🔧 Enclave - Spark Plug Replacement

Replacing spark plugs on your Enclave restores smooth running, helps fuel economy, and prevents misfires. On the 3.6L V6, the front bank is easy to reach, and the rear bank usually requires removing the upper intake manifold to access the ignition coils and plugs.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cold engine to avoid burns and damaged threads.
• ⚠️ Disconnect the negative battery cable before unplugging coils/sensors.
• ⚠️ Keep dirt out of the intake ports; cover openings immediately.
• ⚠️ Do not overtighten spark plugs; aluminum heads strip easily.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 7mm socket
• 8mm socket
• Ratchet 3/8"
• Torque wrench 3/8" (10-30 Nm range)
• 5/8" spark plug socket
• 3/8" extension set (3", 6", 10")
• 3/8" swivel/universal joint
• Flat-blade screwdriver
• Pliers
• Trim clip removal tool
• Pick tool
• Compressed air blow gun
• Shop vacuum
• Clean shop rags
• Masking tape and marker
• Nitrile gloves
• Safety glasses
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs (iridium, OEM-equivalent) - Qty: 6
• Upper intake manifold gasket set - Qty: 1
• Throttle body gasket - Qty: 1
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Let the engine cool fully (at least 1 hour after driving).
• Use a 10mm socket to disconnect the negative battery cable and tuck it aside.
• Use masking tape and marker to label any hoses/connectors you remove. Helps a lot during reassembly.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover and intake duct

• Lift up to remove the engine cover (it’s pressed onto rubber grommets).
• Loosen the intake hose clamps using a flat-blade screwdriver (or use a 7mm socket if clamp is a hex-head style).
• Unclip/unplug any intake duct sensors using a pick tool carefully (don’t pry on the wires).
• Remove the intake duct and set it aside.

Step 2: Replace the FRONT bank spark plugs (radiator side)

• Unplug the ignition coil electrical connector(s) by releasing the lock tab using a pick tool.
• Remove each ignition coil bolt using a 10mm socket.
• Pull the coil straight up and out (a gentle twist helps).
• Blow out the spark plug well using compressed air blow gun to keep debris from falling into the cylinder.
• Remove the spark plug using a 5/8" spark plug socket, 3/8" ratchet, and a 3/8" extension.
• Install the new spark plug by hand first using the spark plug socket and extension (no ratchet at first). Prevents cross-threading.
• Tighten using a torque wrench 3/8": Torque to 22 Nm (16 ft-lbs).
• Apply a small amount of dielectric grease inside the coil boot (the rubber part).
• Reinstall the coil and tighten the coil bolt: Torque to 10 Nm (89 in-lbs).
• Reconnect the coil electrical connector until it clicks.

Step 3: Access the REAR bank spark plugs (firewall side)

• On the 3.6L, rear plugs are typically under/behind the upper intake manifold.
• Label vacuum lines and electrical connectors using masking tape and marker.
• Disconnect vacuum hoses using pliers as needed (twist first, then pull).
• Unplug any intake manifold/throttle body connectors using a pick tool to release locks.
• If the throttle body is in the way, remove it using an 8mm socket and set it aside (do not stress the wiring).

Step 4: Remove the upper intake manifold (rear bank access)

• Remove the upper intake manifold bolts using a 10mm socket and 3/8" ratchet.
• Lift the manifold straight up and off.
• Immediately place clean shop rags in the exposed intake ports so nothing falls in.
• Remove and discard the old intake manifold gaskets.

Step 5: Replace the REAR bank spark plugs (firewall side)

• Unplug coil connectors using a pick tool.
• Remove coil bolts using a 10mm socket and pull coils out.
• Blow out each spark plug well using the compressed air blow gun.
• Remove spark plugs using a 5/8" spark plug socket, 3/8" extension set, and a 3/8" swivel/universal joint (this helps with the tight angle).
• Install new spark plugs by hand first, then tighten with a torque wrench 3/8": Torque to 22 Nm (16 ft-lbs).
• Add a small amount of dielectric grease inside each coil boot.
• Reinstall coils and tighten bolts: Torque to 10 Nm (89 in-lbs).
• Reconnect coil connectors until they click.

Step 6: Reinstall the upper intake manifold and throttle body

• Remove the rags from the intake ports and use a shop vacuum to confirm nothing is inside.
• Install new upper intake manifold gaskets into the manifold grooves.
• Set the manifold into place carefully.
• Tighten upper intake manifold bolts with a torque wrench 3/8": Torque to 25 Nm (18 ft-lbs).
• If removed, install a new throttle body gasket and reinstall the throttle body using an 8mm socket.
• Tighten throttle body bolts with a torque wrench 3/8": Torque to 10 Nm (89 in-lbs).
• Reconnect all hoses and electrical connectors (match your labels).

Step 7: Reinstall the intake duct and engine cover

• Reinstall the intake duct and tighten clamps using a flat-blade screwdriver (or 7mm socket).
• Reconnect any sensors you unplugged.
• Press the engine cover back onto its grommets.
• Reconnect the negative battery cable using a 10mm socket.

---

✅ After Repair

• Start the engine and let it idle for 1-2 minutes; it should run smooth.
• Check for a hissing sound (vacuum leak) around the intake manifold area.
• If you have a check engine light, scan for codes and verify all coil connectors are fully seated.
• Test drive 10 minutes and recheck for warning lights.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$750 (parts + labor)

DIY Cost: $70-$180 (parts only)

You Save: $270-$680 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
