🔧 Santa Fe - Spark Plug Replacement

On your Santa Fe, the front-bank spark plugs are easy to access, but the rear-bank plugs sit under the upper intake manifold (the top “plenum”), so you’ll remove it to reach them. Replacing all 6 plugs restores smooth starting, power, and fuel economy, and helps protect the ignition coils.

Difficulty Level: Advanced | Estimated Time: 2.5-4.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a fully cool engine to avoid burns and stripped threads.
• ⚠️ Disconnect the negative battery terminal to prevent accidental short circuits.
• ⚠️ Keep dirt out of the cylinders and intake ports; vacuum and use clean rags to cover openings.
• ⚠️ Do not force connectors; press the lock tab before pulling.
• ⚠️ Do not use anti-seize on Hyundai-plated spark plug threads unless the plug maker specifically requires it.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 10mm socket
• 12mm socket
• 14mm socket
• 10mm wrench
• 3/8" drive ratchet
• 3/8" drive extension set
• 3/8" drive universal joint swivel
• 5/8" spark plug socket
• Torque wrench (5-60 Nm range)
• Flat trim tool
• Needle-nose pliers
• Small pick tool
• Shop vacuum
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Iridium spark plugs (OEM-spec) - Qty: 6
• Upper intake manifold gasket set - Qty: 1
• Throttle body gasket - Qty: 1
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• 🧰 Park on level ground, shift to Park, and set the parking brake.
• 🧰 Let the engine cool completely (at least 1 hour after driving).
• 🧰 Use a shop vacuum to clean dust around the intake and coils before opening anything.
• 🧰 Disconnect the battery using a 10mm wrench on the negative terminal and move the cable aside.
• 🧰 Tip: Take photos before unplugging hoses.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Assumption: Your Santa Fe uses the transverse 3.3L V6 where the rear-bank plugs require upper intake manifold removal.

Step 1: Remove the engine cover

• Pull up firmly on the plastic engine cover to pop it off the rubber mounts.
• Set it aside where it won’t get stepped on.

Step 2: Replace the front-bank spark plugs (easy access)

• Locate the 3 ignition coils at the front of the engine.
• Unplug each coil connector by pressing the lock tab (use a small pick tool gently if needed) and pulling straight back.
• Remove each coil hold-down bolt using a 10mm socket.
• Twist the coil boot slightly, then pull the coil straight up and out.
• Blow/vacuum debris from each spark plug well using a shop vacuum.
• Remove the spark plug using a 5/8" spark plug socket, 3/8" ratchet, and a 3/8" extension.
• Install the new plug by hand first using the spark plug socket and extension (no ratchet) to avoid cross-threading.
• Tighten with a torque wrench (a torque wrench measures exact tightness so you don’t strip threads): Torque to 18-22 Nm (13-16 ft-lbs).
• Apply a thin wipe of dielectric grease inside the coil boot (dielectric grease helps prevent moisture and eases future removal).
• Reinstall the coil and tighten the coil bolt: Torque to 8-10 Nm (71-89 in-lbs).
• Reconnect the electrical connector until it clicks.
• Repeat for all 3 front coils/plugs.

Step 3: Remove the air intake ducting to access the intake manifold area

• Loosen the intake tube clamp(s) using a flat trim tool or appropriate fastener access with a 10mm socket (varies by clamp style).
• Disconnect any small breather hoses using needle-nose pliers to slide clamps back.
• Lift the ducting out and set it aside.

Step 4: Remove the throttle body from the upper intake manifold

• Unplug the throttle body connector by pressing the lock tab.
• Remove the throttle body mounting bolts using a 10mm socket.
• Carefully pull the throttle body away and remove the old gasket.
• Cover the opening with a clean rag to keep debris out.
• When reinstalling later: Torque to 8-10 Nm (71-89 in-lbs).

Step 5: Disconnect hoses and connectors on the upper intake manifold

• Label and disconnect vacuum/PCV hoses using needle-nose pliers and a flat trim tool to gently break hoses loose.
• Unplug any sensors/solenoids attached to the upper intake manifold by pressing the lock tabs.
• Tip: If a hose feels stuck, twist first.

Step 6: Remove the upper intake manifold (plenum)

• Remove the upper intake manifold bolts using a 12mm socket (some brackets may use 14mm socket).
• Lift the upper intake manifold straight up and out.
• Immediately cover the exposed lower intake ports with clean rags.
• Remove the old upper intake manifold gaskets.
• When reinstalling later: Torque to 18-22 Nm (13-16 ft-lbs) in an even crisscross pattern.

Step 7: Replace the rear-bank spark plugs (now accessible)

• Unplug each rear ignition coil connector (use a flashlight to see the lock tab).
• Remove the coil bolts using a 10mm socket.
• Remove each coil, vacuum the plug wells with a shop vacuum, then remove the plugs using a 5/8" spark plug socket, 3/8" extension, and a universal joint swivel (a swivel bends to reach tight angles).
• Start each new plug by hand, then tighten: Torque to 18-22 Nm (13-16 ft-lbs).
• Add a thin wipe of dielectric grease inside each coil boot.
• Reinstall coils and tighten bolts: Torque to 8-10 Nm (71-89 in-lbs).
• Reconnect all rear coil connectors until they click.

Step 8: Reinstall the upper intake manifold with new gaskets

• Remove the rags from the intake ports.
• Install new upper intake manifold gaskets in the manifold grooves.
• Set the upper intake manifold in place without pinching any wiring.
• Thread bolts in by hand first, then tighten evenly using a 12mm socket.
• Final tighten: Torque to 18-22 Nm (13-16 ft-lbs).
• Reconnect all hoses and connectors you removed.

Step 9: Reinstall the throttle body and intake ducting

• Install a new throttle body gasket, then bolt the throttle body on using a 10mm socket.
• Tighten throttle body bolts: Torque to 8-10 Nm (71-89 in-lbs).
• Reconnect the throttle body electrical connector until it clicks.
• Reinstall the intake ducting and tighten clamps using a 10mm socket.
• Reconnect breather hoses and move spring clamps back using needle-nose pliers.

Step 10: Reconnect the battery and reinstall the engine cover

• Reconnect the negative battery terminal using a 10mm wrench.
• Press the engine cover back onto its mounting studs.

---

✅ After Repair

• ✅ Double-check every hose clamp and electrical connector you touched (especially rear-bank coils and throttle body).
• ✅ Start the engine and let it idle for 2-3 minutes; the idle may be slightly high at first after battery disconnect.
• ✅ Listen for hissing (vacuum leak) and watch for a check engine light.
• ✅ Take a 10-minute test drive, then recheck for any loose clamps or fuel/air smells.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$900 (parts + labor)

DIY Cost: $90-$220 (parts only)

You Save: $360-$680 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.5-4.0 hours.

---
