🔧 Outback - Spark Plug Replacement

On your Outback, the spark plugs sit on the sides of the flat-6 engine, so access is tight and usually done through the wheel wells. You’ll remove the ignition coils, swap all 6 plugs, then reinstall and torque everything correctly to prevent misfires and damaged threads.

Difficulty Level: Advanced | Estimated Time: 2.5–4.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a fully cool engine to avoid burns and damaged threads.
• ⚠️ Support the Outback on jack stands on level ground; never rely on a jack alone.
• ⚠️ Disconnect the negative battery cable with a 10mm socket to prevent accidental shorting.
• ⚠️ Do not drop anything into the spark plug wells; debris can damage the engine.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Wheel chocks
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• 19mm lug nut socket
• Breaker bar (1/2" drive)
• Ratchet (3/8" drive)
• Torque wrench (3/8" drive, 10–30 ft-lbs range)
• 10mm socket (3/8" drive)
• 12mm socket (3/8" drive)
• 3/8" drive extension set (3", 6", 10")
• 3/8" drive wobble extension (specialty)
• 14mm thin-wall spark plug socket (3/8" drive)
• Flat trim clip tool
• Small pick tool
• Dielectric grease
• Compressed air blower or canned air
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Iridium spark plugs (correct fit for your Outback) - Qty: 6

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Open the hood and let the engine cool completely.
• Disconnect the negative battery terminal using a 10mm socket, then position the cable so it can’t spring back.
• Tip: Take a quick photo of each side first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the front and remove both front wheels

• Loosen front lug nuts slightly using a 19mm lug nut socket and breaker bar.
• Lift the front with a floor jack (rated 3-ton minimum) and support it with jack stands (rated 3-ton minimum).
• Remove lug nuts with a 19mm lug nut socket and remove both front wheels.

Step 2: Open the wheel-well access to the ignition coils

• In each front wheel well, remove the necessary plastic clips/screws from the inner liner using a flat trim clip tool (and 10mm socket if bolts are present).
• Peel the liner back enough to reach the ignition coil area for that side.
• Tip: Keep clips from left and right separate.

Step 3: Unplug and remove the ignition coil (one plug at a time)

• Locate the ignition coil and its electrical connector through the wheel well.
• Release the connector lock using a small pick tool, then unplug it by hand (do not pull on wires).
• Remove the coil retaining bolt(s) using a 10mm socket (some locations may use a 12mm socket).
• Twist the coil slightly and pull it straight out by hand.
• Torque to 7.5 Nm (5.5 ft-lbs) when reinstalling the ignition coil bolt(s).

Step 4: Clean the spark plug well

• Blow out the spark plug well using compressed air blower or canned air so dirt can’t fall into the cylinder.
• Use a flashlight to confirm the well is clear.

Step 5: Remove the old spark plug

• Install the 14mm thin-wall spark plug socket onto a 3/8" drive extension set; add a 3/8" drive wobble extension (specialty) if the angle is tight (a wobble extension allows a small bend to reach around obstacles).
• Break the plug loose and remove it with the ratchet (3/8" drive).
• Lift the plug out carefully with the socket.

Step 6: Install the new spark plug (protect the threads)

• Start the new plug by hand using the 14mm thin-wall spark plug socket (3/8" drive) and extension, turning gently clockwise.
• If it doesn’t thread in smoothly, back it out and restart—don’t force it.
• Tighten with a torque wrench (3/8" drive, 10–30 ft-lbs range): Torque to 21 Nm (15.5 ft-lbs).
• Tip: No anti-seize on plated plugs.

Step 7: Reinstall the ignition coil

• Apply a small amount of dielectric grease inside the coil boot (dielectric grease helps prevent moisture and makes future removal easier).
• Push the coil straight onto the spark plug until it seats fully.
• Install and tighten the coil retaining bolt(s) using a 10mm socket (or 12mm socket if applicable): Torque to 7.5 Nm (5.5 ft-lbs).
• Reconnect the electrical connector by hand until it clicks.

Step 8: Repeat for all 6 spark plugs

• Repeat Steps 3–7 for each cylinder, doing one at a time so nothing gets mixed up.

Step 9: Reassemble the wheel wells and wheels

• Reposition the wheel-well liners and reinstall clips/bolts using the flat trim clip tool and 10mm socket.
• Reinstall wheels and hand-thread lug nuts.
• Lower the Outback off the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern with a torque wrench: Torque to 120 Nm (88.5 ft-lbs).

Step 10: Reconnect the battery

• Reconnect the negative battery terminal using a 10mm socket.

---

✅ After Repair

• Start the engine and let it idle. It should run smooth with no flashing check engine light.
• Listen for ticking, arcing, or a steady misfire. If it runs rough, recheck coil connectors and that each coil is fully seated.
• Take a short test drive, then recheck for any stored warning lights.

---
