🔧 Sorento - Spark Plug Replacement

On your Sorento’s 3.3L V6, there are 6 spark plugs (3 in the front bank, 3 in the rear bank). The front bank is straightforward, but the rear bank usually requires removing the upper intake manifold (plenum) to access the ignition coils and plugs.

Difficulty Level: Intermediate | Estimated Time: 2.5-4.5 hours

Assumption: Standard 3.3L V6 layout where rear plugs require plenum removal.

---

⚠️ Safety & Precautions

• ⚠️ Work on a cold engine to avoid burns and damaged threads.
• ⚠️ Disconnect the negative battery terminal before unplugging coils/sensors.
• ⚠️ Keep dirt out of the intake—cover open ports with clean rags immediately.
• ⚠️ Do not mix up ignition coil connectors; label them if needed.
• ⚠️ If a plug feels stuck, stop and use penetrant—don’t force it.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 10mm socket
• 12mm socket
• 14mm socket
• 3/8" ratchet
• 3/8" torque wrench (10-30 Nm range)
• 3/8" extension set (3", 6", 10")
• 3/8" swivel adapter
• 5/8" spark plug socket
• Flathead screwdriver
• Hose clamp pliers
• Trim clip removal tool
• Small pick tool
• Compressed air blow gun
• Shop vacuum
• Painter’s tape and marker
• OBD2 scan tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs (iridium, OEM-equivalent) - Qty: 6
• Upper intake manifold (plenum) gasket set - Qty: 1
• Throttle body gasket - Qty: 1
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and let the engine cool fully.
• Use a 10mm socket to disconnect the negative battery terminal and isolate it so it can’t spring back.
• Use painter’s tape and marker to label any hoses/connectors you remove.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover

• Pull up firmly on the engine cover to release the rubber grommets (no tools on most setups).
• Set it aside where it won’t get stepped on.

Step 2: Remove the air intake duct (to access the throttle body area)

• Use a flathead screwdriver to loosen the hose clamps.
• Disconnect any small breather hose(s) using hose clamp pliers.
• Lift the duct out.

Step 3: Replace the FRONT bank spark plugs (the easy side)

• Unplug one ignition coil connector at a time (press the lock tab; use a small pick tool gently if needed).
• Remove the coil hold-down bolt with a 10mm socket and pull the coil straight up.
• Blow out the plug well using compressed air blow gun so debris can’t fall into the cylinder.
• Remove the spark plug using a 5/8" spark plug socket, 3/8" ratchet, and extension.
• Install the new plug by hand first using the spark plug socket and an extension (no ratchet at first). Hand-threading prevents cross-threading.
• Tighten with a torque wrench: Torque to 18-22 Nm (13-16 ft-lbs).
• Put a small smear of dielectric grease inside the coil boot (dielectric grease is a non-conductive grease that helps prevent moisture and future sticking).
• Reinstall the coil and tighten the bolt: Torque to 8-10 Nm (71-89 in-lbs).
• Reconnect the coil connector and repeat for the other two front cylinders.

Step 4: Remove the upper intake manifold (plenum) to access the REAR bank

• Disconnect the throttle body electrical connector and any nearby sensor connectors using your hands; use a small pick tool only if the lock tab is stubborn.
• Remove vacuum/PCV hoses attached to the plenum using hose clamp pliers; label them with painter’s tape.
• If any wiring clips are attached to the plenum, release them using a trim clip removal tool.
• Remove plenum mounting bolts/nuts using a 12mm socket (and 10mm socket if equipped in your layout).
• Carefully lift the plenum up and off without forcing it.
• Immediately place clean rags into the intake ports and use a shop vacuum to clean around the area.

Step 5: Replace the REAR bank spark plugs

• Unplug the three rear ignition coil connectors.
• Remove each coil bolt with a 10mm socket, then pull the coil straight up.
• Blow out each plug well using compressed air blow gun.
• Remove each plug using a 5/8" spark plug socket, extension, and swivel adapter as needed for angle.
• Install each new plug by hand first, then torque with a torque wrench: Torque to 18-22 Nm (13-16 ft-lbs).
• Add a small amount of dielectric grease inside each coil boot, reinstall coils, and torque coil bolts: Torque to 8-10 Nm (71-89 in-lbs).
• Reconnect the coil connectors.

Step 6: Reinstall the plenum with new gaskets

• Remove the old plenum gasket(s) and install the new upper intake manifold gasket set.
• Set the plenum back in place carefully, making sure no hoses or wires are pinched.
• Install plenum bolts/nuts finger-tight first, then snug evenly.
• Tighten with a torque wrench: Torque to 18-22 Nm (13-16 ft-lbs).
• Reconnect all vacuum/PCV hoses and electrical connectors.

Step 7: Reinstall the intake duct and engine cover

• Reinstall the air intake duct and tighten clamps with a flathead screwdriver.
• Reconnect any breather hose(s) using hose clamp pliers.
• Push the engine cover back onto its mounting grommets.

Step 8: Reconnect battery and quick checks

• Reconnect the negative battery terminal using a 10mm socket.
• Use an OBD2 scan tool to check/clear any stored codes if needed.

---

✅ After Repair

• Start the engine and let it idle for 2-3 minutes.
• Listen for hissing (vacuum leak) and check that idle is smooth.
• Verify no check engine light is on; scan with an OBD2 scan tool if it is.
• Take a short test drive and recheck for any loose clamps or oil/vacuum smell under the hood.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$700 (parts + labor)

DIY Cost: $70-$220 (parts only)

You Save: $280-$480 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.5-4.5 hours.

---
