🔧 RAV4 - Spark Plug Replacement

On your RAV4, the spark plugs fire the air/fuel mixture. Replacing worn plugs helps prevent misfires, rough idle, and poor fuel economy. The plugs sit under the ignition coils on top of the engine, so this is a straightforward job with basic hand tools.

Difficulty Level: Beginner | Estimated Time: 0.7-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cold engine to avoid burns and to protect the aluminum cylinder head threads.
• ⚠️ Keep dirt out of the spark plug holes; debris can damage the engine.
• ⚠️ If you disconnect the battery, you may lose radio presets and the clock.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 10mm socket
• 3/8" drive ratchet
• 3/8" drive extension set (3" and 6")
• 14mm thin-wall spark plug socket (rubber insert)
• Torque wrench (3/8" drive, 10-30 Nm range)
• Small flathead screwdriver
• Compressed air blow gun
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Iridium spark plugs (OE equivalent) - Qty: 4
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• 🅿️ Park on level ground, shift to Park, and set the parking brake.
• Let the engine cool fully (warm aluminum threads are easier to strip).
• If you want maximum safety, disconnect the negative battery cable using a 10mm socket.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover (if equipped)

• Lift the plastic engine cover straight up by hand (it’s held by rubber grommets).
• Set it aside where it won’t get stepped on.

Step 2: Unplug and remove the ignition coils

• Use a flashlight to locate the 4 ignition coils on top of the engine.
• At each coil connector, gently release the lock tab using a small flathead screwdriver, then pull the connector straight off.
• Remove the coil hold-down bolt using a 10mm socket and 3/8" drive ratchet.
• Twist the coil slightly, then pull it straight up and out.
• Repeat for all four coils.
• Keep coils in order, one per cylinder.

Step 3: Clean the spark plug wells

• Blow out each spark plug well using a compressed air blow gun.
• This prevents sand/dirt from falling into the cylinder when the plug is removed.

Step 4: Remove the old spark plugs

• Install a 14mm thin-wall spark plug socket (rubber insert) onto a 3/8" drive extension set (3" and 6") and 3/8" drive ratchet.
• Lower the socket straight down onto the spark plug until it fully seats.
• Turn counterclockwise to loosen, then spin it out.
• Lift the plug out with the socket.

Step 5: Install the new spark plugs (by hand first)

• Put a new plug into the 14mm thin-wall spark plug socket (rubber insert) so it won’t drop.
• Thread the plug in by hand using only the 3/8" drive extension set (3" and 6") (no ratchet at first).
• If it doesn’t turn smoothly, back it out and try again (this avoids cross-threading).
• Once finger-tight, torque the plug using a torque wrench (3/8" drive, 10-30 Nm range): Torque to 18 Nm (13 ft-lbs).
• Do not adjust iridium plug gaps.

Step 6: Reinstall the ignition coils

• Apply a very small amount of dielectric grease inside each coil boot (the rubber part that snaps onto the plug).
• Push each coil straight down until you feel it seat onto the spark plug.
• Install the coil bolt using a 10mm socket and 3/8" drive ratchet, then finish with a torque wrench (3/8" drive, 10-30 Nm range): Torque to 9 Nm (80 in-lbs).
• Reconnect each electrical connector until it clicks.

Step 7: Reinstall the engine cover and reconnect the battery (if disconnected)

• Press the engine cover back down by hand until the grommets seat.
• If disconnected earlier, reconnect the negative battery cable using a 10mm socket and 3/8" drive ratchet.

---

✅ After Repair

• Start the engine and let it idle for 30-60 seconds. It should run smooth with no shaking.
• If the check engine light turns on or it runs rough, re-check that every coil connector is fully clicked in.
• Take a short test drive, then recheck for any unusual smells or noises.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $40-$90 (parts only)

You Save: $160-$410 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.2 hours.

---
