🔧 Outback - Spark Plug Replacement

On your Outback, the spark plugs sit deep in the cylinder heads on each side of the engine. Replacing them restores strong ignition, helps fuel economy, and prevents misfires—especially as the plugs age.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a completely cool engine to avoid burns and thread damage.
• ⚠️ If you remove the battery, disconnect the negative terminal first and reconnect it last.
• ⚠️ Do not over-tighten spark plugs—over-tightening can damage the aluminum cylinder head.
• ⚠️ Keep dirt out of the spark plug holes; blow/brush debris away before removing plugs.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 10mm socket
• 10mm wrench
• 3/8" ratchet
• 3/8" torque wrench
• 5/8" spark plug socket
• 3/8" extension set
• 3/8" universal joint
• Flathead screwdriver
• Needle-nose pliers
• Compressed air blow gun
• Feeler gauge set
• Dielectric grease

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs - Replace all four - Qty: 4

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Open the hood and let the engine cool fully (at least 1 hour if it was running).
• If you’ll remove the battery for access, use a 10mm wrench to disconnect the negative terminal first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Create access to the coils

• On the passenger side, loosen the intake duct clamps using a flathead screwdriver, then remove the air intake snorkel/ducting as needed.
• Remove the air cleaner upper/box pieces as needed using a 10mm socket and 10mm wrench to get room to reach the coil pack.
• On the driver side, remove the battery for working room: disconnect negative then positive using a 10mm wrench, remove the hold-down using a 10mm socket, and lift the battery out carefully.

Step 2: Unplug and remove one ignition coil at a time

• Pick one cylinder and do it start-to-finish before moving on (this prevents mixing anything up).
• Press the electrical connector tab and unplug the coil. Use needle-nose pliers only if needed (don’t crush the connector).
• Remove the coil retaining bolt using a 10mm socket.
• Twist the coil boot gently to break it loose, then pull the coil straight out.
• Put a tiny dab of dielectric grease inside the end of the rubber boot. Just a thin film is enough.

Step 3: Clean the spark plug well

• Blow debris out of the plug hole using compressed air blow gun.
• If you don’t have compressed air, use a clean rag and take your time—don’t let dirt fall in.

Step 4: Remove the old spark plug

• Install a 5/8" spark plug socket onto a 3/8" extension set and 3/8" ratchet.
• If the angle is tight, add a 3/8" universal joint (this is a flexible joint that helps the socket bend slightly).
• Turn counterclockwise to remove the spark plug, then lift it out with the socket.

Step 5: Check and prepare the new spark plug

• Confirm the new plug matches the old plug’s length and seat type.
• Check the gap using a feeler gauge set. If the plug is iridium/platinum style, do not pry on the tiny center electrode.
• Do not apply anti-seize unless your plug manufacturer specifically instructs it (many modern plugs are nickel-plated and don’t need it).

Step 6: Install the new spark plug (no cross-threading)

• Start the new plug by hand using just the 5/8" spark plug socket and a short 3/8" extension set (no ratchet at first).
• Turn it clockwise by hand until it seats smoothly. If it feels tight early, stop and restart—this prevents cross-threading.
• Torque the spark plug using a 3/8" torque wrench: Torque to 21 Nm (15.2 ft-lbs).

Step 7: Reinstall the ignition coil

• Push the coil straight onto the plug until it fully seats.
• Install the coil retaining bolt using a 10mm socket, then snug it securely (do not over-tighten).
• Reconnect the coil electrical connector until it clicks.

Step 8: Repeat for the remaining three spark plugs

• Repeat Steps 2–7 for the other cylinders.
• One cylinder at a time keeps it simple.

Step 9: Reassemble the intake and battery

• Reinstall the air intake/air box parts using a 10mm socket and tighten clamps with a flathead screwdriver.
• Reinstall the battery and hold-down using a 10mm socket.
• Reconnect battery terminals using a 10mm wrench (positive first, negative last).

---

✅ After Repair

• Start the engine and let it idle for 30–60 seconds. It should run smooth with no shaking.
• Listen for ticking/air leaks near the intake ducting—if you hear one, re-check hose clamps with a flathead screwdriver.
• Take a short test drive and confirm no check engine light or misfire.

---

💰 DIY vs Shop Cost

Shop Cost: $300-$550 (parts + labor)

DIY Cost: $40-$120 (parts only)

You Save: $180-$510 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
