🔧 Explorer - Rear Window Regulator Replacement

You’ll remove the rear door trim panel, detach the glass from the regulator, and swap in a new regulator assembly. Both rear doors are almost identical, so the steps apply to left or right, with mirror-image layout.

Difficulty Level: Intermediate | Estimated Time: 1.0–1.5 hours per door

---

⚠️ Safety & Precautions

• 🔹Disconnect the negative battery cable before unplugging any door wiring to prevent short circuits or airbag warning lights.
• 🔹Rear doors may have side airbag wiring; avoid probing or powering yellow connectors.
• 🔹Support the door glass securely when it is unbolted from the regulator so it doesn’t drop and shatter.
• 🔹Work with the ignition off; do not operate window switches while parts are loose.
• 🔹Use plastic trim tools, not screwdrivers, on panels to avoid cracking clips or scratching paint.
• 🔹Keep fingers clear of the regulator’s moving arms and cables when testing.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🔹Ratchet handle (1/4" or 3/8" drive)
• 🔹7mm socket
• 🔹8mm socket
• 🔹10mm socket
• 🔹Torx T20 driver
• 🔹Torx T25 driver
• 🔹Small flat trim removal tool (plastic)
• 🔹Large panel removal tool (plastic)
• 🔹Needle-nose pliers
• 🔹Phillips screwdriver
• 🔹Flat-blade screwdriver (small)
• 🔹Painter’s tape (wide)
• 🔹Glass suction cup handle (specialty)
• 🔹Plastic clip removal pliers (specialty)
• 🔹Torque wrench (inch-lb and ft-lb capable)
• 🔹Trim clip assortment kit (specialty)
• 🔹Mechanic’s gloves
• 🔹Safety glasses
• 🔹Work light or headlamp

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔹Rear window regulator (left, driver side) - Qty: 1
• 🔹Rear window regulator (right, passenger side) - Qty: 1
• 🔹Rear window regulator motor - Qty: 1 per side if not reusing
• 🔹Rear door trim panel clips - Qty: 6–10 per door
• 🔹Door water shield butyl tape/sealing strip - Qty: 1 roll
• 🔹Electrical contact cleaner - Qty: 1
• 🔹Blue threadlocker (medium strength) - Qty: 1 small tube

---

📋 Before You Begin

• Park the Explorer on level ground, shift to Park, set the parking brake, and turn ignition off.
• Open the affected rear door fully for best access and lighting.
• Lower the affected rear window until you can see the glass mounting bolts through the inner door openings, if possible. If the regulator is completely failed and the glass is stuck, you will secure the glass in place during the steps instead.
• Disconnect the negative battery cable using a 10mm socket and set it aside so it cannot spring back.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Prepare and secure the window glass

• Open the rear door you are working on and make sure the window is fully closed, or at least high enough that you can tape it to the frame.
• Place two strips of painter’s tape vertically on the outside of the glass, running from the metal door skin up over the top of the door frame and down the inside of the glass. This helps hold the glass once it is detached from the regulator.
• If you have a glass suction cup handle, place it on the window to help you hold it later.
• Use plenty of tape; glass is heavy.

Step 2: Remove trim covers and door handle screws

• Use a small flat trim removal tool to gently pop off the small plastic cover behind the interior door handle (where your fingers grab to pull the door closed).
• Remove the screw behind that cover with a Torx T20 driver or 7mm socket (Ford often uses either; check the head shape).
• Use the small flat trim tool again to pop out the small trim cover near the lower grab handle or armrest as needed, then remove any hidden screw with a Torx T20 driver or 7mm socket.
• Set all screws and covers aside in a container so they don’t get lost.

Step 3: Remove the rear door switch panel

• Use the small flat trim removal tool to gently pry up the rear window switch panel from the armrest area, starting at the rear edge.
• Lift the panel enough to reach the connector, then press the locking tab on the connector with your thumb and pull it out by hand. If tight, gently help with needle-nose pliers on the plug body, not the wires.
• Set the switch panel aside where it will not get scratched.

Step 4: Remove the rear door trim panel

• Slide a large panel removal tool between the door trim panel and the metal door at the lower edge.
• Carefully pry outward until you feel a clip pop loose. Move along the bottom and sides, popping each clip one at a time.
• Once the lower and side clips are free, lift the door panel straight up to unhook it from the window ledge.
• Before pulling it away completely, disconnect any remaining wiring connectors (courtesy light, etc.) by pressing their release tabs with your fingers or a small flat-blade screwdriver.
• Set the door panel somewhere safe, soft side down so it does not scratch.

Step 5: Remove the inner water shield

• The “water shield” is the thin plastic sheet stuck to the metal door with sticky sealant. It keeps water away from the trim panel.
• Use your hands and a small flat trim tool to gently peel the water shield back from the door, starting at a top corner. Try to keep the sealant as clean as possible.
• Peel it back far enough to access the large openings where you can see the regulator, glass, and motor. You do not need to remove it completely if you can fold it out of the way.
• Do not rip the plastic; you will reuse it.

Step 6: Locate and loosen the glass-to-regulator fasteners

• Look through the large opening in the door for where the glass attaches to the regulator (usually two small clamps or bolts on a metal carrier).
• If the glass is too high or low to see the fasteners, reconnect the window switch temporarily, reconnect the battery negative cable with a 10mm socket, turn ignition on, and move the window slightly until the fasteners are visible through the access hole. Then turn the ignition off and disconnect the battery negative again.
• Use a 10mm socket or Torx T25 driver (depending on what you see) to loosen the two glass clamp bolts just enough to release the glass. Do not remove them fully.
• Torque on reassembly per Ford spec: Torque to manufacturer specification (consult Ford service info).

