🔧 ILX - 12V Battery Replacement

Your ILX’s 12V battery powers starting and all electronics. Replacing it is straightforward: remove the hold-down, disconnect the cables (negative first), swap the battery, then reconnect (positive first).

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Wear eye protection and gloves; battery acid is corrosive.
• ⚠️ Keep metal tools away from both terminals at once to prevent sparks/shorts.
• ⚠️ Disconnect negative (-) first and reconnect it last.
• ⚠️ If your battery has a vent tube, reconnect it to prevent fumes in the engine bay.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 10mm wrench
• Ratchet (3/8")
• 6" extension (3/8")
• Battery terminal brush
• Torque wrench (in-lb)
• Gloves (chemical-resistant)
• Safety glasses
• Fender cover
• Memory saver (OBD-II) (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V car battery (Group Size 51R) - Qty: 1
• Battery terminal protectant spray - Qty: 1
• Anti-corrosion terminal felt washers - Qty: 2

---

📋 Before You Begin

• Park on level ground, shift to Park, and turn the ignition fully OFF.
• Open the hood and install a fender cover to protect paint.
• If you want to keep radio presets and clock, plug in a memory saver (a small backup power device that plugs into the OBD-II port) before disconnecting the battery.
• Make sure you know which terminal is + and which is - before loosening anything.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Access the battery

• Open the hood and locate the battery in the engine bay.
• If there’s a plastic cover over the battery area, remove it by hand (or use a 10mm socket if it’s bolted).

Step 2: Disconnect the negative (-) cable first

• Use a 10mm wrench to loosen the nut on the negative (-) terminal clamp.
• Wiggle the clamp and lift it off the terminal. Tuck it to the side so it can’t spring back.
• Tip: Twist the clamp, don’t pry.

Step 3: Disconnect the positive (+) cable

• Use a 10mm wrench to loosen the nut on the positive (+) terminal clamp.
• Lift the clamp off and move it aside, away from any metal.

Step 4: Remove the battery hold-down

• Use a 10mm socket, ratchet (3/8"), and 6" extension (3/8") to remove the hold-down nuts/bolts.
• Lift off the hold-down bracket and set it aside.

Step 5: Remove the old battery

• Lift the battery straight up and out. Batteries are heavy—lift with your legs, not your back.
• If your battery has a small vent tube, pull it off gently and remember where it connects.

Step 6: Clean and prep the terminals

• Use a battery terminal brush to clean corrosion from the cable clamps.
• Install anti-corrosion terminal felt washers if you’re using them.

Step 7: Install the new battery

• Place the new battery into the tray in the same orientation as the old one (terminals in the same positions).
• Reconnect the vent tube if equipped.
• Reinstall the hold-down bracket and tighten with a 10mm socket.
• Torque to 9 Nm (80 in-lb) for the hold-down fasteners.

Step 8: Reconnect cables (positive first, then negative)

• Install the positive (+) clamp first and tighten using a 10mm wrench.
• Torque to 5 Nm (44 in-lb) for the terminal clamp nut.
• Install the negative (-) clamp last and tighten using a 10mm wrench.
• Torque to 5 Nm (44 in-lb) for the terminal clamp nut.
• Spray terminals lightly with battery terminal protectant spray.

Step 9: Final check

• Try to rotate each clamp by hand—if it moves, tighten slightly with a 10mm wrench.
• Reinstall any covers you removed.

---

✅ After Repair

• Start the engine and confirm it cranks normally.
• Reset the clock and re-save radio presets if they were lost.
• If the power windows act “one-touch” weird, cycle each window fully down and fully up once to relearn.
• Check the dash for warning lights; most should clear after a short drive if everything is connected properly.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$420 (parts + labor)

DIY Cost: $140-$260 (parts only)

You Save: $80-$160 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
