🔧 Optima - Spark Plug Replacement

On your Optima, the spark plugs sit under the ignition coils on top of the engine. Replacing them restores smooth power, helps fuel economy, and can prevent misfires under boost on the turbo engine.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• 🧯 Let the engine cool fully before starting (hot aluminum threads can strip).
• 🧤 Keep dirt out of the spark plug holes—debris can damage the engine.
• 🔌 Disconnect the negative battery terminal if you’re worried about accidentally shorting a connector.
• 🧪 Do not use anti-seize on these plugs unless the plug manufacturer specifically requires it (it can change torque).

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" ratchet
• 3/8" ratchet
• 3/8" torque wrench (10-40 Nm range)
• 6" extension (3/8")
• 12" extension (3/8")
• 5/8" (16mm) spark plug socket
• Trim clip tool
• Small flathead screwdriver
• Compressed air blow gun
• Shop vacuum
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs (iridium, OEM-style for Optima 2.0T) - Qty: 4
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• 🅿️ Park on level ground, shift to Park, and set the parking brake.
• 🧊 Make sure the engine is fully cool to the touch.
• 🔌 If disconnecting the battery: use a 10mm socket to remove the negative terminal and position it so it can’t spring back.
• 🧼 Have your shop vacuum and compressed air blow gun ready to clean around the coils before removing plugs.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover (if equipped)

• Use a trim clip tool to gently pry up the cover corners if it’s tight.
• Lift straight up to pop it off the rubber grommets, then set it aside.

Step 2: Unplug and remove ignition coils (one cylinder at a time)

• Pick one coil to start with so you don’t mix anything up. Work one plug at a time.
• Press the connector lock and unplug the coil electrical connector; use a small flathead screwdriver only if needed to release the tab gently.
• Remove the coil hold-down bolt using a 10mm socket and 1/4" ratchet.
• Twist the coil boot slightly, then pull the coil straight up and out.

Step 3: Clean the spark plug well

• Vacuum loose dirt around the hole using a shop vacuum.
• Blow out the spark plug well using a compressed air blow gun while wearing safety glasses.

Step 4: Remove the old spark plug

• Install the 5/8" (16mm) spark plug socket onto a 12" extension (3/8") and 3/8" ratchet.
• Lower the socket straight into the well until it fully seats on the plug.
• Turn counterclockwise to loosen, then remove the plug.

Step 5: Install the new spark plug (hand-start first)

• Check the new plug matches the old one (same length and tip style). Don’t force a mismatched plug.
• Start threading the new plug by hand using the spark plug socket and extension only (no ratchet yet) so it can’t cross-thread.
• Once it bottoms lightly, switch to a 3/8" torque wrench (10-40 Nm range) and tighten: Torque to 25 Nm (18 ft-lbs).

Step 6: Reinstall the coil

• Add a tiny smear of dielectric grease inside the coil boot lip (dielectric grease is a non-conductive silicone grease that helps prevent moisture and eases future removal).
• Push the coil straight down until it fully seats on the plug.
• Install the coil bolt using a 10mm socket and snug it with a torque wrench: Torque to 9.8 Nm (7 ft-lbs).
• Reconnect the electrical connector until it clicks.

Step 7: Repeat for the remaining cylinders

• Repeat Steps 2–6 for the other 3 spark plugs.
• Use the same clean-first routine for each plug well.

Step 8: Reinstall engine cover and reconnect battery (if disconnected)

• Press the engine cover back onto its grommets until it seats evenly.
• If you disconnected the battery, reinstall the negative terminal using a 10mm socket and tighten securely.

---

✅ After Repair

• 🔍 Start the engine and let it idle for 1–2 minutes; it should run smooth with no shaking.
• 🚗 Take a short test drive and do a light acceleration pull; watch for hesitation or flashing check-engine light.
• 🧾 If you had a misfire before, scan for codes after the drive to confirm it’s resolved.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $205-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
