🔧 Grand Caravan - Spark Plug Replacement

On your Grand Caravan’s 3.6L V6, the front-row spark plugs are easy to reach, but the rear-row plugs sit under the upper intake manifold. You’ll remove the ignition coils, swap the plugs, then reassemble carefully to prevent vacuum leaks and misfires.

Difficulty Level: Advanced | Estimated Time: 2.5-4.0 hours

Assumption: Stock 3.6L layout; rear bank requires upper intake removal.

---

⚠️ Safety & Precautions

• 🧯 Work on a fully cool engine to avoid burns and stripped threads.
• 🔋 Disconnect the negative battery cable to prevent accidental shorts.
• 👓 Wear safety glasses; debris can fall when plugs come out.
• 🧼 Keep dirt out of the cylinders—clean around each coil/plug before removal.
• 🧩 Do not over-tighten spark plugs; aluminum heads strip easily.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 10mm wrench
• 10mm socket
• 8mm socket
• 1/4" drive ratchet
• 3/8" drive ratchet
• 3/8" drive torque wrench (10-30 ft-lbs)
• 1/4" drive torque wrench (50-150 in-lbs)
• 3/8" drive extension set (3", 6", 10")
• 1/4" drive extension set (3", 6")
• 3/8" drive universal joint
• 5/8" spark plug socket
• Flat-blade screwdriver
• Hose clamp pliers
• Trim clip removal tool
• Compressed air blow gun
• Feeler gauge set
• Magnetic pickup tool
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs - Qty: 6
• Upper intake manifold gasket set - Qty: 1
• Throttle body gasket - Qty: 1
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• 🅿️ Park on level ground, shift to Park, and set the parking brake.
• 🧊 Let the engine cool completely (at least 1 hour).
• 🔋 Use a 10mm wrench to disconnect the negative battery cable and isolate it so it can’t spring back.
• 🏷️ Label connectors/hoses with tape as you unplug them. This prevents mix-ups later.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover and open up access

• Pull up on the engine cover to pop it off its rubber grommets (no tools).
• Use a flat-blade screwdriver and/or 8mm socket to loosen the air intake hose clamps.
• Disconnect the intake tube and move it aside (use hose clamp pliers where spring clamps are used).

Step 2: Replace the front bank spark plugs (easy-access row)

• Unplug one ignition coil electrical connector at a time (press the lock tab by hand).
• Remove the coil hold-down bolt with a 10mm socket.
• Twist the coil boot gently and pull the coil straight up. (A “coil boot” is the rubber sleeve that seals to the spark plug.)
• Use compressed air blow gun to blow debris out of the spark plug well.
• Remove the spark plug using a 5/8" spark plug socket, 3/8" drive ratchet, and a 3/8" drive extension.
• Check the new plug gap with a feeler gauge set (do not forcefully bend fine-wire tips). Most plugs come pre-gapped.
• Thread the new spark plug in by hand using the 5/8" spark plug socket and extension only (no ratchet at first).
• Tighten with a 3/8" drive torque wrench: Torque to 17 Nm (13 ft-lbs).
• Apply a thin smear of dielectric grease inside the coil boot (a non-conductive grease that helps seal out moisture).
• Reinstall the coil and tighten the coil bolt: Torque to 9 Nm (80 in-lbs) using a 1/4" drive torque wrench.
• Reconnect the coil connector before moving to the next cylinder.

Step 3: Remove the throttle body (to remove the upper intake)

• Unplug the throttle body electrical connector by hand.
• Remove the throttle body mounting bolts using a 8mm socket and 1/4" drive ratchet.
• Remove the throttle body and old gasket; wipe mating surfaces with shop towels.
• Set the throttle body aside gently (do not pull on wiring).

Step 4: Disconnect hoses and connectors on the upper intake manifold

• Use trim clip removal tool to release any wire looms clipped to the intake.
• Disconnect the PCV/EVAP vacuum lines using hose clamp pliers where needed.
• Unplug any intake-mounted sensors/connectors you can’t safely leave attached.
• Place shop towels under areas where small parts could fall.

Step 5: Remove the upper intake manifold (rear plug access)

• Remove the upper intake manifold bolts with a 10mm socket, 1/4" drive ratchet, and extensions.
• Lift the upper intake manifold straight up and out.
• Immediately stuff clean shop towels into the exposed intake ports to prevent dropped hardware entering the engine.

Step 6: Replace the rear bank spark plugs (under the intake)

• Repeat the same process as the front bank: unplug coil, remove coil bolt with 10mm socket, remove coil.
• Blow out each spark plug well using the compressed air blow gun.
• Remove/install plugs using 5/8" spark plug socket, 3/8" drive ratchet, extensions, and a 3/8" drive universal joint as needed.
• Tighten each new plug: Torque to 17 Nm (13 ft-lbs).
• Reinstall coils and tighten coil bolts: Torque to 9 Nm (80 in-lbs).

Step 7: Reinstall the upper intake manifold with new gaskets

• Remove the old intake gaskets from the manifold and install the new upper intake manifold gasket set.
• Remove the shop towels from the intake ports (double-check all ports are clear).
• Set the intake manifold into place carefully, making sure no wires or hoses get pinched.
• Install intake bolts finger-tight first, then tighten evenly with a 10mm socket.
• Final tighten with a 1/4" drive torque wrench: Torque to 12 Nm (105 in-lbs).

Step 8: Reinstall the throttle body and intake tube

• Install a new throttle body gasket.
• Reinstall throttle body bolts using an 8mm socket, then torque: Torque to 8 Nm (71 in-lbs).
• Reconnect the throttle body electrical connector.
• Reinstall the air intake tube and tighten clamps using an 8mm socket or flat-blade screwdriver.
• Reinstall the engine cover by pressing it into the grommets.

---

✅ After Repair

• 🔋 Reconnect the negative battery cable using a 10mm wrench.
• 🔎 Visually check that every coil connector, vacuum line, and sensor connector is reconnected.
• 🧪 Start the engine and let it idle for 2 minutes; it should run smooth with no hissing sounds (hissing can mean a vacuum leak).
• 🚗 Test drive for 10 minutes; verify no check engine light and normal acceleration.
• 🧠 If a check engine light appears, recheck intake connections first, then scan for codes.

---

💰 DIY vs Shop Cost

Shop Cost: $400-$750 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $220-$690 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.5-4.0 hours.

---
