🔧 Escape - Spark Plug Replacement

Replacing the spark plugs on your Escape helps restore smooth idle, easy starting, fuel economy, and proper turbocharged engine performance. This job involves removing the ignition coils, replacing all four spark plugs, and reinstalling everything carefully so the threads and coils are not damaged.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool completely before starting; spark plugs thread into the aluminum cylinder head and can be damaged if removed hot.
• ⚠️ Disconnect the negative battery cable before unplugging ignition coil connectors.
• ⚠️ Work on one spark plug at a time so debris does not fall into open plug wells.
• ⚠️ Do not use anti-seize unless the spark plug manufacturer specifically requires it; most modern plugs are pre-coated.
• ⚠️ Do not over-tighten spark plugs; the cylinder head is aluminum and the threads can strip.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 8mm socket
• 10mm socket
• 3/8-inch drive ratchet
• 3/8-inch drive 6-inch extension
• 5/8-inch spark plug socket
• Torque wrench inch-pound range
• Torque wrench foot-pound range
• Plastic trim tool
• Compressed air blow gun
• Spark plug gap gauge
• Dielectric grease
• Clean shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Iridium spark plugs - Qty: 4
• Ignition coil boots - Qty: 4

---

📋 Before You Begin

• 🅿️ Park your Escape on level ground, shift to Park, and set the parking brake.
• ❄️ Make sure the engine is fully cool before removing spark plugs.
• 🔋 Use a 10mm socket to disconnect the negative battery cable and move it aside so it cannot touch the battery post.
• 🧽 Clean around the engine cover and ignition coil area before opening anything.
• ℹ️ A spark plug socket is a deep socket with a rubber insert or magnet that holds the spark plug so it does not drop.
• ℹ️ Dielectric grease is a non-conductive silicone grease used inside ignition boots to help prevent moisture and sticking.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the Engine Cover

• Use your hands and a plastic trim tool to gently lift the engine cover upward from its rubber mounting grommets.
• Set the cover aside in a safe place.
• Pull straight up, not sideways.

Step 2: Locate the Ignition Coils

• The four ignition coils sit on top of the engine, one coil above each spark plug.
• Use compressed air blow gun and safety glasses to blow dirt away from the coil and spark plug areas.
• This keeps debris from falling into the engine when a spark plug is removed.

Step 3: Disconnect the First Ignition Coil

• Start with one coil only.
• Use your fingers to press the electrical connector lock tab, then pull the connector straight off the ignition coil.
• If it is stubborn, use a plastic trim tool gently at the connector body, not on the wires.
• Never pull on the wires.

Step 4: Remove the First Ignition Coil

• Use an 8mm socket, 3/8-inch drive ratchet, and 3/8-inch drive 6-inch extension to remove the ignition coil hold-down bolt.
• Twist the ignition coil gently by hand to loosen the rubber boot.
• Pull the coil straight upward and remove it from the spark plug well.
• Inspect the boot for oil, cracks, carbon tracking, or swelling.
• If replacing the boot, pull the old boot off the coil by hand and install the new ignition coil boot fully onto the coil.

Step 5: Clean the Spark Plug Well

• Use compressed air blow gun and safety glasses to blow out the spark plug well before loosening the spark plug.
• Look down the well with a light if available to make sure no dirt or debris remains.
• Clean first, remove second.

Step 6: Remove the Old Spark Plug

• Use a 5/8-inch spark plug socket, 3/8-inch drive 6-inch extension, and 3/8-inch drive ratchet to loosen the spark plug counterclockwise.
• Once loose, turn it out slowly until it comes free.
• Lift the old spark plug out carefully using the spark plug socket.
• If the plug feels tight after breaking loose, stop and turn it slightly back in, then out again slowly.
• Do not force aluminum threads.

Step 7: Check the New Spark Plug

• Use a spark plug gap gauge to verify the new plug gap is correct before installation.
• For your Escape, set/verify spark plug gap at 0.028 in to 0.031 in.
• Do not pry hard on iridium spark plug tips; the fine center electrode can be damaged.
• Compare the new spark plug to the old one to confirm thread length and connector style match.

Step 8: Install the New Spark Plug by Hand

• Place the new spark plug into the 5/8-inch spark plug socket.
• Use only the 3/8-inch drive 6-inch extension by hand at first, without the ratchet.
• Thread the spark plug clockwise into the cylinder head by hand until it seats lightly.
• If it does not turn smoothly, remove it and start again.
• Hand-start prevents cross-threading.

Step 9: Torque the New Spark Plug

• Attach the torque wrench foot-pound range to the 5/8-inch spark plug socket and 3/8-inch drive 6-inch extension.
• Tighten the spark plug to Torque to 15 Nm (11 ft-lbs).
• Do not add extra tightening after the torque wrench clicks.

Step 10: Reinstall the Ignition Coil

• Apply a small pea-sized amount of dielectric grease inside the end of the ignition coil boot.
• Push the ignition coil straight down onto the spark plug until it fully seats.
• Use an 8mm socket, 3/8-inch drive ratchet, and torque wrench inch-pound range to reinstall the coil hold-down bolt.
• Tighten the ignition coil bolt to Torque to 6 Nm (53 in-lbs).
• Reconnect the electrical connector until it clicks.

Step 11: Repeat for the Other Three Spark Plugs

• Use the same 8mm socket, 5/8-inch spark plug socket, 3/8-inch drive 6-inch extension, and torque wrenches to replace the remaining spark plugs one at a time.
• Always clean each spark plug well with compressed air blow gun before removing the old plug.
• Torque each spark plug to Torque to 15 Nm (11 ft-lbs).
• Torque each ignition coil bolt to Torque to 6 Nm (53 in-lbs).

Step 12: Reinstall the Engine Cover and Battery Cable

• Use your hands to line up the engine cover with the rubber grommets and press it straight down until seated.
• Use a 10mm socket and torque wrench inch-pound range to reconnect the negative battery cable.
• Tighten the negative battery terminal to Torque to 5 Nm (44 in-lbs).

---

✅ After Repair

• ✅ Start your Escape and let it idle for a few minutes.
• ✅ Listen for smooth idle and check that the engine does not shake or misfire.
• ✅ If the check engine light was on before, use a scan tool to clear codes after confirming the engine runs correctly.
• ✅ Take a short test drive with light acceleration first, then moderate acceleration.
• ✅ Recheck that all ignition coil connectors are fully clicked into place if the engine runs rough.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$420 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $175-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-1.5 hours.

---
