🔧 Rear Window Regulators - Replacement

The rear window regulator lets the rear door glass move up and down. If the window binds, falls into the door, or makes grinding noises, the regulator assembly usually needs replacement.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• Support the window glass before removing the regulator so it does not drop.
• Disconnect the negative battery cable before working in the door. This helps prevent accidental window or lock operation.
• Use care around sharp door-shell edges and the side air bag area in the door.
• If the rear door has a power window switch, keep fingers clear during testing.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 7mm socket
• 10mm socket
• Ratchet
• Socket extension
• Trim panel tool
• Flat trim tool
• Painter’s tape
• Needle-nose pliers
• Torque wrench
• Safety glasses
• Gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear window regulator assembly - Qty: 1
• Rear door vapor barrier adhesive - Qty: 1
• Replacement door panel clips - Qty: 1 set

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Lower the rear window if possible before disconnecting the battery, then tape the glass in place.
• Disconnect the negative battery cable.
• Keep the glass supported the whole time.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the rear door trim panel

• Use a 7mm socket to remove the trim screws in the armrest and pull handle area.
• Use a trim panel tool to release the door panel clips around the edges.
• Lift the panel up and off the door shell.
• Unplug any switch connectors carefully.

Step 2: Remove the water shield

• Use a flat trim tool to peel the vapor barrier back slowly.
• Save it if it is still sealed and reusable.

Step 3: Secure the glass

• Raise or position the glass as needed and hold it with painter’s tape from the outside of the door.
• If the regulator is broken, support the glass by hand while loosening the hardware.

Step 4: Remove the regulator from the door

• Use a 10mm socket and ratchet with extension to remove the regulator bolts.
• Disconnect the motor electrical connector.
• Guide the regulator out through the access opening in the door.

Step 5: Install the new regulator

• Position the new regulator in the door and start all fasteners by hand.
• Reconnect the motor connector.
• Torque to 9 Nm (80 in-lbs) for the regulator fasteners unless the replacement part instructions specify otherwise.

Step 6: Reattach and test the glass

• Remove the tape and align the glass in the regulator clamps.
• Use a 10mm socket to tighten the glass-to-regulator fasteners.
• Torque to 9 Nm (80 in-lbs).
• Cycle the window up and down with the switch to verify smooth movement.

Step 7: Reassemble the door

• Reinstall the vapor barrier and door panel clips.
• Use a 7mm socket to install the trim screws.
• Reconnect the battery negative cable.

---

✅ After Repair

• Test the rear window several times for smooth travel.
• Check that the glass seals correctly at the top.
• Listen for rubbing, clicking, or cable noise.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $90-$220 (parts only)

You Save: $260-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---

🎯 Ready to get started?

HowToo makes it easy: same-day/2-day shipping on every part, plus all the tools and specialty tools you need! Check out the parts and tools sections below to add everything to your cart.

---

🔧 Side View Mirrors - Replacement

The side view mirror assembly bolts to the door and connects to the power mirror wiring. If the housing is cracked, the glass is broken, or the adjustment motor has failed, replacing the full mirror assembly is usually the cleanest fix.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable before unplugging mirror wiring.
• Be careful not to scratch the paint or crack the mirror glass during removal.
• If your Sierra has heated or power mirrors, make sure the connector is fully seated before reassembly.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 7mm socket
• 10mm socket
• Ratchet
• Socket extension
• Trim panel tool
• Flat trim tool
• Torque wrench
• Safety glasses
• Gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Side view mirror assembly - Qty: 1
• Mirror mounting nuts - Qty: 1 set
• Door panel clip set - Qty: 1 set

---

📋 Before You Begin

• Park with the front wheels straight.
• Disconnect the negative battery cable.
• Protect the painted edges with tape.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the interior mirror trim

• Use a flat trim tool to remove the small sail panel trim at the front corner of the door.
• Set the trim aside carefully.

Step 2: Unplug the mirror connector

• Reach behind the trim area and disconnect the mirror wiring plug by hand.
• If access is tight, use a trim panel tool to move the door panel edge slightly.

Step 3: Remove the mirror fasteners

• Use a 10mm socket and ratchet with extension to remove the mirror mounting nuts from inside the door.
• Hold the mirror with your other hand while removing the last nut.
• Torque to 9 Nm (80 in-lbs) on reassembly.

Step 4: Install the new mirror

• Place the new mirror in position and start the nuts by hand.
• Reconnect the wiring connector before fully tightening.
• Use a 10mm socket to tighten the nuts evenly.
• Torque to 9 Nm (80 in-lbs).

Step 5: Reinstall the trim and test

• Reinstall the sail panel trim.
• Reconnect the battery negative cable.
• Test mirror adjustment, heating, and power-fold functions if equipped.

---

✅ After Repair

• Check that the mirror sits flush against the door.
• Verify power adjustment works in all directions.
• Check heated mirror operation if equipped.
• Confirm there are no wind noises at road speed.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $80-$250 (parts only)

You Save: $170-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-2 hours.

---
