🔧 Outback - Battery Replacement

You’ll remove the old 12V battery, clean the terminals/tray, and install a new battery with the cables connected in the correct order. This restores reliable starting power and prevents issues like slow cranking and random electrical glitches.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Battery acid is corrosive; wear gloves and safety glasses.
• ⚠️ Never let a tool touch both battery terminals at once.
• ⚠️ Disconnect negative (-) first and reconnect it last to reduce short-circuit risk.
• ⚠️ Keep sparks/flames away; batteries can vent explosive gas.
• ⚠️ Battery is heavy; lift with both hands and keep it upright.
• ⚠️ Battery disconnect is not required, but this job does disconnect the battery.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm combination wrench
• 10mm deep socket
• 3/8" drive ratchet
• 3" socket extension
• Torque wrench (in-lb)
• Battery terminal puller (specialty)
• Battery terminal brush
• Baking soda
• Clean water
• Small stiff nylon brush
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V battery (Group Size 35) - Qty: 1
• Battery terminal anti-corrosion pads - Qty: 2
• Battery terminal protector spray - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to neutral, and set the parking brake.
• Turn the ignition fully OFF and remove the key.
• If you want to keep radio presets/clock, plan to reset them afterward (this job will erase some settings).
• Open the hood and locate the battery on the passenger side of the engine bay.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Make the area safe

• Put on nitrile gloves and safety glasses.
• Use a shop towel to wipe off loose dirt around the battery so nothing falls into the terminals.

Step 2: Disconnect the negative (-) battery terminal

• Use a 10mm combination wrench to loosen the negative terminal clamp bolt (the cable marked “-”).
• Wiggle the clamp upward and off the battery post by hand.
• If it’s stuck, use a battery terminal puller (specialty) (a small puller that lifts the clamp off without prying).
• Tuck the negative cable to the side so it cannot spring back and touch the post.
• Torque on install: Torque to 5.4 Nm (48 in-lbs)

Step 3: Disconnect the positive (+) battery terminal

• Use a 10mm combination wrench to loosen the positive terminal clamp bolt (the cable marked “+”).
• Lift the clamp off the post and move it aside so it can’t touch metal parts.
• Torque on install: Torque to 5.4 Nm (48 in-lbs)

Step 4: Remove the battery hold-down bracket

• Use a 10mm deep socket, 3/8" drive ratchet, and 3" socket extension to remove the two hold-down nuts.
• Lift off the hold-down bar and unhook the J-bolts.
• Torque on install: Torque to 7.5 Nm (66 in-lbs)

Step 5: Remove the old battery

• Lift the battery straight up and out with both hands.
• Set it upright on the ground (not on carpet or inside the car).
• Keep it upright to avoid acid leaks.

Step 6: Neutralize and clean corrosion (if present)

• Mix a small amount of baking soda with a little clean water until it’s a thin paste.
• Use the small stiff nylon brush to gently scrub corrosion on the battery tray and cable ends.
• Use clean water and shop towels to rinse/wipe the area dry.
• Use a battery terminal brush to clean the inside of the cable clamps until shiny metal is visible.

Step 7: Install the new battery

• Place the new Group Size 35 battery into the tray in the same orientation as the old one.
• Make sure it sits flat and doesn’t rock.

Step 8: Reinstall and tighten the battery hold-down

• Hook the J-bolts back into place and set the hold-down bar on top.
• Use a 10mm deep socket, 3/8" drive ratchet, and 3" socket extension to snug both nuts evenly.
• Finish with a torque wrench (in-lb): Torque to 7.5 Nm (66 in-lbs)
• Don’t over-tighten; it can crack the case.

Step 9: Connect the positive (+) terminal first

• Install a battery terminal anti-corrosion pad onto the positive post.
• Set the positive clamp fully down on the post.
• Use a 10mm combination wrench to tighten, then use a torque wrench (in-lb): Torque to 5.4 Nm (48 in-lbs)

Step 10: Connect the negative (-) terminal last

• Install a battery terminal anti-corrosion pad onto the negative post.
• Set the negative clamp fully down on the post.
• Use a 10mm combination wrench to tighten, then use a torque wrench (in-lb): Torque to 5.4 Nm (48 in-lbs)

Step 11: Protect the terminals

• Apply battery terminal protector spray to both terminals to slow future corrosion.
• Use a shop towel to wipe any overspray.

---

✅ After Repair

• Start the engine and verify the crank is strong and steady.
• Confirm headlights, brake lights, and horn work normally.
• Reset the clock and radio presets if needed.
• If the driver window one-touch function acts odd, initialize it: with the engine running, fully lower the window and hold the switch down 2 seconds, then fully raise it and hold the switch up 2 seconds.
• Check that the battery is secure and cables don’t move when lightly pushed by hand.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$400 (parts + labor)

DIY Cost: $140-$240 (parts only)

You Save: $110-$160 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
