🔧 Escape - Spark Plug Replacement

Replacing the spark plugs on your Escape helps restore smooth starting, steady idle, fuel economy, and proper ignition performance. The 2.5L engine uses four ignition coils on top of the engine, with one spark plug under each coil.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Work only on a completely cool engine. Spark plugs thread into the aluminum cylinder head, and hot aluminum can strip more easily.
• ⚠️ Disconnect the negative battery cable before unplugging ignition coils.
• ⚠️ Keep dirt and debris out of the spark plug wells. Anything that falls in can enter the engine.
• ⚠️ Do not overtighten spark plugs. The cylinder head is aluminum and the threads can be damaged.
• ⚠️ Replace all four spark plugs together for even engine performance.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 8mm socket
• 10mm socket
• 5/8-inch spark plug socket
• 3/8-inch drive ratchet
• 3/8-inch drive 6-inch extension
• 3/8-inch drive torque wrench
• Flat-blade screwdriver
• Compressed air nozzle
• Spark plug gap gauge
• Needle-nose pliers
• Clean shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs - Qty: 4
• Dielectric grease - Qty: 1 small tube

---

📋 Before You Begin

• Park your Escape on level ground, shift to Park, and set the parking brake.
• Let the engine cool fully before starting.
• Open the hood and remove any loose leaves or dirt around the top of the engine.
• Disconnect the negative battery cable using a 10mm socket. Move the cable aside so it cannot spring back onto the battery terminal.
• A spark plug socket is a deep socket with a rubber insert or magnet that holds the spark plug while you remove or install it.
• Dielectric grease is a non-conductive silicone grease used inside the coil boot to help prevent moisture and sticking.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the Engine Appearance Cover

• Use both hands to lift the plastic engine cover straight upward from the rubber mounting grommets.
• If it feels stuck, gently rock it side to side while lifting.
• Set the cover aside in a safe place.
• Tip: Do not pry hard on plastic.

Step 2: Clean Around the Ignition Coils

• Put on safety glasses.
• Use a compressed air nozzle to blow dirt away from the top of the engine and around each ignition coil.
• Use clean shop towels to wipe loose dirt away.
• The ignition coil is the small electrical part sitting above each spark plug.

Step 3: Unplug the Ignition Coil Connectors

• Use your fingers to press the release tab on the first ignition coil connector.
• If the tab is stiff, use a flat-blade screwdriver gently to help release it.
• Pull the connector straight back from the coil.
• Repeat this for all four ignition coil connectors.
• Tip: Pull the connector, not the wires.

Step 4: Remove the Ignition Coil Bolts

• Use an 8mm socket, 3/8-inch drive ratchet, and 3/8-inch drive 6-inch extension to remove the bolt holding each ignition coil.
• Set the four bolts aside where they cannot roll away.
• Factory reinstall torque for the ignition coil bolts is Torque to 6 Nm (53 in-lbs).

Step 5: Remove the Ignition Coils

• Pull each ignition coil straight upward by hand.
• If a coil sticks, gently twist it left and right while pulling up.
• Use needle-nose pliers only if needed to help grip the rubber boot carefully.
• Lay the coils in order from left to right so they go back into the same cylinders.
• Tip: Keeping coils in order helps diagnosis later.

Step 6: Blow Out the Spark Plug Wells

• Use a compressed air nozzle to blow out each spark plug well before removing the plugs.
• The spark plug well is the deep tube where the coil was sitting.
• This step keeps dirt from falling into the engine when the spark plug comes out.

Step 7: Remove the Old Spark Plugs

• Place the 5/8-inch spark plug socket onto the 3/8-inch drive 6-inch extension and 3/8-inch drive ratchet.
• Lower the socket straight down into the first spark plug well.
• Turn counterclockwise slowly to loosen the spark plug.
• Once loose, continue turning by hand with the extension until the plug comes out.
• Repeat for all four spark plugs.
• If a plug feels very tight, stop and tighten it slightly, then loosen again slowly.
• Tip: Slow movement protects cylinder head threads.

Step 8: Check the New Spark Plugs

• Use a spark plug gap gauge to check each new spark plug gap.
• The correct gap for your Escape is 0.049-0.053 in (1.25-1.35 mm).
• Do not forcefully bend the fine center electrode on modern iridium-style plugs.
• If a plug is dropped, do not install it. Replace it.

Step 9: Install the New Spark Plugs by Hand First

• Place one new spark plug into the 5/8-inch spark plug socket.
• Attach the socket to the 3/8-inch drive 6-inch extension only, without the ratchet.
• Lower the plug straight into the spark plug well.
• Turn clockwise by hand several full turns until the plug seats lightly.
• If it does not turn smoothly, back it out and start again.
• Repeat for all four spark plugs.
• Tip: Hand-starting prevents cross-threading.

Step 10: Torque the Spark Plugs

• Attach the 5/8-inch spark plug socket and 3/8-inch drive 6-inch extension to a 3/8-inch drive torque wrench.
• Tighten each spark plug to Torque to 15 Nm (11 ft-lbs).
• Do not add anti-seize compound unless the spark plug manufacturer specifically requires it.
• Most modern replacement spark plugs have coated threads, and extra lubricant can cause overtightening.

Step 11: Apply Dielectric Grease

• Apply a small pea-sized amount of dielectric grease inside the end of each ignition coil boot.
• Use a clean shop towel to wipe away any excess grease.
• Do not put grease on the metal spark plug terminal.

Step 12: Reinstall the Ignition Coils

• Push each ignition coil straight down over its spark plug by hand.
• You should feel the boot seat onto the top of the plug.
• Install each coil bolt using an 8mm socket, 3/8-inch drive 6-inch extension, and 3/8-inch drive torque wrench.
• Tighten each ignition coil bolt to Torque to 6 Nm (53 in-lbs).

Step 13: Reconnect the Ignition Coil Connectors

• Push each electrical connector onto its ignition coil by hand until it clicks.
• Lightly tug each connector to confirm it is locked in place.
• If needed, use a flat-blade screwdriver gently to align a connector tab, but do not pry hard.

Step 14: Reinstall the Engine Cover and Battery Cable

• Line up the engine cover with the rubber grommets and press it straight down by hand.
• Reconnect the negative battery cable using a 10mm socket.
• Tighten the battery terminal nut snugly to Torque to 5 Nm (44 in-lbs).

---

✅ After Repair

• ✅ Start your Escape and let it idle for 1-2 minutes.
• ✅ The idle may be slightly uneven for a few seconds after the battery was disconnected, then should smooth out.
• ✅ Listen for misfires, ticking, or popping sounds.
• ✅ If the check engine light flashes, shut the engine off and recheck the coil connectors and coil seating.
• ✅ Take a short, gentle test drive and confirm smooth acceleration.
• ✅ Recheck that the engine cover is secure after the test drive.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $35-$90 (parts only)

You Save: $145-$260 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
