battery cover (if equipped)

• Lift off the cover by hand. If it’s clipped, gently release the clips by hand.

Step 2: Disconnect the negative (-) battery cable

• Use a 10mm socket with a 3/8" ratchet to loosen the negative terminal clamp nut.
• Twist the clamp slightly and lift it off the negative post, then tuck it aside so it can’t spring back.
• Negative first prevents accidental shorts.
• Torque to 5 Nm (44 in-lbs) when reinstalling the terminal clamp nut.

Step 3: Disconnect the positive (+) battery cable

• Use a 10mm socket with a 3/8" ratchet to loosen the positive terminal clamp nut.
• Lift the clamp off the positive post and position it away from the battery.
• Torque to 5 Nm (44 in-lbs) when reinstalling the terminal clamp nut.

Step 4: Remove the battery hold-down

• Use a 13mm socket, 6" socket extension, and 3/8" ratchet to remove the hold-down bolt.
• Remove the hold-down bracket and set it aside.
• Torque to 17 Nm (13 ft-lbs) when reinstalling the hold-down bolt.

Step 5: Remove the battery

• Use a battery strap/lifter to lift the battery straight up and out.
• Place the old battery on the ground in a safe, upright position.

Step 6: Clean the battery terminals and tray

• Use a battery terminal brush to clean the inside of both cable clamps until shiny metal is visible.
• Wipe the battery tray area clean by hand (don’t allow debris to fall into the engine bay).
• Install battery terminal anti-corrosion pads onto the new battery posts if you’re using them.

Step 7: Install the new battery and secure it

• Set the new battery into the tray in the same orientation as the old one.
• Reinstall the hold-down bracket and bolt using a 13mm socket, 6" socket extension, and 3/8" ratchet.
• Finish with a torque wrench: Torque to 17 Nm (13 ft-lbs).

Step 8: Reconnect the positive (+) cable, then the negative (-) cable

• Install the positive clamp first and tighten using a 10mm socket.
• Use a torque wrench: Torque to 5 Nm (44 in-lbs).
• Install the negative clamp last and tighten using a 10mm socket.
• Use a torque wrench: Torque to 5 Nm (44 in-lbs).
• Apply battery terminal protectant spray after everything is tight and secure.

Step 9: Reinstall any battery cover (if equipped)

• Reinstall the cover by hand and ensure it’s fully seated.

---

✅ After Repair

• Start your Colorado and confirm it cranks normally and no warning lights stay on.
• Use a digital multimeter at the battery posts with the engine running: you should typically see about 13.5V-14.8V (charging).
• Reset the clock and re-save radio presets if needed.
• Recycle the old battery (most parts stores take it back).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $180-$320 (parts only)

You Save: $70-$130 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
