🔧 Optima - Spark Plug Replacement

On your Optima, replacing the spark plugs restores smooth power, fuel economy, and helps prevent misfires under boost. This job is straightforward because the ignition coils sit right on top of each plug.

Difficulty Level: Beginner | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a fully cool engine to avoid burns and protect the aluminum cylinder head threads.
• ⚠️ Keep dirt out of the spark plug holes; debris can damage the engine.
• ⚠️ Do not over-tighten spark plugs; stripped threads are a major repair.
• 🔋 Battery disconnect is recommended: remove the negative terminal before unplugging coils.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 3/8" drive ratchet
• 3/8" drive extension set (3" and 6")
• 5/8" spark plug socket
• Torque wrench (3/8" drive, 10-30 ft-lbs range)
• Flat trim removal tool
• Feeler gauge set (inch or mm)
• Compressed air blow gun
• Clean shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Iridium spark plugs (OEM-equivalent, turbo application) - Qty: 4
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Let the engine cool completely (at least 1 hour after driving).
• Disconnect the negative battery terminal using a 10mm socket.
• Torque wrench = a tool that tightens bolts to an exact setting so you don’t over-tighten.
• Spark plug socket = a deep socket with an insert that grips the plug so it lifts out easily.
• Dielectric grease = silicone grease that helps keep moisture out of the coil boot.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover

• Grip the cover and pull straight up to pop it off the mounting grommets.
• If it feels stuck, gently pry at a corner using a flat trim removal tool.

Step 2: Unplug and remove the ignition coil from cylinder 1

• Start on one coil at a time so nothing gets mixed up.
• Press the electrical connector lock tab and pull the connector off by hand.
• Remove the coil hold-down bolt using a 10mm socket and 3/8" drive ratchet.
• Twist the coil slightly, then pull straight up to remove it.
• Don’t yank the wiring harness.

Step 3: Clean the spark plug well

• Blow out the spark plug hole using compressed air blow gun.
• Wipe around the opening with clean shop towels.

Step 4: Remove the old spark plug

• Install the 5/8" spark plug socket on a 3/8" drive extension and 3/8" drive ratchet.
• Turn counterclockwise to loosen, then spin it out by hand with the ratchet.
• Lift the plug out with the socket.

Step 5: Check the new plug gap (don’t bend iridium tips)

• Use a feeler gauge set to verify the gap matches the plug spec for the turbo engine.
• Typical turbo spark plug gap is around 0.028-0.031 in (0.7-0.8 mm) depending on the exact plug supplied.
• If the plug is labeled “do not gap,” install as-is.
• Never pry on the tiny center tip.

Step 6: Install the new spark plug by hand, then torque it

• Place the new plug into the 5/8" spark plug socket and lower it into the hole.
• Thread it in by hand using only the extension (no ratchet at first) to avoid cross-threading.
• Once hand-tight, torque the plug using a torque wrench: Torque to 18-22 Nm (13-16 ft-lbs).
• If it doesn’t thread smoothly, stop and restart.

Step 7: Reinstall the ignition coil

• Apply a very small dab of dielectric grease inside the end of the coil boot.
• Push the coil straight down until it fully seats on the spark plug.
• Install the coil bolt with a 10mm socket and 3/8" drive ratchet: Torque to 8-10 Nm (71-89 in-lbs).
• Reconnect the electrical connector until it clicks.

Step 8: Repeat for the remaining cylinders

• Repeat Steps 2 through 7 for each of the other 3 coils and plugs.
• Keep everything clean and do one cylinder at a time.

Step 9: Reinstall the engine cover and reconnect the battery

• Press the engine cover down until it snaps into place.
• Reconnect the negative battery terminal using a 10mm socket.

---

✅ After Repair

• Start the engine and let it idle for 30-60 seconds. It should run smooth with no shaking.
• Take a short test drive and do a gentle acceleration pull; watch for a blinking check engine light (misfire).
• If you get a misfire, re-check that each coil connector is fully clicked in and each coil is fully seated.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $40-$120 (parts only)

You Save: $130-$410 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
