🔧 F-250 Super Duty - Spark Plug Replacement

Your F-250 uses one ignition coil per cylinder (called a coil-on-plug, or COP). Replacing the spark plugs restores smooth starting, power, and fuel economy, and helps prevent misfires.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

Assumption: stock intake/engine bay accessories.

---

⚠️ Safety & Precautions

• ⚠️ Work on a fully cool engine to avoid burns and protect aluminum threads.
• ⚠️ Keep dirt out of the spark plug holes—blow debris away before removing plugs.
• ⚠️ Do not over-tighten spark plugs; the cylinder heads are aluminum.
• ⚠️ Battery disconnect is not required, but remove the key and keep it away from the truck.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Work light
• Shop towels
• 1/4" drive ratchet
• 3/8" drive ratchet
• 1/4" drive extension set (3" and 6")
• 3/8" drive extension set (6" and 10")
• 8mm socket
• 10mm socket
• 5/8" spark plug socket
• Torque wrench (inch-pound, 20–200 in-lb)
• Torque wrench (foot-pound, 10–80 ft-lb)
• Small flat screwdriver
• Needle-nose pliers
• Compressed air blow gun
• Feeler gauge (for spark plug gap)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs (6.2L V8) - Qty: 8
• Dielectric grease - Qty: 1
• Ignition coil boots (optional, if boots are swollen/torn) - Qty: 8

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and let the engine cool completely.
• Lay out 8 plugs in order and work one cylinder at a time to avoid mixing parts.
• If you use compressed air, wear safety glasses.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover (if equipped)

• Pull up on the cover to release the rubber grommets (use your hands).
• Set it aside where it won’t get stepped on.

Step 2: Create working room where needed

• On the tighter side, loosen any intake tube clamps using an 8mm socket and move the tube aside if it blocks access.
• Release stubborn hose clips with a small flat screwdriver and reposition hoses gently.
• Take a quick photo before moving hoses.

Step 3: Unplug one ignition coil (COP) connector

• Pick one cylinder to start with.
• Press the connector lock tab and unplug it (use your fingers or needle-nose pliers gently if needed).

Step 4: Remove the ignition coil

• Remove the coil hold-down bolt using a 8mm socket and 1/4" drive ratchet.
• Twist the coil slightly, then pull straight up to remove it.
• During install later: Torque the coil bolt to 7 Nm (62 in-lb).

Step 5: Clean the spark plug well

• Blow compressed air down around the plug using a compressed air blow gun.
• This prevents dirt from falling into the cylinder when the plug comes out.

Step 6: Remove the old spark plug

• Use a 5/8" spark plug socket with a 3/8" drive ratchet and the needed 3/8" drive extensions.
• Turn counterclockwise until the plug is free, then lift it out carefully.
• If it feels extremely tight, stop and work it gently—don’t force it on a hot engine.

Step 7: Check and prepare the new spark plug

• Check the gap using a feeler gauge. (Gap = the small space between the center and ground electrode.)
• Adjust only if the plug manufacturer says it’s allowed; many modern plugs come pre-gapped.
• Do not add anti-seize unless the plug maker specifically requires it (most plated plugs do not).

Step 8: Install the new spark plug (by hand first)

• Start the plug by hand using the 5/8" spark plug socket and an extension (no ratchet at first).
• Thread it in several turns to ensure it’s not cross-threaded.
• Tighten with a torque wrench: Torque the spark plug to 25 Nm (18 ft-lb).

Step 9: Reinstall the ignition coil

• Put a small dab of dielectric grease inside the coil boot (this helps prevent moisture and makes future removal easier).
• Push the coil straight down until fully seated on the plug.
• Install the bolt using an 8mm socket, then Torque to 7 Nm (62 in-lb) using an inch-pound torque wrench.
• Reconnect the coil electrical connector until it clicks.

Step 10: Repeat for the remaining 7 cylinders

• Work one cylinder at a time so no connectors or bolts get mixed up.
• Use the same process: unplug coil → remove coil → blow out well → remove plug → install new plug → reinstall coil.

Step 11: Reassemble intake items and engine cover

• Reinstall any intake tube(s) you moved and tighten clamps using an 8mm socket.
• Press the engine cover back onto its grommets (use your hands).

---

✅ After Repair

• Start the engine and let it idle for 30–60 seconds. It should run smooth with no shaking.
• Listen for a ticking/air leak near any intake tube you moved; tighten with an 8mm socket if needed.
• If the check engine light comes on or it misfires, re-check that every coil connector is fully clicked in and every coil is seated.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$700 (parts + labor)

DIY Cost: $80-$180 (parts only)

You Save: $270-$520 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
