🔧 Focus - Spark Plug Replacement

Your Focus uses coil-on-plug ignition (one coil sits on each spark plug). Replacing the plugs helps prevent misfires, rough running, and poor fuel economy, and it’s important on the 2.0L because the plugs live deep in the cylinder head and wear over time.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool fully before starting; hot aluminum threads can strip.
• ⚠️ Keep dirt out of the spark plug holes; debris can damage the engine.
• ⚠️ Disconnect the negative battery terminal to reduce the chance of electrical damage.
• ⚠️ Do not use anti-seize on Ford’s plated spark plug threads unless the plug maker specifically requires it.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" ratchet
• 3/8" ratchet
• 6" socket extension
• 8mm socket
• 5/8" (16mm) spark plug socket
• Torque wrench (inch-lb)
• Torque wrench (ft-lb)
• Trim clip/pick tool
• Compressed air blow gun
• Shop vacuum
• Feeler gauge set (spark plug gap)
• Dielectric grease
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs (OEM-equivalent iridium, correct heat range) - Qty: 4
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and open the hood.
• Let the engine cool until you can comfortably touch the top of the engine.
• Disconnect the battery negative terminal using a 10mm socket and tuck the cable aside so it can’t spring back.
• Work one cylinder at a time.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover (if equipped)

• Lift the cover straight up by hand. If it’s tight, gently help it with a trim clip/pick tool at the corners.

Step 2: Unplug and remove ignition coil #1

• Locate the first ignition coil (the coil is the “stick” sitting on top of the valve cover).
• Release the electrical connector lock using a trim clip/pick tool, then pull the connector off by hand.
• Remove the coil hold-down bolt using an 8mm socket and 1/4" ratchet.
• Twist the coil gently, then pull it straight up to remove it.
• Don’t yank the wiring.

Step 3: Clean the spark plug well

• Blow out the spark plug tube using compressed air blow gun.
• If you see sand/grit, vacuum around the opening with a shop vacuum before removing the plug.

Step 4: Remove the spark plug

• Install a 5/8" (16mm) spark plug socket with a 6" socket extension and 3/8" ratchet.
• Turn counterclockwise to loosen, then lift the plug out carefully.
• If it feels stuck, stop and re-tighten slightly, then loosen again slowly.

Step 5: Check the new plug gap (don’t bend the fine tip)

• Use a feeler gauge set (spark plug gap) to verify the gap matches the Ford underhood emissions label spec for your Focus.
• If the plug is iridium, avoid forcing the tool against the tiny center tip.
• Most iridium plugs come pre-gapped.

Step 6: Install the new spark plug

• Start threading the plug by hand using the spark plug socket and extension only (no ratchet at first) to avoid cross-threading.
• Once finger-tight, torque the spark plug with a torque wrench (ft-lb): Torque to 15 Nm (11 ft-lbs).

Step 7: Reinstall the ignition coil

• Apply a small dab of dielectric grease inside the coil boot (this helps prevent moisture and eases future removal).
• Push the coil straight down until fully seated.
• Install the coil bolt using an 8mm socket, then torque with a torque wrench (inch-lb): Torque to 7 Nm (62 in-lbs).
• Reconnect the coil electrical connector until it clicks.

Step 8: Repeat for the remaining cylinders

• Repeat Steps 2–7 for the other three coils and plugs, one at a time.

Step 9: Reconnect the battery and reinstall the cover

• Reconnect the negative battery terminal using a 10mm socket.
• Reinstall the engine cover by pressing it down into place by hand.

---

✅ After Repair

• Start the engine and let it idle for 30–60 seconds. It should run smooth with no shaking.
• If the check engine light is on or it runs rough, re-check that each coil connector is fully latched and each coil is seated.
• Test drive for 10 minutes, then recheck for any warning lights.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $40-$90 (parts only)

You Save: $160-$410 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
