🔧 Side View Mirror Replacement

This repair covers removing and replacing the exterior door mirror assembly on your Sierra. The job is usually straightforward, but you need to work carefully around the door trim and wiring connector so nothing gets damaged.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• Assumption: standard power side mirror assembly; if your mirror has turn signals, heat, or power folding, the connector may have extra wires.
• Disconnect the negative battery cable before unplugging mirror wiring.
• Use care around the door trim panel clips; they can break if pried too hard.
• Support the mirror while removing the last fastener so it does not fall and scratch the paint.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 7mm socket
• 10mm socket
• Ratchet
• Socket extension
• Trim panel removal tool
• Flat trim tool
• Torx T15 screwdriver
• Torque wrench
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Side view mirror assembly - Qty: 1
• Door trim panel clips - Qty: 1 set
• Mirror mounting nuts - Qty: 3

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Lower the window glass fully to help with trim removal and access.
• Disconnect the negative battery cable before unplugging the mirror connector.
• Keep a small container ready for fasteners and clips.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the door trim panel

• Use a 7mm socket and ratchet to remove the screws from the door pull and lower trim area.
• Use a trim panel removal tool to pop the panel clips loose around the edge of the door.
• Lift the panel upward to unhook it from the top door ledge.
• Disconnect any electrical connectors from the window switches if needed.

Step 2: Disconnect the mirror wiring

• Locate the mirror connector near the front upper corner of the door.
• Press the lock tab and unplug the connector by hand.
• Do not pull on the wires.

Step 3: Remove the old mirror

• Use a 10mm socket, ratchet, and socket extension to remove the 3 mirror mounting nuts.
• Hold the mirror from the outside while removing the last nut.
• Lift the mirror away from the door.
• Remove the old foam gasket if it stays on the door.

Step 4: Install the new mirror

• Set the new mirror in place and align the studs with the door holes.
• Install the 3 mounting nuts by hand first.
• Use a 10mm socket and torque wrench to tighten the nuts evenly.
• Torque to 8 Nm (71 ft-lbs).
• Reconnect the mirror electrical connector until it clicks.

Step 5: Reinstall the door trim panel

• Reconnect the switch connectors if they were unplugged.
• Hang the top of the panel on the door ledge first.
• Press the panel clips back into place around the perimeter.
• Use a 7mm socket to reinstall the screws.
• Make sure every clip seats fully.

Step 6: Reconnect power and test

• Reconnect the negative battery cable.
• Test mirror adjustment, heat, and any turn signal or puddle light functions if equipped.
• Check that the mirror is secure and does not shake.

---

✅ After Repair

• Verify both mirrors adjust correctly from the switch.
• Check for wind noise around the mirror at road speed.
• Confirm the door panel sits flush with no rattles.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$650 (parts + labor)

DIY Cost: $80-$250 (parts only)

You Save: $170-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-2 hours.

---
