🔧 Veloster - Spark Plug Replacement

Replacing the spark plugs restores strong ignition, helps prevent misfires, and keeps your turbo engine running smoothly. On your Veloster, the plugs sit under individual ignition coils on top of the engine, so this is a straightforward job once access is cleared.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a fully cool engine; hot aluminum threads can strip easily.
• ⚠️ Disconnect the negative battery cable to avoid accidental shorts and to protect the ignition system.
• ⚠️ Keep dirt out of the spark plug wells—debris can fall into the cylinder and cause engine damage.
• ⚠️ Do not use anti-seize unless the spark plug manufacturer specifically says to; most modern plugs are nickel-coated and anti-seize can cause over-tightening.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 3/8" ratchet
• 3/8" extension set (3" and 6")
• 5/8" spark plug socket
• Torque wrench (3/8", 5-60 Nm range)
• Flathead screwdriver
• Trim clip removal tool
• Needle-nose pliers
• Feeler gauge set (inch/mm)
• Compressed air blow gun
• Shop vacuum
• Nitrile gloves
• Safety glasses
• Fender cover

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs (OEM-spec iridium for 1.6L turbo) - Qty: 4
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and open the hood.
• Let the engine cool completely (at least 1 hour after driving).
• Disconnect the battery negative terminal using a 10mm socket and move the cable aside.
• Take a quick photo before removing hoses.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover / access panels

• Remove any top engine cover/ducting by releasing clips with a trim clip removal tool and loosening any clamps with a flathead screwdriver.
• If your Veloster has top-mounted charge-air/intercooler ducting over the coil area, loosen hose clamps with a flathead screwdriver and remove the ducting for clear access.

Step 2: Unplug and remove the ignition coils

• Locate the 4 ignition coils on top of the valve cover (one per cylinder).
• Press the electrical connector tab and unplug each coil connector. If it’s stubborn, use needle-nose pliers gently—don’t pull on the wires.
• Remove each coil hold-down bolt using a 10mm socket and 3/8" ratchet.
• Twist the coil slightly and pull straight up to remove it. (An ignition coil is the part that makes the high voltage for the spark plug.)
• Torque to 9 Nm (80 in-lbs) when reinstalling the coil bolts.

Step 3: Clean the spark plug wells

• Use a shop vacuum around each spark plug well to remove loose dirt.
• Blow out each spark plug well using a compressed air blow gun while wearing safety glasses.

Step 4: Remove the old spark plugs

• Install a 5/8" spark plug socket on a 3/8" extension and 3/8" ratchet.
• Loosen and remove each spark plug counterclockwise.
• If a plug feels like it’s binding, stop and work it back and forth gently to avoid damaging threads.

Step 5: Check the new plug gap (if applicable) and prep the coils

• Use a feeler gauge set (inch/mm) to verify the gap matches the spec provided with the OEM-spec plugs for your Veloster turbo. Don’t force-bend fine-wire iridium tips.
• Apply a small dab of dielectric grease inside each coil boot (the rubber “socket” that seals to the plug).

Step 6: Install the new spark plugs

• Start each spark plug by hand first (use the spark plug socket and extension without the ratchet) and turn clockwise several full turns to ensure it’s not cross-threaded.
• Tighten with a torque wrench (3/8", 5-60 Nm range).
• Torque to 18 Nm (13 ft-lbs) for the OEM-style gasket-seat plugs used on this engine.

Step 7: Reinstall the ignition coils and reconnect everything

• Reinstall each coil straight down onto its spark plug.
• Install the coil bolts using a 10mm socket and tighten with a torque wrench: Torque to 9 Nm (80 in-lbs).
• Reconnect all coil electrical connectors until they click.
• Reinstall any ducting/covers removed earlier, tightening clamps with a flathead screwdriver and reinstalling clips with a trim clip removal tool.
• Reconnect the battery negative terminal using a 10mm socket.

---

✅ After Repair

• Start the engine and let it idle for 30–60 seconds; it should run smooth with no shaking.
• Listen for any hissing (intake/boost leak) if you removed charge-air ducting.
• Take a short test drive and confirm normal power delivery and no check-engine light.
• If a check-engine light appears, recheck coil connectors and that every coil is fully seated.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $40-$120 (parts only)

You Save: $130-$410 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
