🔧 Frontier - Spark Plug Replacement

Your Frontier’s spark plugs ignite the air/fuel mixture. Worn plugs can cause misfires, rough idle, poor mileage, and hard starts. On your Frontier’s 4.0L V6, this job typically requires removing the upper intake manifold to reach the rear plugs.

Difficulty Level: Intermediate | Estimated Time: 2.5-4.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine to avoid burns and stripped threads.
• ⚠️ Disconnect the negative battery cable before unplugging ignition coils.
• ⚠️ Keep dirt out of the intake ports—cover openings immediately if the manifold comes off.
• ⚠️ Do not over-tighten spark plugs; aluminum heads strip easily.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 1/4" drive ratchet
• 3/8" drive ratchet
• 3/8" torque wrench (10–60 ft-lbs range)
• 1/4" torque wrench (inch-lb range)
• 10mm socket
• 12mm socket
• 14mm socket
• 5/8" spark plug socket (rubber insert)
• 3/8" extension set (3", 6", 10")
• 3/8" universal joint swivel
• Flathead screwdriver
• Needle-nose pliers
• Pick tool
• Compressed air blow gun
• Shop vacuum
• Painter’s tape
• Paint marker
• Magnetic pickup tool
• Trim clip tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plug set (OEM-style for 4.0L V6) - Qty: 6
• Upper intake manifold gasket set - Qty: 1
• Throttle body gasket - Qty: 1
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and let the engine cool fully.
• Disconnect the negative battery cable using a 10mm socket and tuck it aside.
• Use painter’s tape to label any vacuum hoses/electrical connectors you unplug.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover and intake duct

• Remove the plastic engine cover (if equipped) using a 10mm socket.
• Loosen the air intake duct clamps using a flathead screwdriver.
• Unplug the MAF sensor connector (on the intake tube) by pressing the lock tab by hand.
• Remove the intake duct and set it aside.

Step 2: Create access to the upper intake manifold

• Disconnect any vacuum hoses and electrical connectors attached to the upper intake manifold using needle-nose pliers (for spring clamps) and a pick tool (to gently lift stubborn hose ends).
• Mark hose locations with a paint marker or painter’s tape.

Step 3: Remove the upper intake manifold (plenum)

• Remove the upper intake manifold fasteners using a 12mm socket and 3/8" extension.
• Lift the manifold straight up. If it sticks, gently rock it by hand—do not pry on sealing surfaces.
• Immediately cover the exposed intake openings with clean shop towels to prevent anything from falling in.
• Take a quick photo before unplugging more.
• Torque to 25 Nm (18 ft-lbs) for upper intake manifold fasteners during reassembly.

Step 4: Remove ignition coils (one cylinder at a time)

• Unplug the ignition coil electrical connector by pressing the tab (use a pick tool gently if needed).
• Remove the coil hold-down bolt using a 10mm socket.
• Twist the coil slightly, then pull it straight up and out.
• Torque to 8 Nm (71 in-lbs) for ignition coil bolts during reassembly.

Step 5: Clean the spark plug wells

• Blow out debris around each spark plug using compressed air blow gun.
• If dirt is heavy, use the shop vacuum first, then compressed air.
• This helps prevent grit from falling into the cylinder when the plug comes out.

Step 6: Remove the old spark plugs

• Remove each spark plug using a 5/8" spark plug socket, 3/8" extension, and 3/8" ratchet.
• For tight rear locations, use a 3/8" universal joint swivel (a swivel lets the socket bend slightly to reach angled plugs).
• If a plug feels stuck, stop and work it gently back-and-forth to avoid damaging threads.

Step 7: Install the new spark plugs

• Check the new plugs are the correct type for your Frontier and match the old plug’s reach/length.
• Start each plug by hand using the 5/8" spark plug socket and an extension only (no ratchet) so you don’t cross-thread.
• Tighten with a 3/8" torque wrench: Torque to 25 Nm (18 ft-lbs).
• Do not apply anti-seize unless the plug manufacturer specifically instructs it.

Step 8: Reinstall ignition coils

• Apply a very small amount of dielectric grease inside the coil boot (helps prevent moisture and eases future removal).
• Reinstall each coil and tighten the coil bolt using a 10mm socket.
• Torque to 8 Nm (71 in-lbs).
• Reconnect each coil electrical connector until it clicks.

Step 9: Reinstall the upper intake manifold with new gaskets

• Remove the old intake gaskets and install the new upper intake manifold gasket set.
• Use a shop vacuum to ensure nothing is in the intake area before removing the shop towels.
• Set the upper intake manifold back in place and start all fasteners by hand.
• Tighten evenly using a 12mm socket, then torque: Torque to 25 Nm (18 ft-lbs).

Step 10: Reinstall intake ducting and reconnect battery

• Reinstall the intake duct and tighten clamps using a flathead screwdriver.
• Reconnect the MAF sensor connector.
• Reconnect the negative battery cable using a 10mm socket.

---

✅ After Repair

• Start your Frontier and let it idle for 1–2 minutes. A brief rough idle can happen after battery disconnect.
• Listen for hissing (vacuum leak) around the intake area. If you hear one, re-check hose routing and manifold seating.
• Take a short test drive. Confirm no hesitation and no check engine light.
• If a check engine light appears, re-check coil connectors first (most common).

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $80-$180 (parts only)

You Save: $270-$470 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.5-4.0 hours.

---
