🔧 Lancer - Rear Window Regulator Replacement

The rear window regulator is the lift mechanism inside the door that moves the glass up and down. When it fails, the window may drop, move crooked, move slowly, or not move at all. You’ll remove the rear door panel, secure the glass, swap the regulator (and motor if needed), then reassemble and test.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours (one door)

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the negative battery cable before door work to reduce the risk of accidental airbag/SRS issues and to prevent short circuits.
• ⚠️ Glass can drop suddenly—support the window glass with tape before loosening anything.
• ⚠️ Wear gloves and safety glasses; door metal edges are sharp.
• ⚠️ Keep the key away from the car while connectors are unplugged to prevent the window being operated.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" ratchet
• 6" extension for 1/4" ratchet
• Phillips #2 screwdriver
• Flat trim tool
• Needle-nose pliers
• Pick tool
• Painter’s tape 2" wide
• Torque wrench 3/8" drive (10–80 Nm range)
• Work light
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear window regulator (left or right, correct side) - Qty: 1
• Rear window motor - Qty: 1 (only if not included with regulator)
• Door panel retainer clip set - Qty: 1 (replace any broken clips)
• Butyl tape (vapor barrier adhesive) - Qty: 1

---

📋 Before You Begin

• Park on level ground and turn ignition OFF.
• Open the rear door fully and lower the window if it still works (it helps access the glass clamps).
• Disconnect the battery negative terminal using a 10mm socket, then wait at least 60 seconds.
• Take photos of connectors and clip locations.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the rear door trim panel

• Use a flat trim tool to carefully pop off the small trim covers in the door pull/handle area (if equipped).
• Remove any exposed screws using a Phillips #2 screwdriver.
• Slide a flat trim tool under the bottom edge of the door panel and pop the retaining clips free one-by-one.
• Lift the panel straight up to unhook it from the window ledge.
• Unplug the window switch connector(s) using a pick tool to gently release the locking tabs (a locking tab is the small plastic latch that holds the connector tight).

Step 2: Remove the vapor barrier (water shield)

• Peel back the plastic vapor barrier slowly by hand.
• If the adhesive is stubborn, use a flat trim tool to separate it without tearing.
• Stick it out of the way so it stays clean.
• Don’t discard it—water leaks happen without it.

Step 3: Secure the window glass

• If the window is up, apply multiple vertical strips of painter’s tape 2" wide from the outside of the glass over the top of the door frame and down onto the inside.
• If the window is down but still attached, you’ll raise it by hand after loosening the clamps (next step), then tape it up.

Step 4: Detach the glass from the regulator

• Locate the glass-to-regulator clamp bolts through the door access holes.
• Use a 10mm socket with a 1/4" ratchet and extension to loosen (and remove if required) the clamp bolts.
• With the clamps released, lift the glass fully up by hand and add more painter’s tape 2" wide to hold it securely.

Step 5: Unplug and remove the window motor/regulator assembly

• Unplug the regulator motor connector using a pick tool.
• Remove the regulator mounting bolts using a 10mm socket, 1/4" ratchet, and extension.
• If the motor is separate from the regulator, remove motor fasteners using a 10mm socket.
• Carefully maneuver the regulator out through the largest door opening.

Step 6: Install the new regulator (and motor if separate)

• Guide the new regulator into the door and line up the mounting holes.
• Start all mounting bolts by hand first, then tighten with a 10mm socket.
• Use a torque wrench 3/8" drive to tighten fasteners to factory specification.
• If transferring the motor, install it onto the new regulator and tighten using a 10mm socket, then torque to factory specification using a torque wrench 3/8" drive.
• Hand-start bolts to avoid cross-threading.

Step 7: Reattach the glass to the regulator

• Lower the glass carefully until it sits in the regulator clamps.
• Install/tighten the clamp bolts using a 10mm socket.
• Use a torque wrench 3/8" drive to tighten to factory specification.
• Remove some tape but leave enough to catch the glass if it slips while testing.

Step 8: Quick function test (before reassembly)

• Reconnect the battery negative terminal using a 10mm socket.
• Plug in the window switch connector and motor connector (if unplugged) by hand.
• Turn ignition ON and run the window down and up a few times, watching for smooth travel and correct alignment.
• Turn ignition OFF and disconnect the battery negative terminal again using a 10mm socket before final reassembly.

Step 9: Reinstall the vapor barrier and door panel

• Press the vapor barrier back into place; add butyl tape where the original adhesive no longer sticks.
• Reconnect all connectors by hand.
• Hook the top of the door panel onto the window ledge and press it down into place.
• Press the clips in around the edges using firm hand pressure.
• Reinstall screws using a Phillips #2 screwdriver and snap trim covers back on by hand.

---

✅ After Repair

• Reconnect the battery negative terminal using a 10mm socket.
• Cycle the rear window fully down and fully up 3–5 times to confirm smooth movement and proper sealing at the top.
• Check the door panel for rattles and verify the switch works normally.
• If the window “auto” feature acts odd (if equipped), cycle full down/full up once more and hold the switch for 2 seconds at each end.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $90-$250 (parts only)

You Save: $260-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
