🔧 Outback - Spark Plug Replacement

On your Outback, the spark plugs sit on the sides of the engine and are a bit tight to reach. You’ll remove a few nearby components for access, swap the plugs one at a time, and reinstall everything with the correct torque so the threads in the cylinder head don’t get damaged.

Difficulty Level: Intermediate | Estimated Time: 1.5–3.0 hours

---

⚠️ Safety & Precautions

• 🛑 Work on a fully cool engine to avoid burns and thread damage.
• 🛑 Don’t over-tighten spark plugs; the cylinder head is aluminum.
• 🛑 If you remove the battery, disconnect the negative terminal first and reconnect it last.
• 🛑 Keep dirt out of the spark plug holes; blow them out before removing plugs.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 10mm socket
• 12mm socket
• 3/8" ratchet
• 3/8" torque wrench (5–30 ft-lbs range)
• 14mm thin-wall spark plug socket (magnetic or rubber insert)
• 3/8" 3" extension
• 3/8" 6" extension
• 3/8" wobble extension
• 3/8" universal joint
• Flathead screwdriver
• Phillips screwdriver
• Needle-nose pliers
• Compressed air blow gun
• Spark plug gap gauge
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs (iridium, correct spec for your Outback) - Qty: 4
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and open the hood.
• Let the engine cool completely (at least 1 hour after driving).
• If you’ll remove the battery for access: use a 10mm socket to disconnect the negative terminal first.
• Do one cylinder at a time.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the air intake duct and air box (for access)

• Use a flathead screwdriver to loosen the intake hose clamp(s).
• Unclip/unbolt the air box as needed using a 10mm socket and Phillips screwdriver.
• Lift the duct/air box out carefully and set it aside.

Step 2: Remove the battery (if needed for access on that side)

• Use a 10mm socket to disconnect the negative terminal, then the positive.
• Remove the battery hold-down using a 10mm socket.
• Lift the battery out carefully (it’s heavy).

Step 3: Locate the ignition coils and unplug them

• Each cylinder has an ignition coil (the electrical module bolted above the spark plug).
• Press the connector tab and unplug the coil connector by hand; use needle-nose pliers only if needed and gently.

Step 4: Remove the ignition coil(s)

• Use a 12mm socket to remove the coil retaining bolt.
• Twist the coil slightly and pull it straight out.
• Torque to 10 Nm (7 ft-lbs) when reinstalling the coil bolt.

Step 5: Clean the spark plug well

• Use compressed air blow gun to blow debris out around the spark plug.
• This helps keep dirt from falling into the cylinder when the plug comes out.

Step 6: Remove the old spark plug

• Install the 14mm thin-wall spark plug socket with a 3/8" wobble extension (or universal joint) and a 3/8" ratchet.
• Turn counterclockwise to loosen, then remove the plug.
• If it feels extremely tight, stop and work it back-and-forth gently to avoid stripping threads.

Step 7: Check and prepare the new spark plug

• Use a spark plug gap gauge to confirm the gap matches spec for your Outback (most iridium plugs are pre-gapped).
• Do not use anti-seize unless the plug manufacturer specifically requires it.
• Apply a tiny amount of dielectric grease inside the ignition coil boot (this helps prevent moisture and makes future removal easier).

Step 8: Install the new spark plug (hand-thread first)

• Place the new plug into the 14mm spark plug socket and carefully lower it into the hole.
• Thread it in by hand using the extension only (no ratchet at first) until it seats smoothly.
• Use a 3/8" torque wrench to tighten: Torque to 21 Nm (15 ft-lbs).

Step 9: Reinstall the ignition coil

• Push the coil straight onto the spark plug until fully seated.
• Install the coil bolt using a 12mm socket.
• Tighten with a 3/8" torque wrench: Torque to 10 Nm (7 ft-lbs).
• Plug the electrical connector back in until it clicks.

Step 10: Repeat for the remaining spark plugs

• Repeat Steps 3–9 for each cylinder, one at a time.
• Keep coils with their original cylinder.

Step 11: Reinstall the air box/duct and battery

• Reinstall the intake/air box using a 10mm socket and tighten clamps with a flathead screwdriver.
• If removed, reinstall the battery and hold-down using a 10mm socket.
• Reconnect battery terminals: positive first, negative last using a 10mm socket.

---

✅ After Repair

• Start the engine and let it idle for 1–2 minutes; it should run smooth with no shaking.
• Check that no warning lights appear and listen for any hissing (intake hose not fully clamped).
• If the check engine light is on or it misfires, recheck each coil connector and coil seating.

---

💰 DIY vs Shop Cost

Shop Cost: $300–$550 (parts + labor)

DIY Cost: $40–$90 (parts only)

You Save: $260–$460 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5–2.5 hours.

---
