🔧 Ball Joints - Replacement

Assumption: This guide covers the front lower ball joints on your XC60. On this model, the ball joint is typically serviced at the front lower control arm area, so access and fastener style matter.

Worn ball joints can cause clunks, uneven tire wear, and vague steering. Replacing them restores steering feel and helps keep the front suspension safe and tight.

Difficulty Level: Advanced | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• Support the vehicle securely with jack stands; do not work under a car held only by a jack.
• The steering knuckle and suspension can shift suddenly when the ball joint is released.
• If your XC60 has a wheel speed sensor wire or brake hose near the work area, keep it clear and do not let the knuckle hang by it.
• Torque-critical suspension fasteners must be tightened with the vehicle at normal ride height if the manual calls for it.
• No battery disconnect is normally required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated for vehicle weight)
• Wheel chocks
• Safety glasses
• Mechanic gloves
• Metric socket set
• Metric wrench set
• Torx socket set
• E-Torx socket set
• Breaker bar
• Torque wrench
• Ball joint separator (specialty)
• Pry bar
• Penetrating oil
• Hammer
• Trim clip removal tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front lower ball joint - Qty: 2
• Ball joint mounting hardware kit - Qty: 1 set
• Control arm pinch bolt hardware - Qty: 1 set
• Front wheel alignment - Qty: 1

---

📋 Before You Begin

• Park on level ground and chock the rear wheels.
• Loosen the front wheel bolts before lifting.
• Spray penetrating oil on the ball joint fasteners and pinch points if rust is present.
• Plan on getting a wheel alignment after the repair.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front of the vehicle

• Use a floor jack to raise the front of the XC60 at the proper lift point.
• Set the vehicle on jack stands and verify it is stable before working.
• Remove the front wheel with a metric socket.

Step 2: Access the ball joint area

• Turn the steering wheel as needed to give yourself room to work.
• Locate the lower ball joint where the control arm meets the steering knuckle.
• Clean the area first so fasteners are easier to see.

Step 3: Separate the ball joint from the knuckle

• Use the correct metric socket and breaker bar to remove the ball joint retaining hardware.
• If the joint is pressed or tightly seated, use a ball joint separator to free it from the knuckle.
• Do not hammer directly on the steering knuckle unless the service procedure allows it.

Step 4: Remove the old ball joint

• Use the appropriate Torx socket or E-Torx socket if the mounting bolts use those heads.
• Remove the old ball joint from the control arm area.
• Inspect the control arm, knuckle, and boot area for wear or damage.

Step 5: Install the new ball joint

• Position the new ball joint and start all fasteners by hand first.
• Use the torque wrench to tighten the ball joint fasteners to factory specification.
• If a pinch bolt or locking nut is used, replace it with new hardware.

Step 6: Reconnect and torque suspension fasteners

• Reinstall the knuckle connection and verify the joint is fully seated.
• Tighten all related suspension fasteners to factory specification.
• If any fastener is a torque-to-yield type, replace it rather than reusing it.

Step 7: Reassemble the wheel and repeat on the other side

• Reinstall the wheel and snug the lug bolts by hand first.
• Lower the vehicle and torque the wheel bolts to factory specification.
• Repeat the same procedure on the opposite side.

---

✅ After Repair

• Test-drive slowly and listen for clunks or looseness.
• Check steering feel and confirm the vehicle tracks straight.
• Schedule a wheel alignment as soon as possible.
• Recheck for loose fasteners and inspect for torn boots after the road test.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$900 (parts + labor)

DIY Cost: $120-$300 (parts only)

You Save: $330-$600 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
