🔧 Camry - Rear Turn Signal Bulb Replacement

Your Camry’s rear turn signal bulbs are inside the tail lamp assemblies and are accessed from the trunk. You’ll remove a small section of trunk liner, twist the bulb socket out, swap the bulb, then test the signal before reinstalling everything.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn the car OFF and remove the key/fob from the car area.
• ⚠️ Let bulbs cool before touching; they can be hot.
• ⚠️ Wear safety glasses—trunk clips and trim can snap loose.
• ⚠️ Do not touch the glass of a halogen bulb with bare fingers; skin oils can shorten bulb life.
• ⚠️ Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" ratchet
• 6" socket extension
• Phillips screwdriver #2
• Trim clip removal tool
• Flashlight
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear turn signal bulb (7440 amber) - Qty: 2
• Trunk trim push clips - Qty: 2

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Open the trunk and clear out cargo so you can work comfortably.
• Tip: Replace both sides to match brightness.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Access the tail lamp area in the trunk

• Use a flashlight to locate the trunk liner behind the tail lamp (left or right side).
• Remove any plastic fasteners using a trim clip removal tool.
• If a screw is present, remove it with a Phillips screwdriver #2.
• Peel the liner back enough to see the back of the tail lamp and bulb sockets.

Step 2: Remove the tail lamp retaining nuts

• Use a 10mm socket, 1/4" ratchet, and 6" socket extension to remove the tail lamp nuts.
• Place the nuts somewhere safe so they don’t get lost in the trunk trim.

Step 3: Pull the tail lamp assembly outward

• Hold the lamp with one hand from the outside and gently pull it straight back.
• If it feels stuck, wiggle slightly—don’t pry hard on the painted body.
• Tip: Pull straight back to avoid breaking alignment pins.

Step 4: Remove the rear turn signal bulb socket

• Find the turn signal socket on the back of the tail lamp (usually the amber/turn position).
• Twist the socket counterclockwise by hand and pull it out.

Step 5: Replace the bulb

• Wear nitrile gloves to keep oils off the bulb.
• Pull the old bulb straight out of the socket.
• Push the new rear turn signal bulb (7440 amber) straight into the socket until fully seated.

Step 6: Reinstall socket and tail lamp

• Insert the socket back into the tail lamp and twist clockwise until it locks.
• Align the tail lamp pins with the body holes and press the lamp straight in.
• Install the nuts using a 10mm socket and 1/4" ratchet.
• Torque to 5 Nm (44 in-lbs)

Step 7: Reinstall trunk liner

• Reposition the liner.
• Reinstall clips using the trim clip removal tool (or replace with new clips if any are damaged).
• Reinstall any screw using a Phillips screwdriver #2.

---

✅ After Repair

• Turn the car ON and test the left and right turn signals and hazards.
• Verify the turn signal flashes at a normal speed (fast flashing usually means a bulb isn’t working).
• Check that the tail lamp sits flush and doesn’t wobble.

---

💰 DIY vs Shop Cost

Shop Cost: $80-$180 (parts + labor)

DIY Cost: $10-$30 (parts only)

You Save: $70-$150 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---

🎯 Ready to get started?

HowToo makes it easy: same-day/2-day shipping on every part, plus all the tools and specialty tools you need! Check out the parts and tools sections below to add everything to your cart.

Assumption: Your Camry uses 7440 amber rear turn signal bulbs (common fitment for this model).
