🔧 Civic - Spark Plug Replacement

On your Civic, the spark plugs sit under the ignition coils on top of the engine. Replacing them restores smooth starting, idle quality, and fuel economy, especially if they’re due by mileage or you’re feeling a misfire.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a fully cool engine to avoid burns and damaged threads.
• ⚠️ Keep dirt out of the spark plug holes; debris can damage the engine.
• ⚠️ Do not overtighten spark plugs; aluminum cylinder head threads strip easily.
• ⚠️ Battery disconnect is not required, but keep the key off and headlights off.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 3/8" drive ratchet
• 3/8" drive torque wrench (5-30 ft-lbs range)
• 10mm socket
• 5/8" spark plug socket
• 3/8" drive extension (6")
• Small flat trim tool
• Compressed air blow gun
• Feeler gauge (0.039"-0.043")

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Iridium spark plugs (correct fit for Civic 1.8L) - Qty: 4
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and let the engine cool completely.
• Open the hood and remove any loose items around the engine bay.
• Have your new plugs ready and keep them in the box until install to avoid dropping them.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover (if equipped)

• If your Civic has a top plastic cover, remove it using a small flat trim tool to release clips, then lift it off by hand.

Step 2: Unplug the ignition coils

• Locate the 4 ignition coils on top of the engine (one per cylinder).
• Press the connector lock tab and pull each connector off by hand; use a small flat trim tool gently if the tab is stubborn.
• Pull on the connector body, not the wires.

Step 3: Remove the ignition coils

• Remove each coil hold-down bolt using a 10mm socket and 3/8" drive ratchet.
• Lift the coil straight up and out. (An ignition coil is the pencil-shaped part that sits on the spark plug.)
• Set coils aside in order so they go back to the same cylinder.

Step 4: Clean around the spark plug tubes

• Blow out each spark plug well using a compressed air blow gun.
• This prevents dirt from falling into the cylinder when the plug comes out.

Step 5: Remove the old spark plugs

• Install the 5/8" spark plug socket onto a 3/8" drive extension (6") and 3/8" drive ratchet.
• Lower the socket straight down onto the plug and loosen counterclockwise.
• Once loose, keep turning until the plug comes out; lift it out carefully.

Step 6: Check the new spark plug gap

• Use a feeler gauge (0.039"-0.043") to verify the gap is within spec.
• If the plugs are iridium (most are), do not pry on the tiny center tip; if a gap is off, exchange the plug.

Step 7: Install the new spark plugs by hand first

• Place a new plug into the 5/8" spark plug socket (the rubber insert should hold it).
• Thread it in by hand using only the 3/8" drive extension (6") (no ratchet at first) until it seats.
• If it doesn’t spin easily, back out and retry.
• Tighten with a torque wrench: Torque to 18 Nm (13 ft-lbs) using a 3/8" drive torque wrench.
• No anti-seize needed on plated plugs.

Step 8: Reinstall ignition coils

• Put a small smear of dielectric grease inside the end of each coil boot (dielectric grease helps prevent moisture and makes future removal easier).
• Push each coil straight down onto the plug until fully seated.
• Install the coil hold-down bolt using a 10mm socket, then torque it: Torque to 12 Nm (9 ft-lbs) using a 3/8" drive torque wrench.

Step 9: Reconnect electrical connectors and reinstall cover

• Reconnect each coil connector until it clicks into place.
• Reinstall the engine cover (if equipped) by hand and snap clips back in.

---

✅ After Repair

• Start the engine and let it idle for 30-60 seconds; it should run smooth with no shaking.
• Listen for a ticking sound (could indicate a loose plug) and recheck torque if needed.
• Take a short test drive and confirm there’s no flashing check engine light.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$450 (parts + labor)

DIY Cost: $40-$120 (parts only)

You Save: $180-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.0 hours.

---
