🔧 Tacoma - Shock Absorber Replacement

This guide covers replacing the shock absorbers on your Tacoma. The front uses a coil-over shock assembly, meaning the shock sits inside the front spring assembly; the rear uses separate shock absorbers mounted between the axle and frame.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Always support your Tacoma with jack stands before working underneath it. Never rely on a floor jack alone.
• ⚠️ Do not disassemble the front coil spring from the shock unless you have a proper spring compressor and experience. The spring is under high force and can cause serious injury.
• ⚠️ Replace shocks in pairs: both front shocks together or both rear shocks together.
• ⚠️ Keep your hands clear of pinch points when lowering or raising the axle.
• ⚠️ Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• 21mm socket
• 19mm socket
• 17mm socket
• 14mm socket
• 12mm socket
• 17mm wrench
• 19mm wrench
• Ratchet 3/8-inch drive
• Ratchet 1/2-inch drive
• Breaker bar 1/2-inch drive
• Torque wrench 1/2-inch drive
• Torque wrench 3/8-inch drive
• Pry bar 18-inch
• Rubber mallet
• Penetrating oil
• Paint marker
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front shock absorber assemblies - Qty: 2
• Rear shock absorbers - Qty: 2
• Front shock mounting hardware kit - Qty: 1
• Rear shock mounting hardware kit - Qty: 1

---

📋 Before You Begin

• Park your Tacoma on level ground and set the parking brake.
• Place wheel chocks behind the rear wheels when working on the front, and in front of the front wheels when working on the rear.
• Spray the shock mounting nuts and bolts with penetrating oil and let it soak for 10-15 minutes.
• A torque wrench tightens bolts to the correct factory tightness so they are not too loose or too tight.
• A breaker bar is a long-handled tool that gives extra leverage for tight bolts.
• If replacing the front shocks, use complete front shock assemblies if you are a beginner. This avoids handling the compressed coil spring.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Wheel Lug Nuts

• Use a 21mm socket and breaker bar 1/2-inch drive to loosen the lug nuts slightly before lifting your Tacoma.
• Do not fully remove the lug nuts yet.
• Tip: Loosen before lifting.

Step 2: Raise and Support Your Tacoma

• Use a floor jack rated 3-ton minimum to lift the end of your Tacoma you are working on.
• Place jack stands rated 3-ton minimum under the frame.
• Slowly lower your Tacoma onto the jack stands.
• Use the floor jack to lightly support the lower control arm in front or the rear axle in back.

Step 3: Remove the Wheels

• Use a 21mm socket and ratchet 1/2-inch drive to remove the lug nuts.
• Remove the wheel and set it flat on the ground.

Step 4: Replace the Front Shock Assembly

• Use a paint marker to mark the position of any alignment-related lower shock hardware before removal.
• Use a 17mm socket, 19mm socket, 17mm wrench, or 19mm wrench as needed to remove the lower shock mounting bolt and nut.
• Use a 14mm socket and ratchet 3/8-inch drive to remove the three upper shock mount nuts.
• Do not remove the large center nut on top of the shock assembly.
• Use a floor jack rated 3-ton minimum to slightly raise or lower the lower control arm until the shock assembly is loose.
• Use a pry bar 18-inch carefully if the lower shock eye is stuck in the bracket.
• Remove the front shock assembly from the wheel well.
• Install the new complete front shock assembly into the upper mount first.
• Use a 14mm socket to install the three upper mount nuts by hand, then tighten them evenly.
• Install the lower shock bolt and nut using a 17mm socket, 19mm socket, 17mm wrench, or 19mm wrench.
• With the lower control arm supported at normal ride height, tighten the front shock fasteners.
• Torque front upper shock mount nuts to 47 Nm (35 ft-lbs).
• Torque front lower shock mounting bolt to 135 Nm (100 ft-lbs).
• Tip: Start all nuts by hand.

Step 5: Replace the Rear Shock Absorber

• Use the floor jack rated 3-ton minimum to lightly support the rear axle near the shock you are replacing.
• Use a 17mm socket, 19mm socket, 17mm wrench, or 19mm wrench to remove the lower rear shock bolt and nut.
• Use a 17mm socket, 19mm socket, 17mm wrench, or 19mm wrench to remove the upper rear shock bolt and nut.
• If the shock is stuck, use a rubber mallet to tap it loose.
• Remove the old rear shock absorber.
• Position the new rear shock absorber with the body and dust boot oriented the same way as the original.
• Install the upper shock bolt by hand first.
• Install the lower shock bolt by hand.
• Use the floor jack rated 3-ton minimum to raise the axle slightly until the shock is near normal ride height.
• Use a 17mm socket, 19mm socket, 17mm wrench, or 19mm wrench to tighten the rear shock bolts.
• Torque rear upper shock bolt to 74 Nm (55 ft-lbs).
• Torque rear lower shock bolt to 74 Nm (55 ft-lbs).
• Tip: Tighten suspension at ride height.

Step 6: Repeat on the Opposite Side

• Repeat the same procedure on the opposite side using the same tools.
• Always replace shocks in pairs so your Tacoma handles and brakes evenly.

Step 7: Reinstall the Wheels

• Install the wheels by hand and start all lug nuts by hand.
• Use a 21mm socket and ratchet 1/2-inch drive to snug the lug nuts in a star pattern.
• Use the floor jack rated 3-ton minimum to lift your Tacoma slightly, remove the jack stands rated 3-ton minimum, and lower it to the ground.
• Use a 21mm socket and torque wrench 1/2-inch drive to tighten the lug nuts.
• Torque wheel lug nuts to 113 Nm (83 ft-lbs).

Step 8: Final Check

• Use a torque wrench 1/2-inch drive to recheck all shock mounting bolts.
• Use a torque wrench 3/8-inch drive to recheck the front upper shock mount nuts.
• Look for brake hose, ABS wire, or suspension contact before driving.

---

✅ After Repair

• ✅ Bounce each corner of your Tacoma by hand. It should settle quickly without repeated bouncing.
• ✅ Take a slow test drive first. Listen for clunks, rattles, or rubbing.
• ✅ After 25-50 miles, recheck the lug nut torque with a 21mm socket and torque wrench 1/2-inch drive.
• ✅ If you replaced the front shock assemblies, get a front wheel alignment. Front suspension removal can slightly change alignment.

---

💰 DIY vs Shop Cost

Shop Cost: $650-$1,200 (parts + labor)

DIY Cost: $250-$650 (parts only)

You Save: $400-$550 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---

🎯 Ready to get started?

HowToo makes it easy: same-day/2-day shipping on every part, plus all the tools and specialty tools you need! Check out the parts and tools sections below to add everything to your cart.
