🔧 Equinox - Spark Plug Replacement

You’ll be replacing all six spark plugs on your Equinox’s V6. This restores good starting, smooth idle, and fuel economy, and prevents misfires that can damage the catalytic converters.

Difficulty Level: Intermediate (OK for careful beginner) | Estimated Time: 2–3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a completely cold engine; hot parts can burn you and damage threads in the aluminum cylinder heads.
• ⚠️ Disconnect the negative battery cable before unplugging ignition coils to avoid short circuits.
• ⚠️ Do not pull on the ignition coil wires; always pull on the coil body.
• ⚠️ Keep dirt out of the spark plug holes; debris in the cylinder can cause engine damage.
• ⚠️ Use a torque wrench; overtightening spark plugs can strip the aluminum threads.
• ⚠️ Only use spark plugs that match the OEM spec and gap; mixing types can cause drivability issues.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠️ 3/8" drive ratchet
• 🛠️ 1/4" drive ratchet
• 🛠️ 3/8" drive torque wrench (5–60 ft-lbs range)
• 🛠️ 10mm socket
• 🛠️ 8mm socket
• 🛠️ 5/8" spark plug socket (with rubber insert or magnet)
• 🛠️ 3/8" drive extension (3"–6")
• 🛠️ 3/8" drive wobble or universal joint adapter
• 🛠️ Flathead screwdriver (medium size)
• 🛠️ Needle-nose pliers
• 🛠️ Spark plug gap gauge (wire or coin style)
• 🛠️ Dielectric grease tube
• 🛠️ Small clean brush or nylon detailing brush
• 🛠️ Compressed air can or air blower (if available)
• 🛠️ Shop rags
• 🛠️ Mechanic gloves
• 🛠️ Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Iridium spark plug set (OEM spec, 1.1 mm / 0.043" gap) - Qty: 6
• 🔩 Ignition coil boots - Qty: 6 (optional but recommended if original)
• 🔩 Dielectric grease - Qty: 1 small tube
• 🔩 Throttle body/intake cleaner spray - Qty: 1 (optional for light cleaning while open)

---

📋 Before You Begin

• Park the Equinox on level ground, shift to Park, and set the parking brake.
• Turn off the engine and remove the key; let the engine cool at least 45–60 minutes.
• Open the hood and support it securely.
• Disconnect the negative battery terminal using a 10mm socket and move the cable aside so it cannot spring back.
• Lay out your new spark plugs and verify you have six, all the same part number.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover

• Locate the plastic engine cover on top of the engine; it usually says “V6” or similar.
• Use a 10mm socket on your 1/4" ratchet to remove any visible bolts holding the cover (some versions just pull up off rubber grommets).
• Lift the cover straight up and set it aside carefully.
• Cover off lets you see coils and plugs.

Step 2: Identify front and rear cylinder banks

• The engine is mounted sideways. The front bank is closest to the radiator; the rear bank is closest to the firewall (windshield side).
• Each spark plug has a black ignition coil on top with an electrical connector.
• Front bank is easier; start there to learn.

Step 3: Unplug front bank ignition coils

• On the front bank, locate the 3 ignition coils.
• On the first coil, press down on the connector’s plastic locking tab with your thumb or a flathead screwdriver while gently pulling the connector straight back.
• Repeat for the other two front coils.
• If stuck, gently wiggle the connector; avoid pulling on the wires.

Step 4: Remove front bank ignition coils

• Use a 10mm socket and 1/4" ratchet to remove the single bolt holding each coil to the valve cover.
• Set the bolts in a small tray or on a clean rag so you don’t lose them.
• Grasp the coil body and twist slightly, then pull straight up to remove it from the spark plug well.
• Inspect each coil boot for oil, cracks, or burning; replace boots if damaged.

Step 5: Clean around front spark plug holes

• Use a brush to gently loosen any dirt around each spark plug hole.
• Blow the area out with compressed air if you have it, aiming away from your face.
• Keep debris from falling into the cylinders.

Step 6: Remove front spark plugs

• Attach the 5/8" spark plug socket to a 3/8" extension and your 3/8" ratchet.
• Carefully insert the socket into the first spark plug well until it seats on the plug.
• Turn counterclockwise to loosen. Once loose, spin it out by hand with the extension.
• Pull the plug out; the rubber insert or magnet in the socket should hold it.
• Repeat for the other two front plugs.

