🔧 C-HR - 12V Battery Replacement

Replacing the 12V battery on your C-HR is a straightforward under-hood job. The key is disconnecting and reconnecting the terminals in the correct order to prevent shorts and protect electronics.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Keep the key fob at least 10 ft away from your C-HR while working.
• ⚠️ Always disconnect the negative (-) terminal first and reconnect it last to reduce short-circuit risk.
• ⚠️ Do not let a tool touch the battery positive (+) and any metal body part at the same time.
• ⚠️ Wear eye protection and gloves; batteries can vent acid/corrosive residue.
• ⚠️ Battery disconnect is required for replacement (you’ll lose clock/radio presets unless you use a memory saver).

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 3/8" drive ratchet
• 6" socket extension
• Torque wrench (10–30 Nm range)
• Battery terminal puller (specialty)
• Battery carrying strap (specialty)
• Battery terminal cleaning brush
• Shop rags
• Nitrile gloves
• Safety glasses
• Memory saver (OBD-II) (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V battery (OEM-equivalent specification for your C-HR) - Qty: 1
• Battery terminal anti-corrosion spray - Qty: 1
• Battery terminal felt washers - Qty: 2

---

📋 Before You Begin

• Park on level ground, shift to P, and set the parking brake.
• Turn the vehicle OFF and make sure all lights/accessories are OFF.
• If you’re using a memory saver: connect your OBD-II memory saver (specialty) now (it keeps settings while the battery is disconnected).
• Open the hood and locate the 12V battery in the engine bay.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm battery access and identify terminals

• Visually identify the negative (-) terminal and the positive (+) terminal (positive typically has a protective cover).
• Put on nitrile gloves and safety glasses.

Step 2: Disconnect the negative (-) terminal first

• Use a 10mm socket with a 3/8" drive ratchet to loosen the negative terminal clamp nut.
• Wiggle the clamp up and off the battery post. If it’s stuck, use a battery terminal puller (specialty) (a small puller that lifts the clamp without prying).
• Wrap the disconnected negative cable end with a shop rag so it can’t spring back and touch the battery.
• Torque to 5 Nm (44 in-lbs) when reinstalling.

Step 3: Disconnect the positive (+) terminal

• Open/remove the positive terminal cover.
• Use a 10mm socket with a 3/8" drive ratchet to loosen the positive terminal clamp nut.
• Lift the clamp straight up off the battery post and position it aside so it cannot touch metal.
• Torque to 5 Nm (44 in-lbs) when reinstalling.

Step 4: Remove the battery hold-down

• Use a 12mm socket with a ratchet and 6" socket extension to remove the battery hold-down fasteners.
• Lift off the hold-down bracket and set it aside.
• Torque to 19 Nm (14 ft-lbs) when reinstalling.

Step 5: Remove the old battery

• Use a battery carrying strap (specialty) to lift the battery straight up and out.
• Set it on the ground upright (do not tip it).
• Keep it level to avoid spills.

Step 6: Clean the terminals and tray

• Use a battery terminal cleaning brush to clean corrosion from the inside of the terminal clamps.
• Wipe the battery tray area using shop rags.
• Install battery terminal felt washers if you’re using them.

Step 7: Install the new battery

• Place the new battery into the tray in the same orientation as the old one.
• Reinstall the hold-down bracket using the 12mm socket, then tighten with a torque wrench: Torque to 19 Nm (14 ft-lbs).

Step 8: Reconnect terminals in the correct order (positive first)

• Reconnect the positive (+) terminal first. Use a 10mm socket to snug it, then use a torque wrench: Torque to 5 Nm (44 in-lbs).
• Reconnect the negative (-) terminal last. Use a 10mm socket, then Torque to 5 Nm (44 in-lbs).
• Apply battery terminal anti-corrosion spray to both terminals.

---

✅ After Repair

• Start your C-HR and confirm the engine cranks normally.
• Reset the clock and any saved settings if you didn’t use a memory saver.
• If the power windows lost auto-up/down: with the engine running, fully lower the window, then fully raise it and keep holding the switch for ~2 seconds.
• If warning lights stay on after a short drive, scan for codes (some systems may need a brief drive to relearn).

---

💰 DIY vs Shop Cost

Shop Cost: $220-$420 (parts + labor)

DIY Cost: $140-$280 (parts only)

You Save: $80-$200 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
