🔧 Focus - Battery Replacement

Replacing the 12V battery on your Focus is a simple under-hood job: disconnect the old battery safely, remove the hold-down, and install the new battery with clean, tight connections. A weak battery can cause slow cranking, random warning lights, and no-start issues.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Wear eye protection and gloves; batteries can vent acid and hydrogen gas.
• ⚠️ Keep sparks/flames away; do not smoke near the battery.
• ⚠️ Always disconnect negative (-) first and reconnect negative (-) last to reduce short-circuit risk.
• ⚠️ The battery is heavy; lift with both hands and keep it upright.
• ⚠️ Battery disconnect will reset clock and some settings.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 10mm socket
• 13mm socket
• 3/8" ratchet
• 6" socket extension
• Torque wrench (in-lb or low-range ft-lb)
• Battery terminal brush
• Shop rags
• Battery carrying strap (optional)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V battery (Group 96R) - Qty: 1
• Battery terminal anti-corrosion spray - Qty: 1
• Battery terminal felt washers - Qty: 2

---

📋 Before You Begin

• Park on level ground, switch ignition OFF, remove the key, and open the hood.
• Wait 2-3 minutes before disconnecting the battery so modules can “go to sleep.”
• Set your tools aside so nothing metal can fall across the battery terminals.
• Torque wrench = tool that tightens to a set force.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the battery and identify terminals

• Open the hood and find the battery in the engine bay.
• Identify negative (-) (usually black cable) and positive (+) (usually red cover/cable).

Step 2: Disconnect the negative (-) battery cable

• Use a 10mm socket with a 3/8" ratchet to loosen the negative terminal clamp bolt.
• Lift the negative clamp straight up and off the battery post.
• Tuck the cable to the side so it cannot spring back onto the post.

Step 3: Disconnect the positive (+) battery cable

• Use a 10mm socket with a 3/8" ratchet to loosen the positive terminal clamp bolt.
• Remove the positive clamp from the battery post and keep it from touching metal parts.

Step 4: Remove the battery hold-down

• Use a 13mm socket, 6" socket extension, and 3/8" ratchet to remove the battery hold-down bolt/retainer at the base of the battery.
• Set the hold-down parts aside where they won’t get lost.

Step 5: Remove the old battery

• Lift the battery straight up and out. Use a battery carrying strap if you have one.
• Keep the battery upright to avoid acid leakage.

Step 6: Clean the tray and cable clamps

• Use shop rags to wipe debris from the tray.
• Use a battery terminal brush to gently clean the inside of both cable clamps until the metal looks bright.
• Install battery terminal felt washers if you’re using them.

Step 7: Install the new battery

• Place the new Group 96R battery into the tray in the same orientation as the old one.
• Reinstall the hold-down using the 13mm socket, extension, and ratchet.
• Use a torque wrench: Torque to 10 Nm (7 ft-lbs) for the hold-down fastener.

Step 8: Reconnect the positive (+) cable first

• Push the positive clamp fully down onto the positive post.
• Use a 10mm socket and torque wrench: Torque to 5 Nm (44 in-lbs).
• Apply a light coat of battery terminal anti-corrosion spray.

Step 9: Reconnect the negative (-) cable last

• Push the negative clamp fully down onto the negative post.
• Use a 10mm socket and torque wrench: Torque to 5 Nm (44 in-lbs).
• Apply a light coat of battery terminal anti-corrosion spray.

Step 10: Reset the Battery Monitoring System (BMS)

• If you have a scan tool: use it to run BMS Reset / Battery Replacement Reset for Ford.
• If you don’t have a scan tool, try this manual reset sequence:
• Turn ignition to ON (engine OFF).
• Within 10 seconds, flash the high beams 5 times.
• Then press and release the brake pedal 3 times.
• Watch for the battery light to flash (if equipped), which indicates a reset.
• If it doesn’t flash, it may still learn normally.

---

✅ After Repair

• Start the engine and confirm it cranks strongly.
• Check that the battery cables are secure by gently twisting each clamp by hand (they should not move).
• Set the clock and re-save radio presets as needed.
• If you have a voltmeter, charging voltage at idle should typically be around 13.5-14.7V.
• Dispose of the old battery properly; most parts stores will recycle it.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$420 (parts + labor)

DIY Cost: $140-$260 (parts only)

You Save: $80-$160 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