Step 7: Check and set gap on new plugs

• Use the spark plug gap gauge. This is a small tool that measures the distance between the center electrode and the side electrode.
• GM spec for this engine is typically 1.1 mm (0.043"); confirm on the plug box or under-hood label.
• Slide the correct size on the gauge between the electrodes; it should just drag slightly.
• If you must adjust, very gently bend only the side electrode; do not hit or pry on the center electrode.
• Iridium tips are delicate, handle them carefully.

Step 8: Install front bank new spark plugs

• Do not use anti-seize on these plugs unless the plug manufacturer specifically instructs it. GM iridium plugs are usually pre-coated; added anti-seize can cause over-tightening.
• Apply a tiny smear of dielectric grease just inside the top of the coil boot area (not on the metal threads or electrodes).
• Place a new spark plug into the 5/8" spark plug socket and extension.
• Carefully lower it into the spark plug hole, then thread it by hand only, turning clockwise.
• Make sure it spins in smoothly. If it binds, back it out and restart to avoid cross-threading.
• Once hand tight, attach the torque wrench to the extension.
• Tighten each plug to 25 Nm (18 ft-lbs) using the torque wrench.

Step 9: Reinstall front ignition coils

• Slide each coil boot down over its new spark plug until fully seated.
• Reinstall the 10mm coil bolts using a 10mm socket and ratchet; snug them. Torque to about 8 Nm (71 in-lbs) if you have an in-lb setting.
• Plug the electrical connectors back in until you hear or feel a click.

Step 10: Access rear bank coils

• The rear bank is closer to the firewall and tighter to reach but still doable.
• You may need to move or gently flex plastic wiring looms or small brackets for better access.
• If there is a plastic cowl brace or cover in your way, remove its fasteners using an 8mm socket or 10mm socket as needed and set it aside.
• Take photos first so reassembly is easier.

Step 11: Unplug and remove rear bank coils

• Repeat the same process as the front: unplug all 3 rear coil connectors by pressing the tab and pulling straight back.
• Remove the coil retaining bolts with a 10mm socket and 1/4" ratchet.
• Twist and pull each coil up and out. Space is tighter, so a slow, gentle twist helps.

Step 12: Clean and remove rear spark plugs

• Use the brush around the holes and blow with compressed air if possible.
• Use your 5/8" spark plug socket, extension, and a wobble or universal joint adapter if needed to reach the plugs at a slight angle.
• Break each plug loose with the ratchet, then spin out by hand and remove.

Step 13: Install rear bank new spark plugs

• Confirm gaps again at 1.1 mm (0.043") with your gap gauge.
• Put each new plug into the spark plug socket and extension and thread in by hand only, taking your time.
• Once fully hand tight, use the torque wrench to torque each to 25 Nm (18 ft-lbs).
• Hand-starting is key to protecting threads.

Step 14: Reinstall rear ignition coils

• Apply a small amount of dielectric grease inside each boot as you did on the front.
• Push each coil down onto its plug until seated.
• Reinstall the coil bolts with the 10mm socket and snug them; torque about 8 Nm (71 in-lbs) if possible.
• Reconnect each coil electrical connector until it clicks.

Step 15: Reinstall any removed brackets and engine cover

• If you removed any cowl braces or small brackets, reinstall them using the 8mm socket or 10mm socket and tighten securely.
• Place the engine cover back in position.
• Press it onto its rubber grommets or reinstall the bolts using a 10mm socket.

Step 16: Reconnect battery and final check

• Reconnect the negative battery terminal and tighten with a 10mm socket. Do not overtighten; just snug.
• Double-check that all coil connectors are plugged in and no tools are left in the engine bay.

---

✅ After Repair

• Start the engine and let it idle. It should run smoothly with no misfires or warning lights.
• Listen for unusual ticking or hissing noises; if heard, shut off and recheck coil connections and plug tightness.
• Take a short, gentle test drive: check acceleration, idle at stoplights, and note if any check engine light appears.
• If the check engine light comes on, have the codes read; an unseated coil connector is a common cause after this job.

---

💰 DIY vs Shop Cost

Shop Cost: $350–$550 (parts + labor)

DIY Cost: $70–$150 (parts only)

You Save: $200–$400 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.5–2.0 hours.

---
