🔧 Odyssey - Spark Plug Replacement

On your Odyssey, the front 3 spark plugs are easy to reach, but the rear 3 sit under the upper intake manifold (the top “air passage” on the engine). This job replaces all 6 plugs and restores smooth starts, power, and fuel economy.

Difficulty Level: Advanced | Estimated Time: 2.5-4.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a fully cool engine to avoid burns and damaged threads.
• ⚠️ Disconnect the battery negative cable to prevent accidental shorts.
• ⚠️ Do not over-tighten spark plugs; the cylinder head is aluminum and threads can strip.
• ⚠️ Keep dirt out of the intake; cover open ports immediately after manifold removal.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 10mm socket
• 12mm socket
• 14mm socket
• 3/8" drive ratchet
• 3/8" drive extension set (3", 6", 10")
• 3/8" drive wobble extension
• 5/8" spark plug socket (rubber insert or магнит type)
• Torque wrench (3/8" drive, 10-60 ft-lbs range)
• Flat trim tool
• Phillips screwdriver
• Pliers
• Pick tool
• Compressed air blow gun
• Painter’s tape
• Shop towels
• Magnetic parts tray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs (OEM-equivalent, correct heat range and reach) - Qty: 6
• Upper intake manifold gasket set - Qty: 1
• Throttle body gasket - Qty: 1
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and let the engine cool completely (at least 1 hour).
• Use 10mm socket to disconnect the battery negative cable and tuck it aside.
• Use painter’s tape to label any hoses/connectors you unplug. Helps you avoid mix-ups.
• Know these terms: the ignition coil is the pencil-shaped part on each plug; the upper intake manifold is the top aluminum/plastic section feeding air to the rear bank.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover and front-access parts

• Remove the engine cover using your hands and a flat trim tool as needed to release the rubber grommets.
• If the air intake duct/resonator blocks access, loosen clamps and fasteners using a Phillips screwdriver and 10mm socket, then set the duct aside.

Step 2: Replace the front bank (front 3) spark plugs

• Unplug each ignition coil connector by pressing the lock tab; use a pick tool gently if the tab is stubborn.
• Remove each coil hold-down bolt with a 10mm socket, then pull the coil straight up.
• Blow out the spark plug well with compressed air blow gun so debris can’t fall into the cylinder.
• Remove the spark plug using a 5/8" spark plug socket, 3/8" ratchet, and extension.
• Install the new spark plug by hand first using the spark plug socket and extension (no ratchet at first). Prevents cross-threading.
• Tighten with a torque wrench: Torque to 18 N·m (13 ft-lbs).
• Apply a small amount of dielectric grease inside the coil boot (the rubber inside the coil that touches the plug).
• Reinstall the coil and coil bolt with a 10mm socket: Torque to 10 N·m (7 ft-lbs).
• Reconnect the coil connector until it clicks.

Step 3: Clear access for the rear bank (prepare to remove the upper intake)

• Locate the upper intake manifold on top of the engine (the section feeding the rear cylinders).
• Disconnect any vacuum hoses and electrical connectors attached to the upper intake using pliers and a pick tool as needed.
• Use painter’s tape to label each hose/connector you remove.

Step 4: Remove the throttle body from the upper intake

• Unplug the throttle body electrical connector by hand (use a pick tool carefully if needed).
• Remove the throttle body mounting fasteners using a 10mm socket.
• Move the throttle body aside and remove/discard the old throttle body gasket.
• Cover the intake opening with a shop towel to keep dirt out.

Step 5: Remove the upper intake manifold (rear plug access)

• Remove the upper intake manifold fasteners using a 12mm socket and extension.
• Lift the upper intake manifold straight up and off. If it sticks, gently work it loose by hand—do not pry on sealing surfaces.
• Immediately cover the exposed intake ports with shop towels.
• Remove/discard the old upper intake manifold gaskets.

Step 6: Replace the rear bank (rear 3) spark plugs

• Unplug the rear ignition coil connectors (use a pick tool gently if needed).
• Remove coil bolts with a 10mm socket and pull coils out.
• Blow out each plug well using the compressed air blow gun.
• Remove each spark plug using the 5/8" spark plug socket, wobble extension, and 3/8" ratchet.
• Install new plugs by hand first, then torque with a torque wrench: Torque to 18 N·m (13 ft-lbs).
• Add a small amount of dielectric grease inside each coil boot, reinstall coils, and torque coil bolts: Torque to 10 N·m (7 ft-lbs).
• Reconnect all coil connectors until they click.

Step 7: Reinstall the upper intake manifold and throttle body

• Install new upper intake manifold gaskets into place (match them to the grooves/locators).
• Set the upper intake manifold back on evenly by hand.
• Tighten upper intake manifold fasteners using a 12mm socket in a crisscross pattern: Torque to 22 N·m (16 ft-lbs).
• Install a new throttle body gasket, then reinstall the throttle body using a 10mm socket: Torque to 12 N·m (9 ft-lbs).
• Reconnect the throttle body connector and any vacuum hoses/connectors you removed.

Step 8: Reassemble intake ducting and reconnect the battery

• Reinstall the intake ducting using a Phillips screwdriver and 10mm socket.
• Reinstall the engine cover by pressing it onto its grommets.
• Reconnect the battery negative cable using a 10mm socket.

---

✅ After Repair

• Start the engine and let it idle for 2–3 minutes. It may idle slightly high for a short time after intake/throttle work.
• Listen for hissing (vacuum leak sound). If you hear it, re-check the hoses and intake seating.
• Test drive 10 minutes, then recheck for warning lights and any fuel smell.
• If a check engine light comes on, don’t keep driving—scan the codes and I’ll help you pinpoint what was missed.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $90-$220 (parts only)

You Save: $360-$630 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.5-4.0 hours.

---