Step 7: Secure the glass in the fully up position

• With the clamps loose, gently push the glass upward by hand until it is fully seated in the top of the frame.
• Add more painter’s tape from the outside of the glass over the top of the door and down the inside to lock it in place. Use at least three tape “straps.”
• If available, use the glass suction cup handle on the outside to help support the glass.
• Make sure the glass is stable before moving on. It should not slide down when you lightly push it.

Step 8: Disconnect the window motor and regulator wiring

• Locate the window motor on the metal inner door (usually near the middle or front side).
• Press the locking tab on the motor’s electrical connector and unplug it by hand. If stiff, gently help with needle-nose pliers on the connector body.
• If the regulator has any additional clips or wiring retainers, release them using a small flat trim tool or clip removal pliers.

Step 9: Remove the window regulator (and motor if needed)

• Find all the regulator mounting bolts on the inner door (usually 4–6 small bolts around the tracks and sometimes at the motor).
• Use an 8mm socket or 10mm socket (whichever matches) with a ratchet to remove each mounting bolt. Support the regulator with your hand as you remove the last bolt so it does not fall inside the door.
• If you’re reusing the existing motor, remove the motor mounting bolts (typically with a Torx T25 driver or 8mm socket) and separate the motor from the old regulator.
• Torque on reassembly per Ford spec: Torque to manufacturer specification (consult Ford service info).
• Carefully maneuver the regulator assembly out through the large opening in the door. Rotate as needed, but do not scratch the paint.

Step 10: Transfer the motor to the new regulator (if reusing)

• Align the old motor with the new regulator’s motor mounting holes.
• Install the motor mounting bolts by hand to avoid cross-threading, then snug them with a Torx T25 driver or 8mm socket.
• Apply a tiny amount of blue threadlocker to each bolt if recommended.
• Torque to manufacturer specification (consult Ford service info).

Step 11: Install the new window regulator assembly

• Carefully feed the new regulator assembly into the door cavity through the large opening, guiding the tracks into the same position as the old unit.
• Align the mounting holes in the regulator with the threaded holes in the inner door.
• Install all regulator mounting bolts by hand first using an 8mm socket or 10mm socket to avoid cross-threading.
• Once all bolts are started, tighten them evenly with the ratchet.
• Torque to manufacturer specification (consult Ford service info).
• Reconnect the motor electrical connector by pushing it in until it clicks.

Step 12: Reattach the glass to the new regulator

• Carefully remove some of the top painter’s tape while holding the glass with one hand or the glass suction cup handle.
• Guide the glass down slowly until its mounting area lines up with the regulator clamps or brackets. Make sure the glass stays in the window tracks at the front and rear.
• Lightly snug the glass clamp bolts with a 10mm socket or Torx T25 driver, but do not fully tighten yet.
• Torque to manufacturer specification (consult Ford service info).

Step 13: Test the window movement (door still open)

• Reconnect the rear window switch and the battery negative cable with a 10mm socket.
• Turn the ignition to ON (engine can stay off).
• With one hand ready to support the glass, slowly move the window up and down using the switch to make sure it travels smoothly and stays in the tracks.
• If it binds or tilts, stop, move it back up, and loosen the glass clamp bolts slightly with a 10mm socket to re-center the glass in the tracks. Then retighten and test again.
• Once movement is smooth, snug the glass clamp bolts to final torque: Tighten to manufacturer specification (consult Ford service info).
• Turn ignition off and disconnect the battery negative cable again with a 10mm socket before reassembling the door.

Step 14: Reinstall the water shield

• Press the plastic water shield back against the metal door, lining up any holes and edges with their original position.
• If the old sealant is not sticky enough, apply new butyl tape/sealing strip around the edges where the original was, then press the shield firmly into it.
• Make sure there are no large gaps; this keeps water away from the door panel.

Step 15: Reinstall the rear door trim panel

• Reconnect all electrical connectors to the door panel (switch panel, courtesy light) by pushing until they click.
• Hook the top edge of the door panel over the window ledge, then rotate the bottom of the panel toward the door.
• Line up the plastic clips with their holes in the door; give the panel a firm tap with your palm around the edges to seat each clip.
• If any clips stayed in the door instead of the panel, remove them with clip removal pliers and move them back to the panel or replace them.

Step 16: Reinstall screws and switch panel trim

• Reinstall the screws you removed from behind the interior handle and armrest using a Torx T20 driver or 7mm socket.
• Torque to snug by hand; do not overtighten (plastic).
• Snap the small plastic covers back over the screws by hand.
• Reinstall the window switch panel by reconnecting its harness (if you unplugged it again) and pressing it down until it clicks into place.

Step 17: Final electrical reconnection and calibration

• Reconnect the negative battery cable for the last time using a 10mm socket and tighten it securely.
• Turn the ignition to ON and test the rear window switch: check full up and full down several times.
• For auto-up/auto-down function (if equipped), hold the switch to fully lower the window and keep holding for 2–3 seconds, then fully raise and hold for 2–3 seconds. This helps the system “learn” end positions.

---

✅ After Repair

• 🔹Verify the rear window moves smoothly, with no grinding noises or jerks.
• 🔹Check that the glass seals properly at the top when closed and does not rattle when you close the door.
• 🔹Verify all door functions: interior handle, lock switch, window switch, and courtesy light.
• 🔹Drive on a rough but safe road and listen for any new rattles from the door area; re-check trim clips if you hear noise.

---

💰 DIY vs Shop Cost

Shop Cost: $450–$700 per rear door (parts + labor)

DIY Cost: $120–$220 per door (parts only)

You Save: $330–$480 per door by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.0–1.5 hours per door.

---
